Why wireless lan
Why Wireless LAN?

  • Traditional LANs need wires, which may be difficult to set up in some situations.

  • Advantages of Wireless LANs

    • Allow mobility and flexibility

    • Reduced cost

  • Applicable scenarios

    • Offices

    • Building with open area

    • Hybrid with wired LANs


Architectures
Architectures

Infrastructure mode

Infrastructure-less/ distributed/ad-hoc mode


Physical layer
Physical Layer

  • RF: Spread Spectrum, no licensing required. Resistance to interference

    • Band: 915-Mhz, 2.4 GHz (worldwide ISM), 5.2 Ghz

    • Direct sequence spread spectrum (DSSS)

      • broaden the signaling band by artificially increasing the modulation rate using a spreading code. 2M or 10M.

    • Frequency hopping spread spectrum (FHSS)

      • hop from narrow band to narrow band within a wide band, using each narrow band for a specific time period.


Mac layer hidden terminal problem
MAC Layer: Hidden Terminal Problem

  • Node B can communicate with A and C both

  • A and C cannot hear each other

  • When A transmits to B, C cannot detect the transmission using the carrier sense mechanism

  • If C transmits, collision will occur at node B

A

B

C


Mcac multiple access with collision avoidance

A

B

C

MCAC (Multiple Access with Collision Avoidance)

  • When node A wants to send a packet to node B, node A first sends a Request-to-Send (RTS)to A

  • On receiving RTS, node A responds by sending Clear-to-Send (CTS), provided node A is able to receive the packet

  • When a node (such as C) overhears a CTS, it keeps quiet for the duration of the transfer

    • Transfer duration is included in RTS and CTS both


Reliability

A

B

C

Reliability

  • Wireless links are prone to errors. High packet loss rate detrimental to transport-layer performance.

  • Mechanisms needed to reduce packet loss rate experienced by upper layers

  • When node B receives a data packet from node A, node B sends an Acknowledgement (Ack).

  • If node A fails to receive an Ack, it will retransmit the packet


Ieee 802 11 wireless mac
IEEE 802.11 Wireless MAC

  • Distributed and centralized MAC components

    • Distributed Coordination Function (DCF)

    • Point Coordination Function (PCF)


Ieee 802 11 dcf

A

B

C

IEEE 802.11 DCF

  • Uses RTS-CTS exchange to avoid hidden terminal problem

    • Any node overhearing a CTS cannot transmit for the duration of the transfer

  • Uses ACK to achieve reliability

  • Any node receiving the RTS cannot transmit for the duration of the transfer

    • To prevent collision with ACK when it arrives at the sender

    • When B is sending data to C, node A will keep quite


Collision avoidance
Collision Avoidance

  • With half-duplex radios, collision detection is not possible

  • CSMA/CA: Wireless MAC protocols often use collision avoidance techniques, in conjunction with a (physical or virtual) carrier sense mechanism

    • Carrier sense: When a node wishes to transmit a packet, it first waits until the channel is idle

    • Collision avoidance: Once channel becomes idle, the node waits for a randomly chosen duration before attempting to transmit


Congestion avoidance
Congestion Avoidance

  • When transmitting a packet, choose a backoff interval in the range [0,cw]

    • cw is contention window

  • Count down the backoff interval when medium is idle

    • Count-down is suspended if medium becomes busy

  • When backoff interval reaches 0, transmit RTS


Example

B1 = 25

B1 = 5

wait

data

data

wait

B2 = 10

B2 = 20

B2 = 15

Example

B1 and B2 are backoff intervals

at nodes 1 and 2

cw = 31


Ieee 802 11 pcf
IEEE 802.11 PCF

  • Purpose: contention-free data transmission

  • System components

    • Access Point (AP): a coordinator controlling the medium access in a poll-and-response manner

    • Stations: transmit only when being polled

  • A LAN operates in PCF or DCF mode

    • The duration in which PCF operates is called contention-free period (CFP)

    • Before/after a CFP, the network operates in DCF.


