  1. Status of (n,a) Measurement with CVD Diamond Detector Weiss Christina 12.04.2011

  2. Introduction • Data Analysis of Testbeams 2010 • Measurements • Analysis • Status for 2011 • Detector • Sample (n,a) with CVD diamond

  3. Data Analysis of Testbeams 2010

  4. Measurements 2010 • pCVD diamond detector : • En > 6 MeV • 200 mV/div • Background measurement • sCVD diamond detector : • En > 100 eV • 10 mV/div • 200 mV/div • Background measurement • 0.1 mm PE foil as converter (recoil protons) (n,a) with CVD diamond

  5. Raw Data Recovery time after g-flash < 200 ns (n,a) with CVD diamond

  6. Raw Data, Cuts Threshold = 20 mV Max Width = 10 ns (n,a) with CVD diamond

  7. Amplitude versus Area (n,a) with CVD diamond

  8. Experimental Data (n,a) with CVD diamond

  9. 12C Cross Section Data (n,a) with CVD diamond

  10. Amplitude Spectrum: 1 MeV < En < 20 MeV Threshold (n,a) with CVD diamond

  11. Preliminary Results : 1 MeV < En < 20 MeV CENDL CENDL (n,a) with CVD diamond

  12. Next Steps • Check TOF – energy conversion • Reassess cuts • Baseline restoration • Take other material into account (esp.: Al, Cu) Simulation ? • Make analysis for the data with converter • Pulse shape analysis (n,a) with CVD diamond

  13. Status for 2011

  14. 10B (n,a) Measurement, 05.2011 • Detector • Metallization of the pCVD diamond: 19. – 20. April 2011 • PCB‘s: in production, expected by end of April • Detector housing: ready • Sample • W. Vollenberg: expected by end next week (n,a) with CVD diamond

  15. Everything ongoing, nothing finished! Thank you for the attention!

  16. Raw Data, Zoom (n,a) with CVD diamond

  17. Amplitude Spectrum (n,a) with CVD diamond
