Nas architecture www nas architecture faa gov cats

NAS Architecturewww.nas-architecture.faa.gov/cats

Steve Bradford

FAA Architecture and Systems Engineering


Nas architecture nas architecture faa cats

Seven Modernization Goals

  • Safety

  • Accessibility

  • Flexibility

  • Predictability

  • Capacity

  • Efficiency

  • Security


Nas architecture

NAS Architecture

  • “Living” representation of the FAA’s strategic plan for NAS modernization

  • Promotes FAA/industry collaboration and communication

  • Supports the FAA acquisition decision processes

    • Allows the system to be placed under control

    • Aids in the clarification of requirements and assessment of their impact on system design

  • Supports the FAA annual budget decision process


The nas architecture

AMS

The NAS Architecture

Logical View of the Architecture

Blueprint for NAS Modernization

NAS Architecture Version 4.0

Programmatic Schedule and Cost

NAS

Architecture

Processes

(Used to

Create Logical

& Technical

Architecture

Products )

Aviation

Community

Desires

Technical View

of the Architecture

Government

Policy &

Laws

NAS Requirements

NAS RD

Technical Details

4


Air traffic services

Air Traffic Services

Air Traffic

Services

Service Group

Services

Flight

Planning

ATC-Separation Assurance

ATC-Advisory

TM-Synchronization

TM-Strategic

Flow

Navigation

Airspace

Management

Infrastructure /Information

Management

  • Flight Plan Support

  • Flight Plan Processing

  • Aircraft - Aircraft

  • Aircraft - Terrain / Obstacles

  • Aircraft - Airspace

  • Surface Separation

  • Weather Advisories

  • Traffic Advisories

  • NAS Status Advisories

  • Airborne

  • Surface

  • Long-Term Planning

  • Flight Day Management

  • Performance Assessment

  • Airborne Guidance

  • Surface Guidance

  • Airspace Design

  • Airspace for Special Use

  • Monitoring & Maintenance

  • Spectrum Management

  • Government / Agency Support

Emergency & Alerting

  • Emergency Assistance

  • Alerting Support

Capabilities


Nas architecture nas architecture faa cats

NAS Modernization Process

“AVIATION COMMUNITY”

OMB

Existing

Services

Future

CONOPs

FAA

Plans

Airport

Imp Plan

Sustain

Service

New

Capabilities

Enterprise

Improvements

Airport

Improvements

5-Year

Projection

NAS ARCHITECTURE

98

99

00

01

02

03

04

05

06

07

08

09

10

11

12

13

14

15

PHASE 1

PHASE 2

PHASE 3

Acquisition Management System

  • Architecture Impact Assessments

  • Investment Analysis

  • Mission Need Analysis

  • Joint Resources Council/Resource Mgmt Councils

National Airspace System

Increasing Capabilities


Nas architecture nas architecture faa cats

Current Communications

  • Separate networks for voice and data; separate operations and administrative networks; mix of owned and leased; old technology

    • Inefficient and costly

    • Limits NAS modernization and growth

  • Voice switch technology 10-20 years old with growing supportability problems; many FAA-unique interfaces

    • Complicates transition to digital network

  • Approximately 40,000 analog radios with growing supportability problems

    • Inefficient use of overcrowded spectrum


Nas architecture nas architecture faa cats

Communications Highlights

  • Modern ground telecommunications infrastructure

    • Integrated digital network for voice, data, and video

    • Different classes of service to meet operations and administrative user needs

    • Improved network monitor, control and usage data

  • Next generation air-ground communications

    • Digital radios for voice and data communications (continue to operate UHF radios for DOD users)


Nas architecture nas architecture faa cats

Communications Summary

  • Migrate to all-digital communications to take advantage of newer, lower-cost technology and services and provide seamless communications for NAS users

  • Integrate voice, data and video networks for greater efficiency, better management, and lower cost

  • Migrate to telecommunications industry protocols and standards to simplify interfaces and reduce cost

  • Transition to digital radios for better spectrum utilization


Nas architecture nas architecture faa cats

Current Data Link

  • Limited Data Link Capability

    • Available through a Commercial Service Provider

      • ACARS (analog system)

  • Domestic

    • 57 Busiest Airports in the Terminal/Tower domains

      • Two sets of messages: Predeparture Clearance and Weather Information

    • Detroit Airport - (Prototype)

      • One message: Taxi Clearance


Nas architecture nas architecture faa cats

Current Data Link (concl.)

  • Oceanic

    • Limited Controller Pilot Data Link Communications (CPDLC) for aircraft equipped with the Future Air Navigation System (FANS)

    • Available at multi-sectors in Oakland Center

    • Service Provider

  • Other Data Link Services - Different Stages

    • Traffic Information Service (TIS) provides situational awareness information via Mode-S

      • Service available at approximately 90 terminal Mode-S sites

    • Initial Flight Information Service (FIS) will provide weather, NOTAM, and SUA data


Nas architecture nas architecture faa cats

Navigation Transition

  • Current navigation aid (NAVAID) assets continuethrough transition with DOD reliance on TACAN

  • Navigation and Landing Highlights

    • SATNAV and RNAV

    • Augmentation of GPS necessary

  • Evolution of Navigation goes beyond just navigation and landing

    • ADS-B

    • Communications Timing

    • Moving Maps


Nas architecture nas architecture faa cats

Public Use Approaches

AVN Development Efforts and Plans (Safer Skies)

  • 12,600 instrument approaches exist

  • 3,009 GPS non-precision approaches (LNAV only)

