Presentation Transcript


Windows phone 7 development l.jpg

Windows Phone 7Development

Tomer Shamam

Senior Architect

Sela Group


Agenda windows phone 7 l.jpg

Agenda: Windows Phone 7

  • General Concept

    • Metro

  • Software Architecture

    • Silverlight Capabilities

  • Application Model

    • Activation and Navigation

    • Application Lifecycle

  • User Interface

    • Application Bar and System Tray, Panorama, Pivot

  • Integration Services

    • Launchers and Choosers, Tiles and Push Notifications, Location and Services

Cloud and Integration Services

App Model

UI Model

Software Architecture

Hardware Foundation


General concept l.jpg

Cloud and Integration Services

General Concept

App Model

UI Model

Software Architecture

Hardware Foundation


New concept l.jpg

New Concept

DESIGN: END USER COMES FIRST

PLATFORM: RICHER, DEEPER, EASIER APPS

HARDWARE:

FASTER TO MARKET, LESS HEAVY LIFTING


Life maximizers l.jpg

Life Maximizers

WHO ARE LIFE MAXIMIZERS?

WHAT’S IMPORTANT TO THEM?

  • Busy personally and professionally

  • Living a rich, active life

  • Settled rather than seeking

  • Juggling priorities

  • Value technology as a means to achieve goals

  • Not feeling overwhelmed

  • Balanced priorities

  • Growing personally and professionally

  • Living life to the fullest


Metro ui l.jpg

Metro UI


Hardware foundation in 7 0 l.jpg

Hardware Foundation (in 7.0)

Capacitive touch

4 or more contact points

800

Sensors

A-GPS, Accelerometer, Compass, Light, Proximity,

Camera

5 mega pixels or more

Multimedia

Common detailed specs, Codec acceleration

Memory

256MB RAM or more, 8GB Flash or more

GPU

DirectX 9 acceleration

CPU

Qualcomm MSM8x55 800Mhz or higher

Hardware buttons | Back, Start, Search

480


Two flavors of applications l.jpg

Two Flavors of Applications

  • Modern XAML/event-driven application UI framework

  • Rapid creation of visually stunning apps

  • Metro-themed UI controls

  • HTML/JavaScript

  • 500,000 developers spanning Windows and web

  • High performance game framework

  • Rapid creation of multi-screen 2D and 3D games

  • Rich content pipeline

  • Mature, robust, widely adopted technology spanning Xbox 360, Windows, and Zune


Windows phone developer tools l.jpg

Windows Phone Developer Tools

Tools

Phone Emulator

Windows Phone

Emulator

Samples

Documentation

Packaging & Verification Tools

Guides

Community

Windows Phone device

Packaging and Verification Tools

myapp.xap


Deployment process l.jpg

Deployment Process

Develop

& Debug

Submit& Validate

Certify

& Sign

Windows Phone Application Deployment Service

Marketplace


Software architecture l.jpg

Cloud and Integration Services

Software Architecture

App Model

UI Model

Software Architecture

Hardware Foundation


Silverlight capabilities l.jpg

Silverlight Capabilities

  • Inputs

    • Keyboard, Mouse, Touch, Ink

  • XAML UI Core

    • Common Controls, Text, Images, Data Binding, Page Navigation, Vector Graphics, Animation, Transformation, Styles and Templates

  • Media

    • Capture and Playback, VC1, WMA, MP3

  • Data

    • LINQ to Objects, LINQ to XML, Isolated Storage, XML

  • Base Class Library

    • Generics, Collections, Cryptography, Threading

  • Communication

    • REST, RSS/ATOM, SOAP


Multitouch l.jpg

Multitouch

  • OOB Controls support touch

    • Translate touch events to mouse events

    • ScrollViewer has built-in support for pan and flick

  • Manipulation for all UIElements

    • Scale

    • Translate

  • Raw Touch, compatible with SL3


Keyboard l.jpg

Keyboard

  • Silverlight TextBox integrates with the SIP (on screen keyboard)

