  1. AnalisisRangkaianDigital SistemKomputer UniversitasNarotama

  2. Topik 5 – Desain Rangkaian Kombinasional • Task: Given a description of problem (logical statement), find the corresponding digital circuits that produce the output (answer) given a set of inputs (condition). • Contoh-2: • Parking lot controller • Elevator controller • Prime number indicator • Adder, subtractor, …

  3. Brute-force approach Row N3 N2 N1 N0 F 0 0 0 0 0 0 1 0 0 0 1 1 2 0 0 1 0 1 3 0 0 1 1 1 4 0 1 0 0 0 5 0 1 0 1 1 6 0 1 1 0 0 7 0 1 1 1 1 8 1 0 0 0 0 9 1 0 0 1 0 10 1 0 1 0 0 11 0 0 1 1 1 12 1 1 0 0 0 13 1 1 0 1 1 14 1 1 1 0 0 15 1 1 1 1 0 • Design: given a description or truth table, find the corresponding Boolean expression and digital circuit. • Brute-force design methodology: • Truth table  canonical sum •  SoP or sum of minterms •  AND-OR / NAND-NAND • Example: prime number detector F = SN3N2N1N0(1,2,3,5,7,11,13)

  4. Minterm list -> canonical sum

  5. Algebraic simplification • Recall (T8) X · Y + X · Y’ = X • Simplify equation to reduce number of gates & gate inputs

  6. Resulting circuit

  7. Combinational circuit design/minimization • Objective: • Minimizing # logic gates • Minimizing # inputs to the logic gates • Note different logic gates may have different # transistors • General idea: simplify the Boolean expression using the theorems, especially (T10, T10’, T13, T13’) • Karnaugh-map (K-map) • Graphical representation of the truth table • Offers visualization of (T10, T10’) • Works for functions with less than 6 variables • Real world: use programs to minimize logic circuits • E.g., VHDL, Verilog, ABEL, …

  8. Karnaugh-map usage • Plot 1s corresponding to minterms of function. • Circle largest possible rectangular sets of 1s. • # of 1s in set must be power of 2 • OK to cross edges • Read off product terms, one per circled set. • Variable is 1  include variable • Variable is 0  include complement of variable • Variable is both 0 and 1  variable not included • Circled sets and corresponding product terms are called `prime implicants’ • Minimum number of gates and gate inputs

  9. 3 variable example: F = S(1,2,5,7) • Rules of thumb: • Group (prime implicant) as large (many 1s) as possible • As few groups as possible • Overlaps are OK

  10. 4 variable K-map example Note how it maps to the rows of the truth table

  11. Prime-number detector revisited

  12. Compare with the previous circuit • When we solved algebraically, we missed one simplification- the circuit below has three less gate inputs.

  13. Design example: alarm controller • Problem statement: • The ALARM output is 1 if PANIC is 1, or if ENABLE is 1 and the house is not secure. • The house is secure if WINDOW, DOOR, GARAGE are all 1 • This can be put in logic expressions as follows: ALARM = PANIC + ENABLE · SECURE’ SECURE = WINDOW · DOOR · GARAGE ALARM = PANIC + ENABLE · (WINDOW · DOOR · GARAGE)’ Multiply out and use (T13), we get the SoP form ALARM = PANIC + ENABLE · WINDOW’ + ENABLE · DOOR’+ ENABLE · GARAGE’

  14. K-map with don’t-cares • In some cases, the output of a combinational circuit doesn’t matter for certain input combinations. • Such combinations are called don’t-cares and the output is represented in the truth table and K-maps as `d’. • When using K-maps to minimize such functions: • Allow d’s to be included when grouping sets of 1’s to make the sets as large as possible. • Do not circle any set that only contains d’s.

  15. N3 N3’· N0 N3 N2 N2 · N0 00 01 11 10 N1 N0 12 8 0 4 00 01 11 10 d 13 5 9 1 d 1 1 N0 15 7 11 3 1 1 d d N1 14 2 10 6 1 d d N2’· N1 N2 Example with don’t-cares • Prime number detection for BCD numbers (takes value between 0-9) – minterms 10-15 are treated as don’t-cares: F(N3,N2,N1,N0) = SN3,N2,N1,N0 (1,2,3,5,7) + d(10,11,12,13,14,15) From K-map: Prime Implicants: N3’· N0 N2’· N1 N2 · N0 Distinguished 1-cells: Cell 1 covered by N3’· N0 Cell 2 covered by N2’· N1 Here not all prime implicants are essential prime implicants that must be included minimum SOP expression: F = N3’ · N0 + N2’ · N1

  16. W W WX WX 00 01 11 10 00 01 11 10 YZ YZ 12 28 8 24 0 16 20 4 00 01 11 10 00 01 11 10 29 13 5 21 25 9 1 17 Z Z 31 15 23 7 11 27 19 3 Y Y 30 14 18 2 26 10 22 6 V = 0 V = 1 X X 5-variable K-maps • The K-map for a 5-variable logic function is organized as two 4-variable K-maps: • Can be visualised as being one 4-variable map on top of another 4-variable map

  17. W W WX WX 00 01 11 10 00 01 11 10 YZ YZ 28 12 24 8 0 16 20 4 00 01 11 10 00 01 11 10 29 13 21 5 25 9 17 1 Z Z 31 15 7 23 11 27 19 3 Y Y 14 30 18 2 26 10 22 6 V = 0 V = 1 X X 5-variable K-map example • F(V,W,X,Y,Z) = SV,W,X,Y,Z(4,5,6,7,9,11,13,15,25,27,29,31) 1 1 1 1 1 1 1 1 1 1 1 1

