6 Different Components of Bentley Transmission Found in Mission Viejo

Transmission is an important component of the Bentley, so you have to understand the different parts of the transmission and the way it works. For the smooth functioning of the transmission, the valve body is receiving a signal from the TCM to move in first gear. Several components are handling all the functions of the automatic transmission in Bentley. The following slides define all the components of the transmission in your Bentley.

markdouglasmotorwork
Download Presentation

6 Different Components of Bentley Transmission Found in Mission Viejo

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. 6 DIFFERENT COMPONENTS OF BENTLEY TRANSMISSION FOUND IN MISSION VIEJO

  2. APART FROM THE ENGINE, THE TRANSMISSION IS ALSO AN IMPORTANT PART OF THE BENTLEY.

  3. BEFORE DRIVING THE CAR, YOU HAVE TO UNDERSTAND THE DIFFERENT COMPONENTS OF THE TRANSMISSION.

  4. FOR THE SMOOTH FUNCTIONING OF THE TRANSMISSION, THE VALVE BODY RECEIVES A SIGNAL FROM THE TCM TO MOVE IN FIRST GEAR.

  5. IN GENERAL, NUMEROUS COMPONENTS ARE HANDLING ALL THE AUTOMATIC TRANSMISSION IN BENTLEY.

  6. THE FOLLOWING POINTS DEFINE ALL THE COMPONENTS OF THE BENTLEY TRANSMISSION MORE BRIEFLY.

  7. PLANETARY GEAR SETS

  8. THUS, THE AUTOMATIC TRANSMISSION OF THE BENTLEY HAS ONE OR MORE PLANETARY GEAR SETS.

  9. ALL THE GEAR SETS IN YOUR BENTLEY ALLOW THE TRANSMISSION TO USE THE DIFFERENT TYPES OF GEAR OPTIONS WITHOUT ANY SETUP.

  10. VALVE BODY

  11. AUTOMATIC TRANSMISSION OF YOUR CAR HAS A VALVE BODY FOR TRANSFERRING THE PRESSURE FROM THE OIL PUMP TO THE TRANSMISSION PARTS.

  12. VALVE BODY IS CONTROLLED BY THE SENSOR AND THE FLUIDS ARE DIRECTLY CONNECTED WITH THE TCM.

  13. TORQUE CONVERTER

  14. LIKE THE CLUTCH IN MANUAL TRANSMISSION, THE AUTOMATIC TRANSMISSION CARS HAVE A TORQUE CONVERTER.

  15. TORQUE CONVERTER IS ALLOWING THE ENGINE TO RUN EVEN IT IS DISCONNECTED FROM THE TRANSMISSION.

  16. OUTPUT SHAFT

  17. INTERNAL TRANSMISSION IS DELIVERING THE ESSENTIAL POWER TO THE DRIVESHAFT FOR SUPPLYING THE POWER TO THE HUBS.

  18. THUS, THE OUTPUT SHAFT OF THE TRANSMISSION DRIVES THE DRIVE SHAFT OF YOUR ENGINE.

  19. OIL PAN

  20. LIKE THE ENGINE, THE TRANSMISSION ALSO HAS AN OIL PAN ON THE BOTTOM OF YOUR BENTLEY.

  21. GENERALLY, IT IS HOLDING THE EXCESS TRANSMISSION FLUID FOR THE OIL PUMP TO PULL THEM FOR THE TRANSMISSION.

  22. OIL PUMP

  23. OIL PUMP DELIVERS THE ESSENTIAL TRANSMISSION FLUID FROM THE TRANSMISSION PAN TO THE VALVE BODY WHEN NEEDED.

  24. AMONG THE DIFFERENT COMPONENTS OF THE TRANSMISSION, THE OIL PUMP WILL FAIL OCCASIONALLY.

  25. CONCLUSION

  26. AUTOMATIC TRANSMISSION OF THE BENTLEY HAS SEVERAL COMPONENTS FOR ITS SMOOTH FUNCTIONING.

  27. WHEN ANY OF THE COMPONENTS ARE DAMAGED, THEN IT WILL NEED IMMEDIATE REPAIR.

  28. THNAK YOU HTTP://MARKDOUGLASMOTORWORKS.COM/