Ieee 802 11 pcf1
IEEE 802.11 PCF

  • Starting

    • AP seizes the medium by using “priority inter-frame space” (PIFS)

    • AP sends out a beacon packet to announce the beginning of a CFP (the packet contains the duration of the CFP)

  • In a CFP

    • AP may transmit data packets to any station

    • AP may send a polling packet to a station

      • The polled station replies with a data packet or a NULL packet (when nothing to send)

  • Ending

    • AP sends out an END packert.


Mac management
MAC Management

  • Synchronization

    • finding and staying with a WLAN.

    • Synchronization functions

  • Power management

    • sleeping without missing any messages

    • power management functions, e.g., periodic sleep, frame buffering, traffic indication map

  • Association and Re-association

    • joining a network, roaming, moving from one AP to another, scanning


Power management
Power Management

  • 802.11 power off station during idle periods

    • A station can be in one of three states:

      • transmitter on,

      • receiver only on,

      • dozing: both transmitter and receivers off

    • is transparent to existing protocols

    • is flexible to support different application


Power management1
Power Management

  • APs buffer packets for sleeping stations

    • AP announces which stations have frames buffered

    • traffic indication map (TIM) sent with every beacon.

    • All multicasts/broadcasts are buffered

  • Time Synchronization Function (TSF) assures AP and power save stations are synchronized

    • stations wake up periodically to hear a beacon

    • TSF timer keeps running when stations are sleeping

    • synchronization allows extreme low power operation


Summary
Summary

  • Architectures of Wireless LANs

    • Infrastructure or infrastructure-less

  • MAC

    • Hidden terminal problem

    • collision avoidance

    • DCF and PCF

  • MAC management

    • Power management and others



What is a manet mobile ad hoc networks
What is a MANET (Mobile Ad Hoc Networks)?

  • Formed by wireless hosts which may be mobile

  • No pre-existing infrastructure

  • Routes between nodes may potentially contain multiple hops

    • Nodes act as routers to forward packets for each other

    • Node mobility may cause the routes change

B

A

A

B

C

C

D

D


Why manet
Why MANET?

  • Advantages: low-cost, flexibility

    • Ease & Speed of deployment

    • Decreased dependence on infrastructure

  • Applications

    • Military environments

      • soldiers, tanks, planes

    • Civilian environments

      • vehicle networks

      • conferences / stadiums

      • outside activities

    • Emergency operations

      • search-and-rescue / policing and fire fighting


Challenges
Challenges

  • Collaboration

    • Collaborations are necessary to maintain a MANET and its functionality.

    • How to collaborate effectively and efficiently?

    • How to motivate/enforce nodes to collaborate?

  • Dynamic topology

    • Nodes mobility

    • Interference in wireless communications


Routing protocols overview
Routing Protocols: Overview

  • Proactive protocols

    • Determine routes independent of traffic pattern

    • Traditional link-state and distance-vector routing protocols are proactive

    • Examples:

      • DSDV (Dynamic sequenced distance-vector)

      • OLSR (Optimized Link State Routing)

  • Reactive protocols

    • Maintain routes only if needed

    • Examples:

      • DSR (Dynamic source routing)

      • AODV (on-demand distance vector)

  • Hybrid protocols

    • Example: Zone Routing Protocol (intra-zone: proactive; inter-zone: on-demand)


Routing protocols tradeoff
Routing Protocols: Tradeoff

  • Latency of route discovery

    • Proactive protocols may have lower latency since routes are maintained at all times

    • Reactive protocols may have higher latency because a route from X to Y may be found only when X attempts to send to Y

  • Overhead of route discovery/maintenance

    • Reactive protocols may have lower overhead since routes are determined only if needed

    • Proactive protocols can (but not necessarily) result in higher overhead due to continuous route updating

  • Which approach achieves a better trade-off depends on the traffic and mobility patterns


Dynamic source routing
Dynamic Source Routing

  • J. Broch, D. Johnson, and D. Maltz, “The dynamic source routing protocol for mobile ad hoc networks,” Internet-Draft Version 03, IETF, October 1999.

