  1. Creating an Automated Blood Vessel Diameter Tracking Tool Peter McLachlan Department of Medical Biophysics The University of Western Ontario Supervisor: Dr. Graham Fraser Co-supervisor: Dr. Dwayne Jackson

  2. Introduction • Blood flow is modulated to meet metabolic demands • Blood flow, Q, described by fluid flow equations • Ohm’s law: • Poiseuille’s law: • Small change in radius  large change in flow • Need to measure vessel diameters

  3. Motivation • Currently, diameters are measured in ImageJ In vivo video stills

  4. Motivation • A graduate student may perform: • 1 experiments / week • ~10 000 images / experiment (conservatively!) • ~5 seconds per measurement with ImageJ • = 700 person hours per year • Very time consuming! • This is twice the time to run the experiment • This process needs to be automated

  5. Current Attempts • Sarelius: • purely horizontal vessels and sub-regions • successful but limited to pre-aligned vessels • Our goal: • vessels at any orientation • more general sub-regions: • can vary the position wrt the input points

  6. Project Objectives • Image Registration • In vivo microscopic sequences of blood flow • Minimize motion in sequence frames • Vessel Diameter Measurement • Automated over video sequence

  7. Quick Overview • Outline of programming tasks: In vivo microvessel video Image Registration User inputs initial diameter seed points Track input points over sequence Output diameter measurements

  8. Why Image Registration? • Consecutive frames experience tissue motion • Breathing • Response to experimental intervention

  9. Raw Video

  10. Image Registration • Measure shift of a frame wrt reference frame • measure similarity to a reference frame • 2D normalized cross-correlation: similarity of frames • outputs correlation amplitude as function of x,y

  11. Methods • Correlation amplitude plotted versus position (x,y) • Best overlap: at the position of maximum similarity • Calculate offset of frame to reference from this • Repeat for every frame

  12. Registered Video

  13. Image Registration • Correlation Amplitude: how good is the match

  14. Project Objectives • Image Registration • Minimize tissue motion in video • Vessel Diameter Measurement • Automate over video sequence

  15. Diameter Measurement • User inputs two seed points in first image • Diameter is distance between two points

  16. Diameter Measurement • Program creates sub-regions around seed points • Compute similarity of current frame sub-region to reference frame sub-region

  17. Diameter Measurement • Peak cross-correlation amplitude how far the regions have moved • Shift seed points by offset and re-calculate diameter d

  18. Feature Tracking First frame with seed pointsfrom user Go to next frame No Final frame? Create sub-regions based on input points from previous frame Calculate new points (and diameter) from peak cross-correlation offset Yes End

  19. Model Validation • Obtained expert manual diameter measurements • The gold standard • Compare these to diameters generated by the program with the same initial seed points

  20. Results • Expert manual measurement

  21. Results • Expert manual measurement

  22. Results • Expert manual measurement

  23. Conclusions • Successfully stabilized tissue motion in sequences • Software is capable of making automated diameter measurements • Resulting diameter measurements are on average within1.5 microns of the gold standard • Some post-hoc analysis and selection of results may be necessary (to identify periods of poor measurements)

  24. Future Work • Test software on other sequences and imaging techniques • Test with other similarity metrics • Expand functionality to measure multiple vessels and ROIs along a single vessel

  25. Acknowledgements • Dr. Graham Fraser • Dr. Dwayne Jackson • Nicole Novielli

  26. References • Lee, J., Jirapatnakul, A., Reeves, A., Crowe, W., Sarelius, I. Vessel Diameter Measurement from Intravital Microscopy Annals of Biomedical Engineering, Vol. 37, No. 5, May 2009 (2009) pp. 913–926 • Brown, L. G. A survey of image registration techniques. ACM Comput. Surv. 24(4):325–376, 1992. • J. P. Lewis. Fast Normalized Cross-Correlation. Industrial Light & Magic

  27. Future Work • Optimize correlation amplitude • Test software on other sequences and imaging techniques • Test various size and position of sub-regions • Test with other similarity metrics • Expand functionality to measure multiple vessels and ROIs along a single vessel

  28. Results • Non-expert Measurement

  29. Tracking • Video of tracked diameters:

  30. Diameter Measurement • Automated method J. Lee et al., Annals of Biomedical Eng., V. 37. No. 5:913–926, 2009

  31. Image Registration • Pick sub-regions in an image • Compare relative positions with respect to reference • Best position: where regions have the highest similarity
