  1. di. mayer hans - oe1smc

  2. B I T T E F L Ü S T E R N di. mayer hans - oe1smc

  3. W H I S P E R 'hwis-pər di. mayer hans - oe1smc

  4. W S P R 'hwis-pər di. mayer hans - oe1smc

  5. di. mayer hans - oe1smc WSPR – was ist es • Ein standalone Programm WSPR • Aktuelle Version 2.0_r1714 (11/2009) • Teil von WSJT ( Mode WSPR ) • Ab Version 7 • Ein Protokoll - Open Source

  6. Weak Signal Propagation Reporter WSPR – wofür steht es di. mayer hans - oe1smc

  7. di. mayer hans - oe1smc WSJT 7 Interaktiv Vorgefertigter Dialog Minimal-QSO WSPR – was kann es WSPR • Beacon mode • Autom. Empfangen und Senden • Upload von Empfangsdaten in eine Datenbank

  8. Joseph H. Taylor Geb. 24. März 1941 Philadelphia Professor an der Universität Princeton Nobelpreis für Physik 1993 Der Autor K1JT di. mayer hans - oe1smc

  9. Einstellung der Sendeleistung in dBm Zum Umrechnen: http://hans.mayer.tv/html/dbmwattcalc.html Setup di. mayer hans - oe1smc

  10. di. mayer hans - oe1smc

  11. Farbkodierung der Calls di. mayer hans - oe1smc

  12. QRGs (USB dial): 1.8366, 3.5926, 7.0386, 10.1387, 14.0956, 18.1046, 21.0946, 24.9246, 28.1246, 50.293 Frequenzen di. mayer hans - oe1smc

  13. Bandbreite u. Modulation di. mayer hans - oe1smc

  14. additive white Gaussian noise (AWGN) bezogen auf 2500 Hz Bandbreite Sensitivity ( Empfindlichkeit ) di. mayer hans - oe1smc

  15. di. mayer hans - oe1smc Zentrale Datenbank im Internet http://wsprnet.org/ • Graphische Aufbereitung ( Propagation Map ) • Abfrage der Daten ( Spot Database ) • Chat • Forum • Infos, Statistiken

  16. Propagation Map di. mayer hans - oe1smc

  17. Spot Database • Timestamp Call MHzSNR Drift Grid Pwr Rptr Rgrid km az • 2009-10-19 19:16 F6BIA 10.140238 -22 -1 JN18dq 2 OE1SMC JN88dd 1034 88 • 2009-10-19 19:32 K1JT 10.140264 -9 0 FN20qi 5 OE1SMC JN88dd 6860 49 • 2009-10-19 19:14 OE1SMC 10.140194 -23 0 JN88dd 2 W3CSW FM19kd 7109 300 • 2009-10-19 19:14 OE1SMC 10.140203 -23 0 JN88dd 2 F6BIA JN18dq 1034 279 • 2009-10-19 19:10 ZL2TLD 10.140227 -23 0 RE79tb 5 OE1SMC JN88dd 18199 303 • 2009-10-19 19:04 OE1SMC 10.140190 -21 0 JN88dd 2 K1JT FN20 6878 300 • 2009-10-19 19:02 OE1SMC 10.140193 -13 0 JN88dd 2 OY3JE IP62oa 2108 326 • 2009-10-19 19:02 OE1SMC 10.140203 -3 0 JN88dd 2 HB9TMW JN36gq 751 261 • 2009-10-19 19:02 OE1SMC 10.140201 -13 0 JN88dd 2 GD4KIN IO74sd 1586 303 • 2009-10-19 19:02 OE1SMC 10.140199 -15 0 JN88dd 2 KL1X BP51ip 7739 353 • 2009-10-19 19:02 OE1SMC 10.140208 -6 0 JN88dd 2 GW4HDR IO83gh 1498 300 • 2009-10-19 18:58 IK1JNS 10.140209 -21 0 JN35sb 2 OE1SMC JN88dd 751 60 • 2009-10-19 18:58 HB9TMW 10.140276 -6 1 JN36gq 5 OE1SMC JN88dd 751 74 di. mayer hans - oe1smc

  18. Less power, more fun di. mayer hans - oe1smc

  19. Spot Database Timestamp Call Mhz SNR Drift Grid Pwr Reporter Rgrid km az 2009-07-02 07:14 DH8SA 10.140156 -7 -1 JO63bt 10 OE1SMC JN88dd 694 154 2009-07-02 07:12 IQ4DJ 10.140189 -5 0 JN54ks 1 OE1SMC JN88dd 559 46 2009-07-02 07:12 F6BIA 10.140243 -15 0 JN18dq 2 OE1SMC JN88dd 1034 88 2009-07-02 07:08 M0GNM 10.140119 -6 0 IO91wi 5 OE1SMC JN88dd 1229 100 2009-07-02 07:08 M0DUO 10.140175 -12 0 IO91kw 0.5 OE1SMC JN88dd 1309 102 2009-07-02 07:08 IQ4DJ 10.140189 -15 0 JN54ks 1 OE1SMC JN88dd 559 46 2009-07-02 07:02 DH8SA 10.140156 -7 -1 JO63bt 10 OE1SMC JN88dd 694 154 2009-07-02 07:02 IQ4DJ 10.140189 -21 0 JN54ks 1 OE1SMC JN88dd 559 46 2009-07-02 07:02 F6BIA 10.140243 -13 0 JN18dq 2 OE1SMC JN88dd 1034 88 2009-07-02 07:00 M0DUO 10.140176 -11 -1 IO91kw 0.5 OE1SMC JN88dd 1309 102 2009-07-02 06:58 OE1SMC 10.140171 -20 0 JN88dd 0.02 DL2YED JO31op 757 304 2009-07-02 06:58 OE1SMC 10.140166 -25 0 JN88dd 0.02 G8SQH IO81 1431 292 2009-07-02 06:58 OE1SMC 10.140176 -27 0 JN88dd 0.02 CT1EKD IM59ib 2280 253 di. mayer hans - oe1smc

  20. Datensätze pro Monat di. mayer hans - oe1smc

  21. OE1DMB OE1GQA OE1IFM OE1LIC OE1MCU OE1MSB OE1RWU OE1SMC OE1VZ OE3AOU OE3BGA OE3CJB OE3CPU OE3DJB OE3DXA OE3FLB OE3FVU OE3GHB OE3GSA OE3KLU OE3REC OE3RFA OE3RWU OE3WGW OE3WHU OE3WMA OE4KHB OE5JKL OE5MPL OE5PSM OE5WEL OE6KLU OE6KYG OE6LUG OE7CMI OE7GJ OESWL OE-Rufzeichen di. mayer hans - oe1smc

  22. Analyse der Ausbreitungsbedingungen Erfahrungen mit kleinster Leistung für SWL oder Newcomer gut geeignet Vergleich der Antennenanlage mit anderen Überprüfung Stabilität des TX, u.v.m. WSPR – was bringt es di. mayer hans - oe1smc

  23. http://wsprnet.org/ http://www.physics.princeton.edu/pulsar/K1JT/wspr.html http://hans.mayer.tv/ http://wiki.oevsv.at/index.php/MEPT_-_a_WSPR_beacon http://www.oe1ifm.at/ Internet-Links di. mayer hans - oe1smc

  24. Danke di. mayer hans - oe1smc