  • When node S wants to send a packet to node D, but does not know a route to D, node S initiates a routing process

  • Runs in three phases

    • Route Discovery  Route Reply  Path Establishment

  • Route Discovery

    • Source node S floods Route Request (RREQ)

    • Each node appends own identifier when forwarding RREQ


Route discovery in dsr
Route Discovery in DSR

Y

Z

S

E

F

B

C

M

L

J

A

G

H

D

K

I

N

Represents a node that has received RREQ for D from S


Route discovery in dsr1
Route Discovery in DSR

Y

Broadcast transmission

Z

[S]

S

E

F

B

C

M

L

J

A

G

H

D

K

I

N

Represents transmission of RREQ

[X,Y] Represents list of identifiers appended to RREQ


Route discovery in dsr2
Route Discovery in DSR

Y

Z

S

[S,E]

E

F

B

C

M

L

J

A

G

[S,C]

H

D

K

I

N


Route discovery in dsr3
Route Discovery in DSR

Y

Z

S

E

F

[S,E,F,J]

B

C

M

L

J

A

G

H

D

K

I

N

[S,C,G,K]


Route reply in dsr
Route Reply in DSR

  • Destination D on receiving the first RREQ, sends a Route Reply (RREP)

  • RREP is sent on a route obtained by reversing the route appended to received RREQ

  • RREP includes the route from S to D on which RREQ was received by node D


Route reply in dsr1
Route Reply in DSR

Y

Z

S

RREP [S,E,F,J,D]

E

F

B

C

M

L

J

A

G

H

D

K

I

N

Represents RREP control message


Route reply in dsr2
Route Reply in DSR

  • Node S on receiving RREP, caches the route included in the RREP

  • When node S sends a data packet to D, the entire route is included in the packet header

    • Hence the name source routing

  • Intermediate nodes use the source route included in a packet to determine to whom a packet should be forwarded


Data delivery in dsr
Data Delivery in DSR

Y

Z

DATA [S,E,F,J,D]

S

E

F

B

C

M

L

J

A

G

H

D

K

I

N

Packet header size grows with route length


Some other routing protocols
Some Other Routing Protocols

  • Location information aided protocols

  • Power-aware protocols

  • Others …

    • e.g., considering the stability of topology


Location aided routing lar
Location-Aided Routing (LAR)

  • Y. Ko and N. Vaidya, “Location-aided routing (LAR) in mobile ad hoc networks,” MobiCom'98.

  • Exploits location information to limit scope of route request flood

    • Location information may be obtained using GPS

  • Expected Zone is determined as a region that is expected to hold the current location of the destination

    • Expected region determined based on potentially old location information, and knowledge of the destination’s speed

  • Route requests limited to a Request Zonethat contains the Expected Zone and location of the sender node

  • B. Karp, and H. Kung, “Greedy Perimeter Stateless Routing for Wireless Networks,” MobiCom 2000.


Power aware routing
Power-Aware Routing

  • Modification to DSR to make it power aware (for simplicity, assume no route caching):

    • Route Requests aggregate the weights of all traversed links

    • Destination responds with a Route Reply to a Route Request if

      • it is the first RREQ with a given (“current”) sequence number, or

      • its weight is smaller than all other RREQs received with the current sequence number


Geography adaptive fidelity
Geography Adaptive Fidelity

  • Each node associates itself with a square in a virtual grid

  • Node in each grid square coordinate to determine who will sleep and how long

    [Y. Xu, et al. “Geography Adaptive Fidelity in Routing,” Mobicom’2001]

Grid head


Research in other layers
Research in Other Layers

  • Transport layer

    • A survey: A. Hanbali, E. Altman, P. Nain, “A Survey of TCP over Mobile Ad Hoc Networks (2004)”.

  • Application layer

    • Data management

      • e.g., B. Xu, A. Ouksel, and O. Wolfson, "Opportunistic Resource Exchange in Inter-vehicle Ad Hoc Networks," MDM, 2004.

