  1. Backup and Disaster Recovery for Oracle in Physical, Virtual, and Cloud Environments Christian Ruoff Senior Technical Engineer SEP Software Corp. cr@sep.de

  2. Introduction Christian Ruoff Senior Technical Engineer SEP Software Corp. cr@sep.de

  3. SEP Software Corp. SEP sesam One backup solution for the entire enterprise

  4. Backup Considerations • When seeking a backup solution, users must consider: • Will my infrastructure be supported? • How quickly will my backups complete? • Will my data be there when I need it? • What is the investment compared to other backup solutions? • Compatibility: • Performance: • Reliability: • Cost:

  5. Why SEP sesam for your Oracle Environment? • One Solution for the Entire Enterprise • Because SEP sesam supports such a wide range of products, enterprises can consolidate all backup needs to one solution and have one central management console. • Performance • SEP sesam’s architecture is only limited by the connection speed and hardware configuration. Up to 64 data streams to tape and unlimited to disk or to the cloud! • Reliability • Set it and forget it reliability. Once a backup completes successfully, the data is ALWAYS there, no exceptions! • Cost • The best TCO, ROI and performance in the industry.

  6. Product Integration

  7. One Solution for the Enterprise • A Single Console to Manage All Sites • The powerful Master GUI allows the System Administrator to layer multiple GUI’s to manage infinite local or remote locations. • Access backups from the main backup server or any authorized desktop, laptop, or workstation. • Back up or restore data from locally attached storage, across the WAN, or from the cloud. • Customize and save different GUI layouts and views for fast and efficient use.

  8. One Solution for the Enterprise

  9. Performance Multi-Streaming Technology Reduces Backup Windows by at least 50%

  10. Customer Results Vodafone Europe: 3,500 remote sites backed up simultaneously. US National Archiving and Records Administration (NARA): Enterprise email system backups decreased from 6+ days to 11 hours. Port of San Diego: Backup times went from 100+ hours and regularly failing to under 4 hours without errors. Oracle backups decreased from 4+ hours to 42 minutes. Public Works and Government Services of Canada: 42 locations backed up across the country.

  11. SEP sesam Features Multi Streaming Technology • Unlimited simultaneous backup streams, resulting in at least a 50% decrease in backup windows. SEP Easy Archive • SEP Easy Archive uses WORM (Write Once Read Many) Technology to prevent unintentional loss or deletion of data as well as unauthorized edits, changes or deletion of data. Deduplication • Destination side and source side available. • Reduces the need for more expensive storage and replication. Generic Drivers • Supports any hardware/media recognized by the O/S.

  12. Oracle Backup • SEP sesam supports the following functions: • Backup level: copy, full, differential, incremental and Archivelog • Database Point-in-Time Recovery • Parallel Backup Channels: Increase backup times • Archive Log Handling (Example: Delete archive logs after backup or after 3 successful backups) • Restore Control File with or without RMAN catalog • Recover After Restore • All backup methods are fully managed and integrated into a heterogeneous, cross-platform, centralized solution.

  13. SEP sesam for Oracle Environments Oracle Databases • SEP sesam is compatible with Oracle Linux or any mixed O/S environment • Data is written directly from database to backup media without writing the data to an intermediate landing zone first • Communicates directly with RMAN • Instantly reduces required Oracle DB disk space by 50%, saving money on hardware costs • Data is delivered directly to Database, Tablespace and Data File-Level Backup and Restores

  14. SEP sesam Oracle Environments Multi-Streaming Technology SEP’s patented Multi-Streaming Technology allows for simultaneous streams, decreasing backup windows by at least 50% Media Management Library Users may perform full and incremental backups while the database is online, all while keeping the information on the database accessible

  15. Bare Metal Recovery • BMR for Linux Servers • Restore entire servers, operating systems, and databases quickly and easily using a universal boot medium.   • Easily restore the environment to full operation within minutes.  • Can be controlled by a single point of administration.   • Disk drive and system failures need no longer be a devastating occurrence. • Available for Virtual Machines

