  1. Chapter 11Modern Atomic Theory

  2. Electromagnetic Radiation • Light is a form of electromagnetic (EM) radiation • All forms of EM radiation are types of kinetic energy • See page 306

  3. EM Radiation • EM radiation can be described as traveling in waves or as packets of energy called photons

  4. EM Radiation • Describe each form of EM radiation by its: • Wavelength • Frequency • Energy of its photon

  5. All forms of EM radiation travel at the speed of light (c) Wavelength x frequency = speed of light

  6. EM Radiation • The longer the wavelength the: • lower the frequency and the lower the energy of the EM radiation • The shorter the wavelength the: • higher the frequency and the higher the energy of the EM radiation

  7. EM Radiation • Compare the wavelength, frequency, and energy of: • Ultraviolet light and infrared light

  8. EM Radiation • The higher the energy of the EM radiation the more damaging it is to living tissue. • CONSIDER GAMMA RAYS, X-RAYS, AND UV LIGHT

  9. Emission of Energy by Atoms • Thanks to the work of Bohr we know that: • When atoms are energized by an input of energy their electrons are excited (energized) • When excited electrons return to lower energy states they emits energy in the form of light. • Emits photons of energy • Energy of the photons emitted depends upon how excited the electron was.

  10. Bohr Experiment (~1911) • Bohr excited hydrogen atoms by running electricity through a tube of hydrogen gas. • The gas gave off a pink light.

  11. Bohr Experiment (~1911) • Bohr aimed a beam of the pink light at a “prism” • Found the pink light generated a line spectrum not a continuous spectrum • Line spectrum – specific colors of light observed • Continuous spectrum – all colors of light present

  12. Bohr Experiment (~1911) • He observed 4 bands of color: (pg 310) • Purple (410 nm) • Blue (434 nm) • Green (486 nm) • Red (656 nm)

  13. Bohr Experiment (~1911) • He then calculated the energy of each color of light • _____________ was the highest energy and _____________ was the lowest energy.

  14. Bohr’s Interpretation of the Data • The electrons circle the nucleus in orbits of specific energies. • Larger orbits are of higher energy than smaller orbits

  15. Bohr’s Interpretation of the Data • Electrons are always in one of the circular orbits. • The electricity excites electrons and allows them to move to higher energy orbits.

  16. Bohr’s Interpretation of the Data • When the excited electrons return to lower energy orbits they emit energy in the form of light. • The difference in energy levels between the orbits determines the energy of the light given off.

  17. Bohr’s Interpretation of the Data • Because only certain wavelengths of light are emitted only certain energy changes are occurring • 4 bands of light, therefore 4 possible energy changes are possible • Say energy levels are quantized, meaning only specific energy levels are available to electrons.

  18. Bohr’s Model • When Bohr’s mathematical approach was applied to other elements it didn’t work. • Bohr’s model of the atom has been revised to replace the circular orbits with “wave mechanical model” of the atom

  19. Modern Atomic Structure • Still picture electrons to be at specific energy levels, but no longer picture them as traveling in circular orbits. • The current model of the atom locates electrons in orbitals.

  20. Modern Atomic Structure • Orbitals are very different than Bohr’s orbits • Read the firefly analogy on page 313

  21. Orbitals • Each orbital is of a specific energy, size, and shape • Each orbital can hold a maximum of 2 electrons of opposite spin (Pauli exclusion principle)

  22. Orbitals • The exact path of an electron in an orbital is not known. • Heisenberg uncertainty principle states that it is impossible to determine the location and path of an electron at the same time

  23. Orbitals • Orbital shapes describe the region in space where an electron will be found 90% of the time.

  24. Modern Atomic Theory • Atoms have specific energy levels in which electrons may be found. • Called Principal Energy Levels (PEL) • PEL farther from the nucleus are larger and of higher energy. • Assign a number (n) to each PEL • See board

  25. Modern Atomic Theory • Within each PEL are sublevels • Sublevels are named: s, p, d, and f • The larger the PEL the more sublevels it contains

  26. Modern Atomic Theory

  27. Modern Atomic Theory

  28. Modern Atomic Theory • Sublevels contain orbitals.

  29. Describing Orbitals • See pages 314/315 for diagrams of the orbitals • S orbitals are spherical • The 3 p orbitals are shaped

  30. Putting it All Together • Unless they are excited, electrons always occupy the lowest energy orbital with room. • Electrons enter orbitals of a given sublevel one at a time before pairing up (Hund’s rule) • Consider 2 electrons in a p sublevel:

  31. The fun part! • Our goal is to write the following for atoms and ions: • Electron configuration • Box/energy diagram • Lewis dot symbol • Our goal is also to: • Identify core and valence electrons

  32. Terms • Electron configuration – shows the number of electrons in each sublevel • Box/energy diagram – shows the number of electrons in each orbital • Orbitals are shown as boxes • electrons are shown as arrows

  33. Terms • Lewis Dot Symbol – shows the valence electrons as dots around the symbol for the element • Maximum of 2 electrons per side of the symbol

  34. Terms • Valence electrons – all the electrons in the highest occupied PEL • Valence electrons are the ones involved in bonding • Core electrons – all electrons not considered valence electrons

  35. You will be given this. • Sublevels listed from lowest energy to higher energy: 1s 2s 2p 3s 3p 4s 3d 4p 5s 4d 5p……….