  18. W W WX WX 00 01 11 10 00 01 11 10 YZ YZ 12 28 8 24 0 16 4 20 1 00 01 11 10 00 01 11 10 1 1 1 13 29 5 21 1 9 25 1 1 17 Z Z 1 31 15 23 7 1 1 1 1 27 11 19 3 Y Y 30 14 1 18 2 10 26 6 22 V = 0 V = 1 X X W · Z V’ · W’· X 5-variable K-map example – cont. Minimum SOP: F = V’ · W’· X + W · Z

  19. K-map product-of-sum minimization • Using K-map, find a minimal PoS expression for F(X,Y,Z) = PX,Y,Z (0,3,4,7) Truth Table X XY Row X Y Z F 0 0 0 0 0 1 0 0 1 1 2 0 1 0 1 3 0 1 1 0 4 1 0 0 0 5 1 0 1 1 6 1 1 0 1 7 1 1 1 0 00 01 11 10 Z 6 0 2 4 0 0 0 1 3 5 7 1 0 0 Z Y

  20. (Y + Z) X XY 00 01 11 10 Z 6 0 2 4 0 1 0 0 3 5 7 1 0 0 Z Y (Y’ + Z’) K-map PoS minimization – cont. Truth Table Row X Y Z F 0 0 0 0 0 1 0 0 1 1 2 0 1 0 1 3 0 1 1 0 4 1 0 0 0 5 1 0 1 1 6 1 1 0 1 7 1 1 1 0 Minimum PoS:F = (Y + Z) · (Y’ + Z’)

  21. W WX 00 01 11 10 YZ 12 8 0 4 0 0 00 01 11 10 13 5 9 1 0 0 Z 15 7 11 3 0 0 Y 14 2 10 6 0 0 X K-map PoS minimization – another example • Using K-map, find a minimal POS expression for • F(W,X,Y,Z) = PW,X,Y,Z (1,3,8,10,12,13,14,15)

  22. W WX 00 01 11 10 YZ (W’ + Z) 12 8 0 4 0 0 00 01 11 10 13 5 9 1 0 0 (W + X + Z’) Z 15 7 11 3 0 0 Y 14 2 10 6 0 0 (W’ + X’) X K-map PoS minimization – another example Minimum POS: F = (W + X + Z’) · (W’ + Z) · (W’ + X’)

  23. Timing Diagram propagation delay 1 X 0 X X’ 1  0 1 X’ 0 Transient output Steady-state output Time Combinational Circuit: Transient vs. Steady-state Output • Transient output: the temporary output due to the gate propagation delay(s) • Gate propagation delay: the time it takes to pull up (or down) the output signals due to the change at the input – depends on the transistor level implementation.

  24. Static-0 Hazard Static-1 Hazard 1 1 1 1 1 0 0 0 0 0 Dynamic Hazard Example Hazards in combinational circuits • Output glitch: a momentary (transient) fluctuation in output signal due to changes in input signal. • Static hazards: • Static-0 hazard: The output should be 0 but goes momentary to 1 as a result of an input change – possible in AND-OR circuits • Static-1 hazard: The output should be 1 but goes momentary to 0 as a result of an input change – possible in OR-AND circuits • Dynamic hazards:The output changes more than once as a result of a single input change (impossible in 2-level circuits).

  25. 1 X X · Z’ Z’ Z 0 ® 1 1 ® 0 X 1 Z XY F 0 Time 00 01 11 10 Z 1 ® 0 D 6 0 2 4 1 0 1 Z’ 0 1 Y Y · Z 3 5 7 1 Z 1 Y·Z 0 1 1 Y D X·Z’ 0 0 X · Z’ 1 1 Steady-state output D 1 1 F Y · Z Example: static-1 hazard • A static-1 hazard exists in the following AND-OR circuit when X=1, Y=1 and Z changes from 1 to 0 (assume all gates have propagation delay D) Extra propagation delay between Z and Z’ Circuit Timing Diagram 1 ® 0 ® 1 K-map

  26. X X·Y 00 01 11 10 Z 6 0 2 4 X 0 1 X · Z’ Z’ 3 5 7 1 Z Z X · Y F Y X·Z’ Y Y · Z 1 1 1 Y·Z 1 X·Y Eliminate static-1 hazard using K-map • Static-1 hazards are found using k-maps by finding adjacent 1 cells that are covered by different product terms. • To eliminate static-1 hazards, additional product terms (prime implicants) are needed to cover such cells thus covering the transition of the variable causing the hazard. • For the previous example the static-1 hazard is eliminated by including the additional product term X · Y New F = X · Z’ + Y · Z + X · Y

  27. Eliminate static-0 hazard using K-map • A static-0 hazard occurs in OR-AND circuits when an input variable and its complement are connected to two different OR gates. • The procedure to find and eliminate static-0 hazards using K-maps is done in a dual way to finding static-1 hazards. • Static-0 hazards are found using k-maps by finding adjacent 0 cells that are covered by different sum terms. • To eliminate static-0 hazards, additional sum terms (prime implicates) are needed to cover such cells thus covering the transition of the variable causing the hazard.

  28. Homework #2 • Turn in: (show your steps) • 4.13 (f), 4.14 (f) • 4.19 (e), 4.20 (e), 4.21 (e) • 4.22 (d) • 4.45 • 4.47 (refer to 4.46 for hints) • 4.55 (a) (b) (c) • 4.65 • 4.72 (f), 4.73 (f) • Self exercise: (you do not need to turn in these, but think about them!!) • 4.48, 4.50, 4.52, 4.68, 4.71, 4.84, 4.85
