Enclosures cables and connectors

Enclosures, Cables and Connectors


Enclosures

Materials available:

ABS plasic

Polycarbonate

Fiberglass

Stainless Steel

Aluminum

Enclosures

  • Needs to withstand hostile environments-rain, snow, saltwater blowing debris.

  • Needs a full hinge and a positive latching system.

  • Nema type 4 or 4X


Enclosures cables and connectors

ABS Plastic: Advantages and Disadvantages

  • Light

  • Easily modified by machine shop

  • Nonconductive

  • Brittle

  • Not UV resistant – needs paint

  • No Hinged Units


Enclosures cables and connectors

Polycarbonate: Advantages and Disadvantages

  • Light

  • Easily modified by machine shop

  • Fairly durable

  • More UV resistant than ABS plastic

  • Nonconductive

  • Black or clear color

  • Still needs to be painted for UV resistance

  • No Hinged Units


Enclosures cables and connectors

Fiberglass: Advantages and Disadvantages

  • Lightest

  • Easily modified by machine shop

  • More durable than Polycarbonate

  • Mostly UV resistant

  • Nonconductive

  • Best R factor

  • Most inexpensive

  • Pain to machine (dust)

  • Will break down over long time (years) if not painted


Enclosures cables and connectors

Stainless Steel: Advantages and Disadvantages

  • Most durable of all materials (will last forever)

  • Pain to machine (hard material)

  • Most heavy

  • Conducts heat/cold/electricity

  • Most expensive


Enclosures cables and connectors

Aluminum: Advantages and Disadvantages

  • Very durable (will last forever)

  • Easy to machine

  • Expensive

  • Heavy

  • Conducts heat/cold/electricity

  • Needs coating

  • 2nd most expensive


Sizes and costs

Sizes and Costs

  • MaterialSizeWeightPrice

  • SS16 x 14 x 620673.80

  • 16 x 12 x 823788.10

  • Fiberglass16 x 14 x 810152.30

  • 15.5 x 12 x 8.2511289.60

  • Al16 x 14 x 6 8392.90

  • 16 x 12 x 610670.50

  • 20 x 16 x 1016885.60


Cables

Jacket choices: PVC, teflon, polyurethane

Inner insulation choices: PVC, teflon, polyethylene

Cables

  • Hostile environments – water, snow, cold, heat, mud, saltwater, rodents, farm machinery

  • No. of traces?

  • Standard lengths?


Cable costs

Cable Costs

  • 22 AWG 4 twisted pairs, PU jacket, PE insulation – 1000 ft @ $1.46/ft- 2500 ft @ $1.19/ft

  • 22AWG 5 conductors, tpe jacket and insulation, $2.78/ft

  • 22 AWG 4 twisted pairs, PVC jacket, shielded, 500 ft @ $1.22/ft


Connectors

Connectors

  • Weather resistant

  • Small in size

  • No of pins?

  • Multiple insertions/extractions

  • Easily installed on cables

  • Cost


Connectors1

Connectors

  • AMP CPC series 1 connectors

  • Bulgin 900 series “Buccaneer”

  • Bulgin STD Buccaneer

  • Bulgin 400 series Buccaneer

  • Conxall

  • Amphenol mil-spec connector


Amp cpc connectors

No spec for waterproofing

Large – 27 mm dia for 9 pin connector

AMP CPC Connectors

  • Have existing inventory, crimpers, experience

  • Inexpensive

  • Fairly easy to install


Bulgin 900 series buccaneer

Large – 7 pin connector has 50 mm dia.

No more than 7 contacts

Expensive – aprox. $29.00 ea on avg.

No existing tooling or experience

Bulgin 900 Series Buccaneer

  • Waterproof specs

  • Low temp specs to -40 deg C

  • 7 contacts available


Bulgin std buccaneer connector

Large – 9 pin connector 38 mm dia

No existing tooling or experience

Bulgin STD Buccaneer Connector

  • Waterproof specs

  • Saltwater resistant

  • -40 deg C low temp spec

  • Inexpensive – 9 pin connector $9.00 on avg

  • USB and ethernet connectors in same size


Bulgin 400 series buccaneer

No existing tooling or experience

Bulgin 400 series Buccaneer

  • Waterproof specs

  • Low temp specs to -40 deg C

  • Small – only 19 mm dia for 12 pin connector

  • Inexpensive – only $4.00 each on avg


Conxall multi con connectors

Inexpensive – aprox. $7.00 ea on avg

No existing tooling or experience

ConXall Multi-Con Connectors

  • Waterproof specs

  • Low temp specs to -55 deg C

  • Saltwater resistant

  • Smaller than exisiting AMP CPC connectors 22 mm dia 9 pin conn

  • Min 300 mate/unmate cycles


Amphenol mil spec connectors

Large – 32 mm dia for 7 pin connector

Expensive – upwards of $40.00 ea min.

Amphenol mil spec Connectors

  • Waterproof specs

  • Cold temp specs

  • Varied configurations and sizes available

  • Have exisiting experience

  • Metal shells instead of plastic