    • 2,427 published

  • 529 LNA/VNAV approaches developed

  • 56 published since October 2000

  • Next Steps2,528 approaches at 576 airports by 2006 (Part 139 airports)

  • 2,864 approaches at 788 airports by 2010 (runways > 5,000’)

  • 4,450 approaches at 1,300 airports after 2010 (runways < 5,000’)

  • LAAS acquisition and fielding starts in FY 02

    • Operational approval of Part 171 LAAS CAT I systems (non-fed)

    • Contract award for first 20 of 60 LAAS units

  • WAAS LNAV/VNAV test, evaluation and acceptance in FY 02

  • WAAS IOC in 2003 for LNAV/VNAV

  • Additional geostationary satellite services decision is in review


Nas architecture nas architecture faa cats

Surveillance Modernization

  • ARSR-4 - Complete FY1999

  • ASR-11

    • Funding through FY2008 for radars

    • SI and ASTERIX mods planned; SI complete 2010, ASTERIX complete 2008

  • ASR-9 Service Life Extensions

  • ATCBI-6

    • Funding to FY2005; complete 2004

  • ASDE-3 Improvements

  • ASDE-X

    • Funding FY2005; complete 2005

  • ADS-B - Enters as Pockets and NAS-wide starting in 2007; ~900 ADS-B ground stations


Nas architecture nas architecture faa cats

Initial Set of ADS-B Functions…

Safety

Efficiency

Surface movement with

surveillance and navigation

(ADS-B/CDTI/TIS-B)

Surveillance in non-radar airspacewith radar-like separation (ADS-B

or ADS-B/CDTI/TIS-B)

Improved see and avoid

capabilities

(ADS-B/CDTI/TIS-B)

Surface movement with surveillanceand navigation (ADS-B/CDTI/TIS-B)

Surveillance in non-radar airspacewith radar-like separation (ADS-B orADS-B/CDTI/TIS-B)

Oceanic ADS-A leading to 30/30 nmand 1,000 feet separation (ADS-A)

Visual acquisition for approaches

(ADS-B/CDTI/TIS-B)

Candidate PRM replacement

…with a path to greater capacity benefit through evaluationsunder Safe Flight 21 with emphasis on certification safety and use for maneuvering


Nas architecture nas architecture faa cats

Infrastructure

  • STARS Replacement of Terminal Automation

  • El Paso and Syracuse Deployed

  • En Route Automation Modernization (eRAM)

  • Requirements Definition Phase to replace HOSTsoftware

  • New Flight Plan Processor and Surveillance DataProcessor


Nas architecture nas architecture faa cats

Oceanic and Offshore Evolution

  • Advanced Technologies & Oceanic Procedures (ATOP)

    • Contract awarded

    • 30 x 30 x 1,000 feet in the Ocean

  • Gulf of Mexico Challenges

    • Domestic Separation is the Goal - 5 miles everywhere

    • Surveillance is the Obstacle

    • Options

      • Beacons in the Gulf

      • ADS-B

      • NASA Helicopter Tracking System Using ADS-B & Multilateration


Nas architecture nas architecture faa cats

Oceanic Evolves towards High Altitude Domestic

3-miles normalized

Low Density Free Maneuvering

Enhanced /Integrated SMS

Non-directional Altitudes

Parabolic Profiles

Enhanced Maneuvers - ADS

Enhanced SDP - Extend 3 miles

Trajectory Management

Flex-Terminals

Shared Authority

Dynamic Design and Asset Mapping

30/30

SMS / Conformance Monitoring

Digital Taxipaths

RVSM

High Altitude Centers

Terminal Redesign

Dynamic Resectorization

RNAV

Expanded Use 3 miles

LAHSO

Inc. Surveillance

Full ADLS

Pilot Spacing

Reduced Sep GOMEX

aFAST with AVOSS

Moving Map

High Alt. RVSM

Mc TMA

Flight Profiles embed SUA Mgmt.

SMA ASDE

High Alt. Uniform Sector

Non-Tactical Data via datalink

LAADR TAAP

RNAV

Wake Advisor

New Sectors

TMA

TOA Assignment at Transition Point

Enhanced Departure Planner - EDP

SUA Status - Inflight Planning

aFAST

CPDLC

LDR

Trajectory Management

Arrival Departure Rates

SUA Mgmt.

Virtual Stream E/DA

Adjacent Airport Procedures

Full TRACON pFAST

Enroute Congestion

Reduce Workload w/ Resolutions

Move Holding

pFAST DSP

URET TMA

Airspace Resource Allocation Program

2015

.

Runways

Runways

Runways

LAADR TAAP

Improved Wx Planning

LAADR TAAP

Simultaneous Alert of Hazards

Airspace Resource Allocation Program

Airport Weather Conditions

Collaborative Routing

Enroute Severe Weather

SMS LAAS CDTI

2010

Continual Process Improvement Training

Digital Taxipaths Conformance Monitoring

Improved Visual Acquisition

Limited Dynamic Resectorization

PRM SOIA

ILS WAAS LAAS

Spacing by Flight Deck

High Alt. RVSM

Adjacent Airport Procedures

Improved WX Forecasting Reporting

Dynamic Resectorization

ADS-B as PRM Source

LAADR TAAP CDR

RNAV

Zero Visibility Operations with CDTI

LAAS CATII/III

WX on DSR

2005

Dynamic Design and Asset Mapping

RVSM

Flight Profile Probing Against Weather

Weather Status - Inflight Planning

RNAV

Icing & Turbulence

All items are from the NAS Concept of Operations/Architecture. Items in grey are addressed in the OEP. Blank spaces indicate that there are no new items in that time period.

Trajectory Management