    • Distributed algorithms

      • clock synchronization

      • mutual exclusion

      • leader election

      • Byzantine agreement



Problems
Problems

  • Hosts may misbehave or try to compromise security at all layers of the protocol stack

  • Transport layer: securing end-to-end communication

    • Need to know keys to be used for secure communication

    • May want to anonymize the communication

  • Network layer: misbehaving hosts may create many hazards

    • May disrupt route discovery and maintenance:Force use of poor routes (e.g., long routes)

    • Delay, drop, corrupt, misroute packets

    • May degrade performance by making good routeslook bad

  • MAC layer: misbehaving nodes may not cooperate

    • Disobey protocol specifications for selfish gains

    • Denial-of-service attacks


Security in manet agenda
Security in MANET: Agenda

  • Key management

  • Securing communications

  • Dealing with MAC and Network layer misbehaviors


Key management
Key Management

  • Challenges

    • In “pure” ad hoc networks, access to infrastructure cannot be assumed

    • Network may also become partitioned

  • Solutions

    • Distributed public key infrastructure

      • Self-organized key management

      • Distributed key certification

    • TESLA

    • Others


Self organized public key management capkun03
Self-Organized Public Key Management [Capkun03]

  • Nodes form a “Certificate Graph”

    • each vertex represents a public key

    • an edge from Ku to Kw exists if there is a certificate signed by the private key of node u that binds Kw to the identity of some node w.

Ku

(w,Kw)Pr Ku

Kw


Self organized public key management capkun031
Self-Organized Public Key Management [Capkun03]

  • Four steps of the management scheme

  • Step 1: Each node creates its own private/public keys. Each node acts independently


Self organized public key management capkun032
Self-Organized Public Key Management [Capkun03]

  • Step 2: When a node u believes that key Kw belongs to node w, node u issues a public-key certificate in which Kw is bound to w by the signature of u

    • u may believe this because u and w may have talked on a dedicated channel previously

    • Each node also issues a self-signed certificate for its own key

  • Step 3: Nodes periodically exchange certificates with other nodes they encounter

    • Mobility allows faster dissemination of certificates through the network


Self organized public key management capkun033
Self-Organized Public Key Management [Capkun03]

  • Step 4: Each node forms a certificate graph using the certificates known to that node

    Authentication: When a node u wants to verify the authenticity of the public key Kv of node v, u tries to find a directed graph from Ku to Kv in the certificate graph. If such a path is found, the key is authentic.


Self organized public key management capkun034
Self-Organized Public Key Management [Capkun03]

  • Misbehaving hosts may issue incorrect certificates

  • If there are mismatching certificates, indicates presence of a misbehaving host (unless one of the mismatching certificate has expired)

    • Mismatching certificates may bind same public key for two different nodes, or same node to two different keys

  • To resolve the mismatch, a “confidence” level may be calculated for each certificate chain that verifies each of the mismatching certificates

    • Choose the certificate that can be verified with high confidence – else ignore both certificates


Secure communication
Secure Communication

  • With the previously discussed mechanisms for key distribution, it is possible to authenticate the assignment of a public key to a node

  • This key can then be used for secure communication

    • The public key can be used to set up a symmetric key between a given node pair as well

    • TESLA provides a mechanism for broadcast authentication when a single source must broadcast packets to multiple receivers


Secure communication1
Secure Communication

  • Sometimes security requirement may include anonymity

  • Availability of an authentic key is not enough to prevent traffic analysis

  • We may want to hide the source or the destination of a packet, or simply the amount of traffic between a given pair of nodes


Traffic analysis
Traffic Analysis

  • Traditional approaches for anonymous communication, for instance, based on MIX nodes or dummy traffic insertion, can be used in wireless ad hoc networks as well


Mix nodes
Mix Nodes

  • Mix nodes can reorder packets from different flows, insert dummy packets, or delay packets, to reduce correlation between packets in and packets out

G

D

C

M3

M1

B

M2

E

F

A


Mix nodes1
Mix Nodes

  • Node A wants to send message M to node G. Node A chooses 2 Mix nodes (in general n mix nodes), say, M1 and M2

G

D

C

M3

M1

B

M2

E

F

A


Mix Nodes

  • Node A transmits to M1message K1(R1, K2(R2, M)) where Ki() denotes encryption using public key Ki of Mix i, and Ri is a random number

G

D

C

M3

M1

B

M2

E

F

A


Mix nodes2
Mix Nodes

  • M1 recovers K2(R2,M) and send to M2

G

D

C

M3

M1

B

M2

E

F

A


Mix nodes3
Mix Nodes

  • M2 recovers M and sends to G

G

D

C

M3

M1

B

M2

E

F

A


Mix nodes4
Mix Nodes

  • If M is encrypted by a secret key, no one other than G or A can know M

  • Since M1 and M2 “mix” traffic, observers cannot determine the source-destination pair without compromising M1 and M2 both


Open problems
Open Problems

  • How to select the mix nodes to

    • balance the tradeoff between anonymity and cost

    • be adaptive to node mobility

  • Can the mix structure be applied without PKI, i.e., only using symmetric key techniques?


