Presentation Transcript
What s new in sql server 2012 reporting services



Updated: 06-Nov-2011

What s new in sql server 2012 reporting services1
What’s new in SQL server 2012 reporting services

  • Empower users with a new visual design experience (Power View)

  • Increase productivity with user-defined data alerts

  • Increase performance and improve administration within SharePoint

    • SharePoint shared service application

    • Built-in scale-out for Reporting Services service applications

    • SharePoint cross-farm reporting

    • Integrated backup and recovery, ULS logging, PowerShell, etc.

  • Visual Studio 2010 designers

  • Excel renderer for Excel 2007-2010

  • Word renderer for Word 2007-2010

Data alerts
Data alerts

  • Data alerts can be defined on the report feed(s)

    • Name

    • Intuitive alert rules based on conditions (AND and OR)

    • Scheduling settings

    • Advanced: Start/End dates

    • Email address, Subject and Description

  • Can only be based on reports that use data sources with stored credentials

  • Alerts can be managed by users and administrators

    • View status, Edit, Delete, Run

  • Only available in SharePoint integrated mode

Sharepoint integrated mode
SharePoint Integrated Mode

  • Shared Service Application

    • Maximum set of SharePoint IT management capability is enabled

    • Lower TCO on IT who can now leverage existing SharePoint skillset and experience

  • All configuration is now simplified and easier, use:

    • Central Admin

    • PowerShell

  • Leverages SharePoint’s in-built scale capability

  • File types are understood

  • Context menus to manage reports, configure alerts, etc. are available

  • BISM Connection File content type is installed

    • Stores connection information to a tabular BI Semantic Model (PowerPivot file or hosted tabular model)

    • Users can launch Power View from this document

    • It can also be used in a connection string to access the model

Sql server 2012 power view
Sql server 2012 power view

  • Power View is an interactive data exploration, visualization, and presentation experience

    • Highly visual design experience

    • Rich meta-driven interactivity

    • Presentation-ready at all times

  • Provides intuitive ad-hoc reporting for business users such as data analysts, business decision makers, and information workers

Power view system requirements
Power view system requirements

  • A Power View report must be based on a deployed tabular BI Semantic Model

    • PowerPivot workbook in a SharePoint library

    • Tabular model hosted on a tabular instance of Analysis Services

  • DAX Tabular Queries are used to query the model

  • Ordinarily, the tabular BI Semantic Model needs to be optimized for the Power View experience

  • Server(s):

    • SharePoint Server 2010 SP1

    • SQL Server 2012 Reporting Services Add-in for SharePoint

  • Client:

    • Supported browsers:

      • Windows Vista: IE7 32-bit, FireFox 4

      • Windows 7: IE8 32-bit, IE9 32-bit, FireFox 4, Safari

      • Note the InPrivate browsing feature of IE is not supported

    • Silverlight 4 (Silverlight 5 by RTM)

Creating and designing power view reports
Creating and designing Power View Reports

  • Users create a new Power View report (.rdlx) from:

    • A BISM Connection File (.bism)

    • An Excel document (.xlsx) in the PowerPivot Gallery (in Gallery view)

    • A reporting services (.rsds) shared data source based on a tabular BI Semantic Model

  • Reports may be saved to SharePoint libraries

  • Clicking the report will open it

    • The report opens in Preview mode

    • If the user has permission, they can switch to Edit mode

  • The design experience consists of:

    • Canvas

    • Home and Insert ribbons

    • Field List

    • Field selection

    • Layout selection

    • Filter area

    • Title

  • The report may be viewed in Preview or Full Screen mode

  • Visualizations can be added to the canvas and then configured using the Layout Selection

Sql azure reporting1
SQL Azure Reporting

  • SQL Azure Reporting is

    • SQL Server Reporting Services technology delivered as a service on the Windows Azure Platform

    • Available for testing via public CTP3

    • Ideal for operational reporting against SQL Azure data

    • Enterprise-ready with automatic support for HA

    • Designed to scale elastically with demand

  • Get started quickly

    • Provision report server via Windows Azure Management Portal

    • Build reports with Reporting Services Report Designer

    • Deploy reports to report server

    • Render reports with Visual Studio ReportViewercontrols

Sql azure reporting2
SQL Azure Reporting

  • Use familiar technologies

    • Visual Studio Report Designer

    • RDL (Report Definition Language)

    • Report items and visualizations

    • Report Server Web Service / URL access

    • Visual Studio ReportViewerControl

  • Identity and access control

    • SQL authentication supported (no support for integrated authentication)

    • Admin user configured during provisioning

    • Admin user has all rights on server, use for administration only

    • Provision users using portal or web service

    • Add users to appropriate item (Browser, Publisher) and system roles (User, Admin)

    • Grant item-level permissions to folders or reports

  • Differences in comparison to Reporting Services

    • Focus on logical vs. physical administration

    • Report catalog and temporary database automatically provisioned

    • Windows Azure Management Portal replaces Report manager

    • SSL Required

    • SQL Azure data sources only

  • Unsupported Reporting Services features

    • Report Builder

    • Subscriptions, schedules, caching

    • Custom extensions

    • Report models

    • External images