  16. Stand-Alone Oracle System For a single Oracle server, the SEP sesam client and SEP sesam Oracle client provide the backup capabilities for up to five SIDs: Installation: Each 1x SEP sesam Client Each 1x Oracle DB package Licensing: 1x Data Backup Client (DC) 1x Oracle online module (includes 5 SID) O/S: Windows 2000 Oracle Database

  17. Distributed Oracle System The example below shows two Oracle database servers hosted by two different O/S for a total of eight SIDs. Installation: Each 1x SEP sesam Client Each 1x Oracle DB package Licensing: 2x Data Backup Clients (DC) 1x Oracle online module (includes 5 SID) 1x Oracle extension (5 SID) O/S: Oracle Linux Oracle Database O/S: Windows 2000 Oracle Database

  18. Distributed Oracle System with Dedicated RMAN Server Below are two Oracle database servers hosted by two different operating systems with a dedicated Recovery Manager (RMAN) server; a total of eight active SIDs and one RMAN catalog SID. Installation: Each 1x SEP sesam Client Each 1x Oracle DB package Licensing: 3x Data Backup Clients (DC) 1x Oracle online module (includes 5 SID) 1x Oracle extension (5 SID) O/S: Oracle Linux Oracle Database O/S: Windows 2000 Oracle Database RMAN Recovery Catalog

  19. Oracle Clusterware Environment This example shows a two-node Oracle Clusterware (OCW) standby cluster is displayed with a total of five active SIDs. Installation: Each 1x SEP sesam Client Each 1x Oracle DB package Licensing: 3x Data Backup Clients (DC) 1x Oracle online module (includes 5 SID) 1x Oracle extension (5 SID) O/S: Oracle Linux Oracle Database O/S: Windows 2000 Oracle Database

  20. Oracle Real Application Clusters (RAC) Environments In the following example, a 4-node Oracle RAC environment is displayed with a total of 12 RAC SIDs and 5 local SIDs across different operating systems. Installation: 1x SEP sesam client (per server) 1x Oracle DB package (per server) SEP GUI 12x RAC SID virtual servers Licensing: 16x Data Backup Clients (DC) 1x Oracle online module (includes 5 SID) 3x Oracle extension (5 SID) O/S: Oracle Linux Oracle Database O/S: RHEL Oracle Database O/S: Linux Oracle Database O/S: Windows 2000 Oracle Database

  21. Oracle Security SEP sesam provides many options to enhance security and assist in meeting compliance requirements: • The backup data streams can be encrypted to protect access to the guest virtual machine backup from unauthorized users. • Logs can be sent to a syslog server to maintain a single centralized location for tracking information. • Notifications can be sent to email addresses or cell phones to provide immediate alerts for failed or completed jobs. • These options are all part of the SEP sesam notification system that can be used to bring backup information into a centralized audit system.

  22. High-Availability SEP sesam fully supports backup of all Oracle System Identifier (SID) instances in a high-availability Oracle RAC environment. • As the SEP sesam components communicate directly with the RAC SID virtual IP addresses, backup tasks are able to properly follow the SIDs if they have moved over to a different RAC host.

  23. SEP and Oracle Partnership Oracle recognizes SEP for its commitment to deliver high-performing backup and disaster recovery solutions and addressing the challenges of joint Oracle/SEP customers. Having a close partnership with Oracle helps reinforce our commitment to provide a backup solution that meets or exceeds key Oracle integration standards. CERTFICATIONS Oracle Exastack Ready • Oracle Exadata Ready • Oracle Exalogic Ready • Oracle SuperCluster Ready • Oracle Exalytics Ready • Oracle Weblogic Ready • Oracle Database Ready • Oracle Linux Ready • Oracle VM Ready • Oracle Solaris Ready

  24. Questions & Answers