Mac layer misbehavior

Access Point

Access Point

Wireless channel

Wireless channel

A

C

B

D

MAC Layer Misbehavior

  • Nodes are required to follow Medium Access Control (MAC) rules

  • Misbehaving nodes may violate MAC rules


Some possible misbehavior
Some Possible Misbehavior

  • Causing collisions with other hosts’ RTS or CTS

  • “Impatient transmitter”

    • Smaller backoff intervals

    • Shorter Inter-frame Spacings


Solutions
Solutions

  • Diagnose node misbehavior

    • Catch misbehaving nodes

  • Discourage misbehavior

    • Punish misbehaving nodes

  • Details will be discussed later in this course


Network Layer Misbehavior: Drop/Corrupt/Misroute

  • A node “agrees” to join a route(for instance, by forwarding route request in DSR) but fails to forward packets correctly

  • A node may do so to conserve energy, or to launch a denial-of-service attack, due to failure of some sort, or because of overload

  • Solutions

    • Opt I: Detect the attacks  tolerate them

    • Opt II: Avoid some attacks


Watchdog Approach

  • Verify whether a node has forwarded a packet or not

B sends packet to C

E

A

C

D

B


Watchdog Approach

  • Verify whether a node has forwarded a packet or not

  • B can learn whether C has forwarded packet or not

  • B can also know whether packet is tampered with if noper-link encryption

C forwards packet to D

E

A

C

D

B

B overhears C

Forwarding the packet


Watchdog + Pathrater

  • “Pathrater” is run by each node. Each node assigns a rating to each known node

    • Previously unknown nodes assigned “neutral” rating of 0.5

    • Rating assigned to nodes suspected of misbehaving are set to large negative value

    • Other nodes have positive ratings (between 0 and 0.8)

  • Ratings of well-behaved nodes increase over time up to a maximum

    • So a temporary misbehavior can be overcome by sustained good behavior

  • Routes with larger cumulative node ratings preferred


Information Dispersal to Tolerate Misbehavior

  • Choose n node-disjoint paths to send the n pieces of information

  • Use a route rating scheme (based on delivery ratios) to select the routes

  • Acknowledgements for received pieces are sent

  • The missing pieces retransmitted on other routes

  • Need to be able to detect whether packets are tampered with


Route Tampering Attack

  • A node may make a route appear too long or too short by tampering with RREQ in DSR

  • By making a route appear too long, the node may avoid the route from being used

    • This would happen if the destination replies to multiple RREQ in DSR

  • By making a route appear too short, the node may make the source use that route, and then drop data packets (denial of service)

  • Solution

    • Protect route accumulated in RREQ from tampering

    • Removal or insertion of nodes should both be detected


Ariadne: Detecting Route Tampering

  • Source-Destination S-D pairs share secret keys Ksd and Kds for each direction of communication

  • One-way hash function H available

  • MAC = Message Authentication Code (MAC) computed using MAC keys


Ariadne: Detecting Route Tampering

  • Let RREQ’ denote the RREQ that would have been sent in unmodified DSR

  • Source S broadcasts RREQ = RREQ’,h0,[]where h0 = HMACKsd(RREQ’)

  • When a node X receives anRREQ = (RREQ’, hi, [m list])

    • it broadcasts RREQ, mi+1

    • where RREQ = (RREQ’, hi+1, [m list]), mi+1where hi+1 = H(X, hi) and mi+1=HMACKx(RREQ)


Acknowledgements
Acknowledgements

Some slides in this talk were based on

  • Nitin Vaidya, Tutorials on Mobile Ad Hoc Networks

  • Nitin Vaidya, Security and Misbehavior Handling in Mobile Ad Hoc Networks

  • Guohong Cao, CSE 598B: Wireless LAN


ad
