Common Chemistry Lab Equipment

Common Chemistry Lab Equipment. Chemistry Lab Drawer. Well Plate Used for “small scale” reactions, where you are only using drops of solutions. Chemistry Lab Drawer. Scoopula Used for measuring small amounts of chemicals. Never stick these directly into a bottle of chemicals.

mirit
Download Presentation

Common Chemistry Lab Equipment

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript


  1. Common Chemistry Lab Equipment

  2. Chemistry Lab Drawer • Well Plate • Used for “small scale” reactions, where you are only using drops of solutions.

  3. Chemistry Lab Drawer • Scoopula • Used for measuring small amounts of chemicals. • Never stick these directly into a bottle of chemicals. • You can contaminate the entire bottle.

  4. Chemistry Lab Drawer • Lab Apron (Folded) • Goggles (top right)

  5. Chemistry Lab Drawer • Wash bottle. Use this for “rinsing” chemicals into your reaction vessel.

  6. Chemistry Lab Drawer • Test Tube Rack and Test Tubes • Test Tubes are another “primary” reaction vessel

  7. Chemistry Lab Drawer • Graduated Cylinder • Use these to accurately measure liquids in lab. Never use beakers to measure. • The answer on the SOL is always GRADUATED CYLINDER.

  8. Volumes. • We will work with liters (L) and milliliters (mL) in this class. • 1000 mL = 1L; 1000 L = 1 m3 • Cubic centimeters (cm3) and milliliters (mL) are different names for the same amount. 1 mL = 1 cm3. • 1 drop from a dropper is approximately 0.05 mL. So, 20 drops = 1 mL.

  9. Chemistry Lab Drawer • Test Tube Holder

  10. Chemistry Lab Drawer • Thermometers

  11. Chemistry Lab Drawer • Other stuff on FRONT SIDE • Stoppers (under goggles) • Hose clamp (under well plate) • Disposable pipet (right of grad cylinder) • Combustion spoon (looks like a soup ladle)

  12. Chemistry Lab Table • Tongs

  13. Chemistry Lab Drawer • Crucible and Lid • Used for STRONG Heating

  14. Chemistry Lab Drawer • Watch Glass

  15. Chemistry Lab Drawer • Evaporating Dish • Used for GENTLE heating or NO heating

  16. Chemistry Lab Drawer • Funnel • Used with filter paper.

  17. Chemistry Lab Drawer • Clay Triangle • Use this when heating crucibles.

  18. Chemistry Lab Drawer • Beakers

  19. Chemistry Lab Drawer • Erlenmeyer Flask • Used as a reaction “vessel” in lab. • Swirl

  20. Chemistry Lab Drawer • Ring Stand and Clamps • Ring Clamps and Utility Clamps

  21. Chemistry Lab Drawer • Wire Gauze • Use this for heating beakers or flasks.

  22. Chemistry Lab Drawer • Bunsen Burner

  23. Bunsen Burner Safety • 1. Never walk away from a lit burner. • 2. Never leave the gas turned on while the burner is NOT lit. • 3. Never leave a test tube in the flame while heating. • 4. Never point a test tube at someone else while heating.

  24. Chemistry Lab Drawer • Pipets and Pipet bulb • NEVER use your mouth to pipet.

  25. Chemistry Lab DrawerNot on Handout • Volumetric flasks

  26. Volumetric Flasks • Used for making very accurate concentrations of solutions. • Beakers/Flasks—accurate to about 5% (50,000 ppm) • Graduated cylinder—accurate to about 1% (10,000 ppm) • Volumetric Flasks—accurate about 0.04% (400 ppm)

  27. Chemistry Lab DrawerNot on Handout • Buret on ring stand • Used for titrations.

  28. Chemistry Lab DrawerNot on Handout • Stirring Rods

  29. Chemistry Lab DrawerNot on Handout • Mortar and Pestle. Used for grinding up solids or mixing solids.

  30. sschwartz@cityschools.com
