  1. Alcatel-Lucent WLAN Solution 소개

  2. OmniSwitch WLANPortfolio MPLS* MPLS* OmniStack6200 OmniSwitch 6855 OmniAccess WLAN OmniSwitch 6250 MPLS* OmniSwitch 9000 Series OmniSwitch 6850/E OmniSwitch 9000E Series OmniSwitch 10K Series OmniSwitch 6400 OmniAccess WAN OmniSwitch 6900 NAC Solution NMS Solution 기타 CyberGateKeeper Omnivista2500/3600 VitalQiP/VitalSuite

  3. OmniSwitch WLANSolution

  4. Packet Processor Encryption Processor Control Processor L2/L3 Switch Serial/ PoE Web 인증서버 DHCP 서버 Site Survey Radius Server PoE Switch Packet capture Firewall MobileIP Router VPN IPS SVP/SIP Alcatel-Lucent WLAN 특징 무선랜과 관련된 모든 기능을 하나의 장비에서 설정과 지원이 가능- 무선랜과 관련된 장애 발생시 관리 포인트를 최소화 할 수 있으며, 빠른 장애 조치가 가능

  5. Alcatel-Lucent WLAN의 구성 요소 무선랜 스위치(Controller) Access Point Optional components WiFi 관리 Adaptive Location Tracking, SSID 관리,Roaming 등 PoE Switch(Alcatel-Lucent OmniSwitch Series) WiFi 보안 WiFi IDS/IPS, Rogue AP Defense 802.11a or 802.11b/g(Single RF) 암호화 WEP, TKIP, AES, 3DES 인증과 사용자 무결성 체크(HIC) MAC, Captive Portal, 802.1x, VPN RADIUS Server 및 인증서버 802.11a and 802.11b/g(Dual RF) 권한 제어 User/Flow Stateful FW + Content Inspection re-direction 트래픽 관리 QoS/Priority/Bandwidth Contracts Data Center 네트워크 서비스 Routing, VLANS, NAT, DHCP, Switching 802.11a/b/g/n(2x2 MIMO, 3x3 MIMO) OmniVista 3600관리용 서버

  6. Alcatel-Lucent WLAN Architecture 인증 서버 및 PoE 스위치 • Access Points • Network Services • Alcatel Lucent MobilityController • End-to-end OmniVista Network Management

  7. Campus 802.11a/b/g/n Access Point • Single Radio(2.5GHz or 5GHz) • Dual Radio(2.5GHz & 5GHz) • High Density, Maximum Flexibility • Low Density or Air Monitor • OAW-92/93(H) • OAW-105(internal) • OAW-AP120/121 • OAW-AP124/125 • Campus Extension • OAW-AP68(internal Antenna) • 옥외용 802.11n Mesh • OAW-175(Harden Design) • Small Branches(Remote AP) • Home Office(Remote AP) • 최대 30명의 사용자 수용(802.an or 802.bgn) • 최대 5명의 사용자 수용(802.11b/g) • OAW-RAP2WG • OAW-RAP5/WN

  8. Campus 802.11a/b/g/n Access Point - Summary

  9. Mobility Controller(OmniAccess Wireless Switch, OAW) • Branch Office • OAW-4306GW • 16 APs, 64 RAPs • 802.11a/b/g/n Wi-Fi • USB-WAN, NAS/Print • 2Gbps Firewall • OAW-4306 • 8 APs, 32 RAPs • USB-WAN • 0.8Gbps Firewall • OAW-4306G • 16 APs, 64 RAPs • USB-WAN, NAS/Print • 2Gbps Firewall • Large Office • Campus • OAW-4704 • 128 APs • 512 RAPs • 4Gbps Firewall • OAW-6000 • 2048 APs • 4096 RAPs • 80Gbps Firewall • OAW-4604 • 64 APs • 256 RAPs • 4Gbps Firewall • OAW-4504 • 32 APs • 128 RAPs • 3Gbps Firewall

