  1. School of Computer and Information Science Southwest Forestry University 2012.9 Introduction to Computer Programming

  2. Chapter 3 Conditional Statements Danju Lv Autumn semester , 2012

  3. Chap3 Conditional Statements • In this chapter: • Definition of Conditional Statements • Logical judgment and conditional expression • if statement • else statement • elif statement • Mix of conditionals • 条件语句的定义 • 逻辑判断与条件表达式 • 单分支语句 • 双分支语句 • 多分支语句 • 条件嵌套语句

  4. Def. of Conditional Statements This chapter describes a type of control statements in Python , conditional statement. Based on the value of the conditional expression ,True(non-zero ) or False (zero), the conditionals make decisions to control the execution of block of code. 条件语句是根据条件表达式的值是True/非零还是False/零做出决策,控制代码块的执行。

  5. Chap3 conditional statements 条件语句是根据条件表达式的值是True/not zero还是False/zero做出决策,控制执行的代码块。 由表达式的值控制执行的代码块 • 4 key points • Expression • Value of the Expression • Control • Block of Code/suit • 4个要点: • 表达式 • 值 • 控制 • 代码块

  6. 1. Expression • Def. of Expression: • A typical expression is generally composed of: operator and operand (object) • Common operators in conditional expressions • Math:+,-,*,/,// , %,  **,~, • Comparison: >, <, ==, != , <=, >= • Test:in , not in ,is , is not • Conjunction:and, or, not

  7. 1. Math Expressions: 3+2 7%3 3**2 2. Comparison Expressions: 3<6 2<>7 “abc”==“bcd” a=[1,2,3];b=[1,2,3]; a!=b 3. Test Expressions: a=[1,3,5]; 3 in a ; 5 not in a a=“abcdef”; b=a; a is b; a is not b Exp. of expresstion

  8. Conj. Operaters:and or not。 and 和 表示左边的运算、值或者对象为True,接着对右边求值。如果左边为False/zero,就停止运算并且输出结果False,不再继续运算。 or 或 表示对左边表达式求值,如果结果为False, 则继续对右边的表达式求值,得最后结果。如果左边表达式结果为True/not zero,则停止其后表达式求值,且最终结果为True。 not 非单目运算符 在需要在表达相反条件时,用not运算符。 Conjunction Operation 短路特性 Short circuit 运算特点:见False为False False at first False 运算特点:见True为True True at first True

  9. Tell the values of the following expressions: 判断下列逻辑表示式的值 Expr. :2 or 0, 2 and 0, 3 or 2, 3 and 2, not 2, not 0 Exp. of expression values:2, 0, 3, 2, False, True 逻辑运算表达式其值并非得到布尔型的结果

  10. Conjunction in cond. expression • When a judgment need to consider two or more of the conditions / factors, we should correctly use conj. operators to combine those conditionals . • 当做一个判断时需考虑两个或两个以上的条件/因素时,此时需要对条件进行合理的逻辑组合运算。

  11. 1. 成绩score在90~100之间? Exp. Of Conj. Expression逻辑组合表示举例 score>=90 and score<=100 2. 年龄age在25岁~30岁之间且专业subject是计算机或是电子信息工程专业? (age>=25 and age<=30 ) and (subject=="计算机" or subject=="电子信息工程专业”) 注意:表示两者关系相等用“==”, 而非“=”,初学者极易出错

  12. 1. 运算符的优先级 在一个表达式中出现多种运算符时,按照运算符的优先级高低依次进行运算。 注:表达式出现()时,运算级别是最高的,“=”级别最低 Mix of operation混合运算

  13. Mix of operation混合运算 2. 结合规律 通常,相同级别运算符按照从左到右顺序计算 注:=赋值运算是从右到左的结合。 a=b=c  a=(b=c)

  14. Core: Any value is an expression! 核心:有值便是表达式! 如:2, “abc” 在python中对于所有对象都做了True, False的映射 可用bool函数来决定任何对象、表达式的布尔值 Values of the expressions表达式的值

  15. 表达式的值若视为Boolean型,则表达式的值就只可能是True or False 在控制语句中表达式(条件表达式)的值就是视为Boolean型——逻辑判断 Values of expr. in control statements控制语句中表达式的值 由表达式的值控制执行的代码块

