o-notation

o-notation. For a given function g ( n ), we denote by o (g(n )) the set of functions: o ( g ( n )) = { f ( n ): for any positive constant c > 0, there exists a constant n 0 > 0 such that 0  f ( n ) < cg ( n ) for all n  n 0 }

Download Presentation

o-notation

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript


  1. o-notation • For a given function g(n), we denote by o(g(n)) the set of functions: o(g(n)) = {f(n): for any positive constant c > 0, there exists a constant n0 > 0 such that 0 f(n)<cg(n) for all n n0} • f(n) becomes insignificant relative to g(n)as n approaches infinity: lim [f(n) / g(n)] = 0 n • We say g(n) is an upper bound for f(n)that is not asymptotically tight.

  2. O(*) versus o(*) O(g(n)) = {f(n): there exist positive constants c and n0 such that 0 f(n)cg(n), for all n n0}. o(g(n)) = {f(n): for any positive constant c > 0, there exists a constant n0 > 0 such that 0 f(n)<cg(n) for all n n0}. Thus o(f(n)) is a weakened O(f(n)). For example: n2 = O(n2) n2 o(n2) n2 = O(n3) n2 = o(n3)

  3. o-notation • n1.9999 = o(n2) • n2/ lg n = o(n2) • n2o(n2) (just like 2< 2) • n2/1000 o(n2)

  4. w-notation • For a given function g(n), we denote by w(g(n)) the set of functions w(g(n)) = {f(n): for any positive constant c > 0, there exists a constant n0 > 0 such that 0 cg(n)<f(n) for all n n0} • f(n) becomes arbitrarily large relative to g(n)as n approaches infinity: lim [f(n) / g(n)] =  n • We say g(n) is a lower bound for f(n)that is not asymptotically tight.

  5. w-notation • n2.0001 = ω(n2) • n2 lg n = ω(n2) • n2ω(n2)

  6. Comparison of Functions f g  a  b f (n) = O(g(n)) a b f (n) = (g(n)) a b f (n) = (g(n)) a = b f (n) = o(g(n)) a < b f (n) = w (g(n)) a > b

  7. Properties • Transitivity f(n) = (g(n)) & g(n) = (h(n))  f(n) = (h(n)) f(n) = O(g(n)) & g(n) = O(h(n))  f(n) = O(h(n)) f(n) = (g(n)) & g(n) = (h(n))  f(n) = (h(n)) • Symmetry f(n) = (g(n)) if and only if g(n) = (f(n)) • Transpose Symmetry f(n) = O(g(n)) if and only if g(n) = (f(n))

  8. Practical Complexities • Is O(n2) too much time? • Is the algorithm practical? At CPU speed 109 instructions/second

  9. Impractical Complexities At CPU speed 109 instructions/second

  10. Some Common Name for Complexity

  11. Growth Rates of some Functions Polynomial Functions Exponential Functions

  12. Effect of Multiplicative Constant 800 f(n)=n2 600 Run time 400 f(n)=10n 200 0 n 10 20 25

  13. n 2n 1ms x 2n 10 103 0.001 s 20 106 1 s 30 109 16.7 mins 40 1012 11.6 days 50 1015 31.7 years 60 1018 31710 years Exponential Functions • Exponential functions increase rapidly, e.g., 2n will double whenever n is increased by 1.

  14. Practical Complexity

  15. Practical Complexity

  16. Practical Complexity

  17. Practical Complexity

  18. Floors & Ceilings • For any real number x, we denote the greatest integerless than or equal to x by x • read “the floor of x” • For any real number x, we denote the least integergreater than or equal to x by x • read “the ceiling of x” • For all real x, (example for x=4.2) • x – 1  x  x  x  x + 1 • For any integer n , • n/2 + n/2 = n

  19. Polynomials • Given a positive integer d, a polynomial in n of degree d is a function P(n) of the form • P(n) = • where a0, a1, …, ad are coefficient of the polynomial • ad  0 • A polynomial is asymptotically positive iffad  0 • Also P(n) = (nd)

  20. Exponents • x0 = 1 x1 = x x-1 = 1/x • xa . xb = xa+b • xa / xb = xa-b • (xa)b = (xb)a = xab • xn + xn = 2xn x2n • 2n + 2n = 2.2n = 2n+1

  21. Logarithms (1) • In computer science, all logarithms are to base 2 unless specified otherwise • xa = b iff logx(b) = a • lg(n) = log2(n) • ln(n) = loge(n) • lgk(n) = (lg(n))k • loga(b) = logc(b) / logc(a) ; c  0 • lg(ab) = lg(a) + lg(b) • lg(a/b) = lg(a) - lg(b) • lg(ab) = b . lg(a)

  22. Logarithms (2) • a = blogb(a) • alogb(n) = nlogb(a) • lg (1/a) = - lg(a) • logb(a) = 1/loga(b) • lg(n)  n for all n  0 • loga(a) = 1 • lg(1) = 0, lg(2) = 1, lg(1024=210) = 10 • lg(1048576=220) = 20

  23. Summation • Why do we need to know this? We need it for computing the running time of a given algorithm. • Example: Maximum Sub-vector Given an array a[1…n] of numeric values (can be positive, zero and negative) determine the sub-vector a[i…j] (1 i  j  n) whose sum of elements is maximum over all sub-vectors.

  24. Example: Max Sub-Vectors MaxSubvector(a, n) { maxsum = 0; for i = 1 to n { for j = i to n { sum = 0; for k = i to j { sum += a[k] } maxsum = max(sum, maxsum); } } return maxsum; }

  25. Summation

  26. Summation • Constant Series: For a, b  0, • Quadratic Series: For n  0, • Linear-Geometric Series: For n  0,

  27. Series

  28. Proof of Geometric series A Geometric series is one in which the sum approaches a given number as N tends to infinity. Proofs for geometric series are done by cancellation, as demonstrated.

  29. Factorials • n! (“n factorial”) is defined for integers n  0 as • n! = • n! = 1 . 2 .3 … n • n! < nn for n ≥ 2
