Introduction to radiochemistry

Introduction to Radiochemistry

NUSC 341-3

Forces in matter and the subatomic particles

Forces in Matter and the Subatomic Particles

Chapter 1

What is nuclear science

What is Nuclear Science?

Nuclear science: study of structure, properties, and interactions of atomic nuclei at fundamental level.

nucleus – contains almost all mass of ordinary matter in a tiny volume

understanding behavior of nuclear matter under normal conditions

and conditions far from normal a major challenge

extreme conditions existed in the early universe, exist now in the core

of stars, and can be created in the laboratory during collisions

between nuclei (TRIUMF)

Nuclear scientists investigate by measuring the properties, shapes, and decays of nuclei at rest and in collisions.

This course covers low energy, or low temperature, nuclear science

=> properties of the nucleus

Why should we bother

Why should we bother?



  • Electromagnetic

    e- (lepton) bound in the atoms by the electromagnetic force

  • Weak interaction

    Neutrino observed in beta decay.

  • Strong interaction

    Quarks are bound in together by the strong force

    in nucleons. Nuclear forces bind nucleons into


  • Gravitation

    Gravitational interaction between the elementary particles

    is in practice very small compared to the other three.



The forces of elementary particle physics are associated with the exchange of particles.

An interaction between particles is characterized by both its strength and its range.

1 fm = 10-15 m

Force between two objects can be described as exchange of a particle – particle transfers

momentum and energy between the two objects, and is said to mediate the interaction

graviton – not yet observed

pions or pi mesons – between nucleons

Standard model

Standard Model

  • Attempts to explain all phenomena of particle physics in terms of properties and interactions of a small number of three distinct types.

  • Leptons: spin-1/2

  • Quarks: spin-1/2

  • Bosons: spin-1; force carriers

    These are assumed to be elementary.

Standard model1

Standard Model



Hadrons: any strongly interacting subatomic particle; composed of quarks.

There are 2 categories:

  • Baryons: fermions, make of 3 quarks

  • Mesons: bosons, made of quark, antiquark


Electron (e-) – Positron (e+)

Particles and antiparticles (such as the pair highlighted in pink) are created in pairs from the energy released by the collision of fast-moving particles with atoms in a bubble chamber. Since particles and antiparticles have opposite electrical charges, they curl in opposite directions in the magnetic field applied to the chamber.




Building blocks

Building Blocks

  • Molecules consists of atoms.

  • An atom consists of a nucleus, which carries almost all the mass of the atom and a positive charge Ze, surrounded by a cloud of Z electrons.

  • Nuclei consist of two types of fermions: protons and neutrons, called also nucleons.

  • Nucleons consists of three quarks.

e = 1.6022 x 10-19 C

Introduction to radiochemistry

1 Å = 10-10 m

1 fm = 10-15 m

Introduction to radiochemistry

3 quarks


mn = 1.6749 x 10-27 kg

= 939.55 MeV

= 1.008665 u

mp = 1.6726 x 10-27 kg

= 938.26 MeV

= 1.007276 u

Charge: 0

Charge: e

Introduction to radiochemistry

The Nucleus

The atomic nucleus consists of protons and neutrons

Protons and neutrons are generally called nucleons

  • A nucleus is characterized by:

  • A: Mass Number = number of nucleons

  • Z: Charge Number = number of protons

  • N: Neutron Number

Determines the Element

Determines the Isotope

Of course A=Z+N

Usual notation:

Mass number A


Element symbol – defined by charge numberC is Carbon and Z = 6

So this nucleus is made of 6 protons and 6 neutrons

Introduction to radiochemistry


  • Nuclear and atomic masses often given in

    u: atomic mass unit

  • 12.000 u = 12 daltons mass of a neutral 12C atom

  • 1 u = 1.6605 x 10-27 kg

  • Mass and energy are interchangeable –

    E = mc2

    where energy usually expressed in MeV

  • 1 MeV = 1.602 x 10-13 J

  • 1 u = 931.5 MeV/c2

Introduction to radiochemistry






Isotopes: same Z40Ca, 42Ca, 44Ca

often, ‘isotope’ used instead of ‘nuclide’

isotopes have same Z, so same number of electrons => same chemistry

use radioactive isotope in place of stable one – can monitor

decay for tracer studies

Isotones: same N40Ca, 42Ti, 44Cr

Isobars: same A42Ca, 42Ti, 42Cr

Isodiaphors: same neutron excess 42Ca, 46Ti, 50Cr

Classification of nuclides

Classification of Nuclides

  • Stable nuclei: 264; 16O

  • Primary natural radionuclides: 26; very long half-lives; 238U with t1/2 = 4.47 x 109 y

  • Secondary natural radionuclides: 38; 226Ra t1/2 = 1600 y decay of 238U

  • Induced natural radionuclides: 10; cosmic rays; 3H t1/2 = 12.3 y; 14N(n,t)12C

  • Artificial radionuclides: 2-4000, 60Co, 137Cs…

Periodic table

Periodic Table

Chart of nuclei

Chart of Nuclei

  • plot of nuclei as a function of Z and N

  • “Not just one box per element”

Chart of nuclides

Chart of Nuclides

Or segre chart

…or Segre Chart

  • plot allows various nuclear properties to be understood at a glance, similar

    to how chemical properties are understood from the periodic chart

  • ~ 2500 different nuclei known

  • 270 stable/non-radioactive

  • theorists guess at least 4000 more to be discovered at higher neutron numbers, higher mass

  • limits –

  • proton-rich side (left of stable): proton dripline cannot add another proton, it “drips” off dripline is known/accessible to experiments

  • neutron-rich side (right of stable): neutron dripline cannot add another neutron, it “drips” off dripline is unknown – neutron-rich nuclei difficult to produce/study

  • mass (above stable) – cannot add another proton or neutron limit unknown – again, difficult to produce/study

  • “island of stability” predicted near Z = 114; not yet observed

Introduction to radiochemistry

Natural Decay Chains

Thorium decay chain 4n 0

Thorium Decay Chain (4n + 0)

1.4 x 1010 y

Introduction to radiochemistry

(4n + 2)

4.5 x 109 y

The actinium decay series 4n 3

The Actinium Decay Series (4n +3)

  • 235U  … 207Pb (7 alphas and 4 betas)

    7.04 x 108 y

An extinct natural decay chain

An Extinct Natural Decay Chain

  • Neptunium decay series (4n + 1)

  • 237Np (t1/2 = 2.14 x 109 y ) …209Bi

End of chapter 1

End of Chapter 1

Any questions?
