Presentation Transcript

1. www.SageLogix.Com

2. Agenda Overview of tuning tools in Oracle Tuning SQL SQL Trace TKPROF Oracle Trace Analyzer Hotsos Profiler ( UB Tools Analyzer ( Tuning PL/SQL DBMS_PROFILER

3. Overview of performance tuning In order to improve anything, you have to measure it Is it processing? If so, what exactly is it doing? Is it waiting on something? If so, what exactly is it waiting for? Performance tuning is not an art, but a science The right tool for the job is the key

4. Understanding where time is spent

5. Measuring time Tracing Tracing is the recording of actions performed by a program, as they are performed Oracle SQL tracing Event 10046 alter session set events ‘10046 trace name context forever, level 8’ exec dbms_support.start_trace New book “Optimizing Oracle Performance” by Cary Millsap and Jeff Holt (O’Reilly & Associates, Sep 2003) ISBN #059600527X

6. Summarizing trace data Recording every action performed by a program generates huge volumes of data to analyze Forest and trees Look at the trees for diagnosing failures Look at the forest to tune performance Application profiling “C” programs: UNIX “prof” Java programs: EJP on Commercial products from profilers for Java, C#, C++, C, COBOL, other languages TKPROF for SQL trace data Profiling is the summarization of trace data

7. Profiling Using the UNIX “prof” utility as an example: Compile a “C” program using the “-p” option to the “cc” compiler command When compiled/linked program is executed, trace information is output to a file specified by $PROFDIR environment variable (default is “./mon.out”) UNIX “prof” utility then reads trace information and produces a summarized “profile report” which summarizes: Number of calls to functions Amount of time spent in each function

8. Profiling SQL Trace is another example SQL trace is enabled on a session All SQL statements executed in that session dump trace information to a “.trc” file in USER_DUMP_DEST TKPROF program simply reads information in the “.trc” file and summarizes it, displaying: Execution counts CPU and elapsed times Number of physical, logical I/O Number of rows fetched

9. What if the problem is not SQL? SQL statements perform work in the database Summarizing SQL trace info is the best tool for tuning SQL What if the performance problem was in: The network? Operating system? DB instance? Database wait events can help An application program, such as: Java, C#, C++, C, COBOL, Fortran, Lisp? PL/SQL?

10. DBMS_PROFILER Introduced with Oracle8i Not installed with typical installation Some files in “$ORACLE_HOME/rdbms/admin” Documented in MetaLink note #243755.1 Download “” from MetaLink “Oracle PL/SQL Supplied Packages” reference on “DBMS_PROFILER” Generates trace data in PL/SQL programs Trace data saved to tables in database SQL*Plus script produces summarized “profile report” as HTML

11. DBMS_PROFILER Files found in “$ORACLE_HOME/rdbms/admin” SQL*Plus script “profload.sql” creates the package DBMS_PROFILER Run once for global setup on database Must be performed by SYS user Also validates package after creation SQL*Plus script “proftab.sql” creates tables to store trace data Create private sets of tables for each user Each user has the three tables and single sequence Create a “global set” of tables for all users DBA is responsible for granting appropriate permissions and creating synonyms for the three tables and the single sequence

12. DBMS_PROFILER Important extra files provided in “” SQL*Plus script “profiler.sql” Queries data generated by runs of the DBMS_PROFILER package Generates HTML profiler report as output SQL*Plus script “profgsrc.sql” Extracts the source of a stored package, procedure, or function to an ASCII text file for editing So that DBMS_PROFILER procedures can be added to that source code…

13. Using DBMS_PROFILER Initial setup: DBMS_PROFILER package has been created by the DBA using “profload.sql”… developer/user has created the tables using “proftab.sql” Add profiler procedures to PL/SQL source Procedure START_PROFILER(‘run-comment’) Procedure STOP_PROFILER Recompile and run the procedure

14. Using DBMS_PROFILER After running an instrumented PL/SQL program: Execute the SQL*Plus script “profiler.sql” It will display each session’s RUN-ID, a timestamp, and the RUN-COMMENT Choose the appropriate RUN-ID Produces spooled output to a file named “profiler_<RUNID>.html”

15. Case Study #1 A PL/SQL procedure named PROFTEST1 It queries data from a table Stores the data in a comma-separated string Then, repeatedly parses and displays each item in the string There are (at least) two ways to call the INSTR() function: instr(string, ‘,’, 1, n) instr(string, ‘,’, x, 1) Which is faster??? Is there a difference?

16. Case Study #1 Files: proftest1.sql DDL to create stored procedure and table Including use of DBMS_PROFILER run_proftest1.sql SQL*Plus script to run the test proftest1.tkp Output from tkprof <trc-file> <tkp-file> sort=prsela,exeela,fchela explain=<un>/<pwd> proftest1_18.html proftest1_19.html

17. Case Study #1 No real surprise when you think about it But using “instr(string, pattern, m, n)” is faster But THAT MUCH FASTER???

18. Case Study #2 Script to estimate the number of rows per block Originally written for Oracle v6 Adapted to Oracle7 without modification New ROWID formats in v8+ forced changes to the script Started using DBMS_ROWID package in query Extremely slow

19. Case Study #2 DBMS_PROFILER does not affect PL/SQL modules called within SQL statements Unless they are instrumented themselves with START/STOP_PROFILER The resolution of replacing DBMS_ROWID package calls with SUBSTR was easily determined using SQL Trace and TKPROF But DBMS_PROFILER provided some corroboration, at least… :-)

20. Quick Tip #Q10 Q & A Slides and scripts will be posted on and Email: [email protected]
