1. Engineering and Industrial Development Centre “Generating value through knowledge”

2. ACTUAL CAPACITIES R&D AND SPECIALIZED SERVICES ON COMPOSITE STRUCTURES DESIGN, OPTIMIZATION AND MANUFACTURING TECHNOLOGY Autoclave, Econoclave 2×4, ASC Process Systems • Composite material specimen preparation. Hand lay up with prepreg. Preparation in autoclave and hot plates compression press. (laminates of fiber reinforced composite materials with polymeric matrix, different fiber orientation). • Determination of mechanical properties; complete characterization considering the material anisotropy. Tension, compression, bending testing at temperatures -129 a 540°C. • Fatigue and fracture analysis of composite materials: High cycle fatigue, low cycle fatigue, fracture toughness, Poisson modulus, interlaminar shear, dynamic testing. • Nondestructive testing of composite materials, using ultrasonic with phase arrays, immersion ultrasonic, “C” scan, Lamb waves, acoustic emission, radiography, infrared thermography. • Failure analysis of composite materials using optical microscopy and scanning electron microscopy. • Noise and vibration analysis. Manual Hydraulic Compression Press, Q-230H, PHI Mechanical Testing System MTS-810 Instron 8872 SEM

3. ACTUAL CAPACITIES R&D AND SPECIALIZED SERVICES ON COMPOSITE STRUCTURES DESIGN, OPTIMIZATION AND MANUFACTURING TECHNOLOGY BODE 100 - PC Controlled vector network analyzer • ASTM D 3529/D 3529M – 97 (Reapproved 2008) Standard test method for matrix solids content and matrix content of composite prepreg. • ASTM D 3530/D 3530M – 97 (Reapproved 2008) Standard test method for volatiles content of composite material prepreg. • ASTM D 3531 – 99 (Reapproved 2004) Standard test method for resin flow of carbon fiber-epoxy prepreg. • ASTM D 3532 – 99 (Reapproved 2004) Standard test method for gel time of carbon fiber-epoxy prepreg. OMNISCAN MX PA, OLYMPUS Ultrasonic immersion system Hopkinson bar Noise and vibration analysis Infrared thermography

4. ACTUAL CAPACITIES R&D AND SPECIALIZED SERVICES ON METALLIC STRUCTURES DESIGN, OPTIMIZATION AND MANUFACTURING TECHNOLOGY • MECHATRONICS FOR INDUSTRY. Turnkey automation solutions: Assembly & automated manipulation; Machinery for special testing • ASSEMBLY. Design and integration of solutions in: Automated transport & transfer systems; Handling & integration of robots; Positioning & indexing systems. Insertion, clamping, riveting & other assembly operations. • MACHINING. Machining Solutions: Automated drilling systems; Automated regrinding systems; Other machining operations. • TESTING. Design of special machines for inspection testing: Machines for inspection in industrial laboratories; Machines for automated testing; Machines for the inspection and operations of in-line testing; Optical machines. • AUTOMATION SIMULATION AND MACHINERY ANALYSIS. FEM & dynamic analysis; Production line simulations & human factors. • APPLIED ELECTRONICS. Integrated systems in industrial inspection for: • Product quality checking, detection of defects; Barcode inspection in 1d & 2d; Assembly verification; Inspection of dimensions.

5. ACTUAL CAPACITIES R&D AND SPECIALIZED SERVICES ON METALLIC STRUCTURES DESIGN, OPTIMIZATION AND MANUFACTURING TECHNOLOGY • ADVANCED MANUFACTURING • Product Design: Design and development of structural components for manufacturing processes and assembly with DELMIA-CATIA (Robotics simulations & work cells design) • Modeling and simulation • Plastic and other materials prototype manufacturing • Rapid prototyping by stereolitography • High speed and high precision machining • Die and tooling manufacturing • Manufacturing processes development • Optimization of operations sequence, production logistics and production diagnostic systems. • (Aluminum, Stainless Steel, Alloy Steels, Titanium, Engineering plastics)

6. ACTUAL CAPACITIES • NDT • NON DESTRUCTIVE INSPECTION • (MM-063-006/08) • Radiography (RT) Testing • Ultrasonic Testing • Magnetic Particle Testing • Leak Testing • Eddy Current Testing • Visual testing • Fluorescent penetrant examination in aerospace components Certified Personnel ASNT LEVEL III AND NAS 410

7. ACTUAL CAPACITIES Acredited on ISO-IEC-17025-2005 (NMX-EC-17025-IMNC-2006) OTHERMETALLURGICAL SERVICES • Metallography and Failure Analysis • (MM-0031-006/08) • Chemical Analysis • (Q-093-073/09 ema) • Mechanical Testing • (MM-065-006/08)

8. ACTUAL CAPACITIES METROLOGY SERVICES • Management of metrological confirmation programs of measuring equipment. • Installation and set up at operation of calibration laboratories. • Specialized training in Metrology (Courses and Diplomas). • Specializes Consulting in measurement assurance with the MESURA program ® by CENAM and technological institutions. • Development of models and software for estimating uncertainties in measurement processes. • Development and manufacture of measurement equipment.

9. ACTUAL CAPACITIES METROLOGY SERVICES Accreditation NMX-EC-17025-IMNC-2006 Certification NMX-CC-9001-IMNC-2000 Calibration and Measurements: • Dimensional Qro. (D-39 ema), S.L.P. (D-102 ema), G.M. Silao (D-108 ema) • Mass (M-31 ema) • Density (DEN-06 ema) • Volume (V-19 ema) • Flow (FL-14 ema) • Pressure (P-58 ema) • Temperature (T-24 ema) • Humidity (H-09 ema) • Torsionaltorque, S.L.P. (PT-19 ema) • CANHEFERN • Electric (E-85 ema) • Time & Frecuency (TF-14 ema) • MIDE • Gas Flow (FL-016 ema)

10. POTENTIAL CAPACITIES POTENTIAL CAPACITIES ON R&D AND SPECIALIZED SERVICES (no equipments available) • Flammability analysis • Permeability and water absorption analysis • Porosity analysis • Effect of humidity in composite materials • Electrical discharge reception in composite materials • Inspection by shearography • Environmental conditioning • High velocity impact testing • Other validation tests, according with special client requirements

11. IDENTIFIED COLLABORATION OPPORTUNITIES CoopAIR - CIDESI “Generating value through knowledge”

12. Engineering and Industrial Development Centre Tank you very much “Generating value through knowledge”
