Projectiles

Projectiles. 2-D Motion. Now we have movement in both x & y dirs. Gravity acts down v y changes No force horizontally v x is constant. Steps. Separate everything into x & y columns only time can pass between the columns a = -9.8 m/s 2 in y -direction

marlo
Download Presentation

Projectiles

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Projectiles

  2. 2-D Motion • Now we have movement in both x & y dirs. • Gravity acts down • vy changes • No force horizontally • vx is constant

  3. Steps • Separate everything into x & y columns • only time can pass between the columns • a = -9.8 m/s2 in y-direction • Write all givens in correct columns • separate vo into vox and voy • Write equations • 3 Amigos in the y-direction • v=Δs/t in the x-direction • Solve

  4. A cannon is fired with vo = 40 m/s at a 30° upward angle. How far away does it land? vo θ ____x____ ___y___

  5. A cannon is fired with vo = 40 m/s at a 30° upward angle. How far away does it land? vo θ ____x____ ___y___

  6. Tips • Horizontal projectiles have θ = 0° • At the peak, vy = 0 • If it starts and ends at the same level: • vfy = -voy • Δy = 0 • at the peak t = ½ the total travel time • vox = vfx = vx everywhere