  10. Mobility Controller(OAW Switch) - Summary

  11. Centralized Configuration, Zero touch Deployment OmniVista 3600 중앙 집중적인 AP관리 기능 제공 - OmniVista 3600 WLAN Switch (Controller) 중앙 집중적인 보안 정책 정의 및 적용 Wired Infrastructure AP의 수동 설정 뿐만 아니라, 자동으로 AP를 discovery하여 구성할 수 있는 자동 AP 구성 기능 제공 Self Healing 기능을 사용한 Radio관리의 최적화 기능 제공 Access Points

  12. 자동 복구 및 격리 기능 AP 장애 시 자동 복구 기능 AP 장애 시 가장 인접한 AP로의 재연결을통하여 빠른 장애 복구 기능으로서비스를 유지함. (Self Healing 기능을 이용한 AP 커버리지 확장 기능) x Rogue AP의 자동 격리 기능 OmniVista Quarantine Manager Rogue 802.11n AP Rogue Detected Hacker Rogue 차단 802.11 attack dashboard OmniAccess Wireless Switch 정상적인 AP

  13. Cafeteria Lobby Conference Rooms Offices/Cubicles ARM 및 실시간 위치 추적 기능 ARM 기능 Channel#6 현재 인접하게 구성된 AP의 RF 상태를 파악하여 Channel 및 Power의 선택을 자동으로 구성 Channel#1 Channel#11 ARM Channel#1 Channel#11 실시간 위치 추적 기능 정확한 측정을 위해서는 최소 3개의 AP 소요 AP는 RF강도를 근간으로 거리 측정 RSSI Triangluation Algorithm 적용(오차범위 3m 이내)

  14. Virtual AP 및 Role 기반의 접근 제어 Virtual AP 기능 하나의 AP가 여러 개의 가상 AP로 동작하여,사용자 및 Role에 따른 별도의 SSID 제공 및보안 정책 기능 제공 역할 기반의 접근 제어 기법 사용자별 Role을 WLAN controller에 정의하고주어진 역할에 따른 접근제어(ACL) , 대역폭관리(QoS), VLAN할당 등정책 기반의 관리 기능 제공 IP/MAC/사용자 단위의 제어가 아니므로,미디어 타입에 무관한 안전한 이동성 제공

  15. 다양한 이중화 구성 방법 제공 WLAN Controller 이중화 제공 2가지의 이중화 방법 제공 – Active-Active , Active-Standby (선택적 구성 가능) Active-Active 구성 Active-Standby 구성 Master Local Master Backup DB Sync DB Sync Backbone S/W Backbone S/W PoE Switch PoE Switch Master와 Local 무선랜 스위치에서 동시에 서비스 제공 1대의 장비 장애 시, 백업 구성 가능 Master 스위치에서 모든 AP에 대한 서비스 제공 Master 장애 시, Backup 무선랜 스위치가 Master로 동작

  16. 단말기는 DHCP 서버로부터 초기 IP address 할당 10.1.1.1 3 2 2. 단말기는 새로운 subnet으로 이동하고, 다른 DHCP 요청 3. proxy DHCP를 사용하여 초기 할당받은 IP address를 요청 4 4. 단말기는 다른 subnet상에서 같은 IP address를 재 할당 받아 연속적인 통신 가능 VoWLAN 제공 – FMC 적용시 반드시 필요 완벽한 이동 성 보장 Subnet 2 IP - IP Tunnel DHCP Subnet 1 1 5. 스위치간 이동시 끊김없는 서비스 제공(2~3ms) 10.1.1.1 AP VoWLAN 제공 802.11e 제공 – WMM(Wireless Multimedia Management), APSD(Auto Power Save Delivery)

  17. 사용자 요구에 따른 다양한 License 제공 사용자 요구에 부합하는 다양한 License

  18. 안정성 기반의 고성능 RF 관리/제어 기능

  19. 접근 제어 및 무선 보안

  20. Centralized / Cost Effective WLAN 관리

  21. Platform and OverAll WLAN Scalibilty

  22. Q&A 5