    • Password has a delay

  • SIP supports input scoping

    • Key InputScopes: Text, Url, Number, Time, TelephoneNumber, EmailNameOrAddress


Media l.jpg

Media

  • Media support

    • H/W decode

    • MediaStreamSource

    • PlayReady DRM

  • MediaElement Limitations

    • One MediaElement only

  • XNA sound effect API

    • Supports polyphonic, looping wav data


Isolated storage l.jpg

Isolated Storage

  • Compatible APIs with Silverlight on desktop

    • No quota limits

    • Not shared

  • No write access to Media Library, use XNA for that

  • Use for your application settings


Software architecture demo l.jpg

Software Architecture demo


Application model l.jpg

Cloud and Integration Services

ApplicationModel

App Model

UI Model

Software Architecture

Hardware Foundation


Activation and navigation l.jpg

Activation and Navigation

  • Activation Events

    • Handled by the Application instance

    • Launching, Activated, Deactivated and Closing

  • Navigation Events

    • Handled by each PhoneApplicationPage class

    • OnNavigatedTo, OnNavigatedFrom, OnBackKeyPressed, OnChooserReturn, OnOrientationChanged

  • Controlled by

    • Hardware using Back and Home keys

    • Software using Navigation Service


Application lifecycle l.jpg

Application Lifecycle

Save State!

Load State!

  • Phone removed from memory

  • Some state saved to storage


Application model demo l.jpg

Application Modeldemo


Ui model l.jpg

Cloud and Integration Services

UIModel

App Model

UI Model

Software Architecture

Hardware Foundation


Application bar and system tray l.jpg

Application Bar and System Tray

  • System Tray

    • No integration, but does affect Layout

    • Show:Hide using SystemTray.IsVisible

  • Application Bar

    • Up to 4 Buttons

    • Menu Items (Recommended 6)

    • Toggle Visibility

    • <mypage>.ApplicationBar.IsVisible


Panorama l.jpg

Panorama

  • Part of the native Windows Phone look and feel

  • Panorama is a long horizontal canvas

  • PanoramaItemserves as a container that hosts other content and controls


Pivot l.jpg

Pivot

  • Provides a quick way to manage views or pages

  • Pivot is a container of pivot items

  • PivotItem contain individual page content such as controls, grids, or links


Many more l.jpg

Many more…

  • Standard Controls

    • Buttons, Image, Layout, ListBox, TextBox, Slider, Other…

  • Bing Maps

    • Bing Map Control, Integration with Bing Maps Services

  • Deep Zoom

    • Included in core run-time , Optimized to take advantage of GPU, Consumes same content as SL on desktop, Supported for Online content

  • Web Browser

    • Displays network and local content, Supports pan, double tap and pinch to zoom, Supports transforms & projections, Application can interact with javascript


Ui model demo l.jpg

UI Modeldemo


Integration services l.jpg

Cloud and Integration Services

IntegrationServices

App Model

UI Model

Software Architecture

Hardware Foundation


Launchers choosers l.jpg

Launchers & Choosers

  • Enable applications to provide a set of common phone tasks to their users

  • Launchers let you fire and forget

    • SMS, Email, Web Browser, Dialer, Search, etc.

  • Choosers let you fire and pick the results back

    • Picture, Camera, Contact, etc.


Push notifications l.jpg

Push Notifications


Types of push notifications l.jpg

Types of Push Notifications

  • Tile notifications

    • Update tile count, title and background image

  • Toast notifications

    • Display a on-top-like message

  • Raw notifications

    • Can be used in application logic


Location and services l.jpg

Location and Services

  • The service obtains location data from multiple sources such as GPS, Wi-Fi, and cellular

  • Applications can access location information

  • Allows you to create location-aware applications


Integration services demo l.jpg

Integration Servicesdemo


Register your device l.jpg

Register Your Device

Test on a physical device

Register your device

Install, run, and debug unsigned applications

Use Zune to register your device


Questions l.jpg

Questions?