  16. The basis of the control: logic judgment 逻辑判断:体现了一种思维能力。 计算机有没有这种思维能力呢? 常用逻辑判断的类型 两个对象之间的关系(==,!=,<,>,>=,<=) 注: !=还可表示成:<> 成员测试 (in ,not in) 同一性测试(is,not is) 逻辑关系(not, and , or):常用于组合表达式中 3.control: logical judgment控制:逻辑判断

  17. if 条件语句:the syntax of if statement: if 表达式: ture语句块 False 表达式 True ture语句块 图3-1 单分支语句的执行方式 3. control:conditional statements选择控制 • if statement ifexpression: expr_true_suite 单分支语句,菱形框表示if,表达式放在框内,紧接菱形框的矩形框表示冒号后的true语句块。

  18. False 表达式 True true语句块 if 单分支语句 ifexpression: expr_true_suite The suite of the if clause, expr_true_suite, will be executed only if the above conditional expression results in a Boolean true value. Otherwise, execution resumes at the next statement following the suite. If 语句:若表达式为真/非零则执行冒号后的语句块,若表达式为假则跳过该语句块的执行。

  19. 试将以下程序用框图表示,并说明程序运行的结果试将以下程序用框图表示,并说明程序运行的结果 if 简单分支的执行情况分析 n = 1 x = 5 if x>0 : n = n+1 n=1 x=5 n=1 x=-5 False x>0 True n = 1 x = -5 if x>0 : n = n+1 n=n+1

  20. Indentation Python语言利用缩进表示语句块的开始和退出(Off-side规则),而非使用花括号或者某种关键字。 增加缩进表示语句块的开始(回车后自动完成/tab键) 减少缩进则表示语句块退出(backspace键) Indentation in ctrl. Statement of python控制程序中的缩进量

  21. 3-1两数大小比较,按从小到大的顺序输出。 简单分支举例 开始 a=3 b=5 if a>b: t=a a=b b=t print ("从小到大输出:") print (a, b) 程序运行结果: 从小到大输出: 3 5 初始化a、b False a>b True ? 交换a、b的值 输出a、b 结束 图3-2 按升序输出两个数

  22. 【例3-2】从键盘输入圆的半径,如果半径大于等于零则计算圆面积。【例3-2】从键盘输入圆的半径,如果半径大于等于零则计算圆面积。 开始 输入半径 False 半径不小于0 True 计算圆面积 输出圆面积 结束 简单分支举例 import math r=eval(input(“请输入圆的半径:”)) if r>=.0: s=math.pi*r**2 print("s=pi*r*r=",s) 结果验证: 请输入圆的半径:4 s=pi*r*r= 50.26548245743669

  23. 当输入r 为-2时,结果如何? 程序的输出可以改进吗? 如当输入r 为负值时,给出一个提示输入出错的信息,当输入r 为非负值时,计算其圆面积。 思考

  24. Syntax of else statement: if 表达式 : Ture语句块 else : False语句块 The else statement identifies a block of code(expre false suite) to be executed if the conditional expression of the if statement resolves to a false Boolean value. 表达式 False True Ture语句块 False语句块 图3-4 双分支语句的执行方式 双分支语句 else statement ifexpression: expr_true_suite else: expr_false_suite

  25. 图3-4表示了双分支语句,菱形框表示if,表达式放在框内,左边的矩形表示“if表达式”冒号后的“True语句块”,右边的矩形表示“else”冒号后的“False语句块”,若表达式为真则执行Ture语句块,若表达式为假则执行False语句块。图3-4表示了双分支语句,菱形框表示if,表达式放在框内,左边的矩形表示“if表达式”冒号后的“True语句块”,右边的矩形表示“else”冒号后的“False语句块”,若表达式为真则执行Ture语句块,若表达式为假则执行False语句块。 表达式 False True Ture语句块 False语句块 双分支选择 else statement ifexpression: expr_true_suite else: expr_false_suite

  26. 请画出以下程序的框图结构,该程序的执行路线如何,结果是?若程序的x=2替换为x=-2,程序的执行路线又如何,结果?请画出以下程序的框图结构,该程序的执行路线如何,结果是?若程序的x=2替换为x=-2,程序的执行路线又如何,结果? x>0 False True y=1+2*x y=0 双分支程序的理解 X=2 x = 2 if x > 0: y = 1+2*x else: y = 0 print('y=', y) print(‘y=’,y)
