Presentation Transcript


Recovery and reconstruction after the pakistan earthquake l.jpg

RECOVERY and RECONSTRUCTION after the PAKISTAN EARTHQUAKE

CHOOSING OPTIONS THAT WILL FACILITATE LONG-TERM RECOVERY FROM THE OCTOBER 8, 2005 DISASTER


October 8 2005 pakistan earthquake l.jpg

OCTOBER 8, 2005 PAKISTAN EARTHQUAKE


Long term recovery needs after pakistan earthquake l.jpg

LONG-TERM RECOVERY NEEDS AFTER PAKISTAN EARTHQUAKE

  • NEED 2 TO 3 MILLION NEW DWELLINGS THAT ARE EARTHQUAKE RESILIENT.

  • NEED NEW SCHOOLS THAT ARE EARTHQUAKE RESILIENT.

  • NEED NEW HOSPITALS THAT ARE EARTHQUAKE RESILIENT.

  • NEED INFRASTRUCTURE THAT IS EARTHQUAKE RESILIENT.


Slide4 l.jpg

GOAL

  • TO MARSHAL AND INTEGRATE THE COMMUNITY’S STAPLE FORCES,..

  • …GIVING THEM EQUITY IN DESIGNING PROCESSES FOR BECOMING EARTHQUAKE RESILIENT.


Objectives l.jpg

TO BECOME RESILIENT TO GROUND SHAKING, LANDSLIDES, AND AFTERSHOCKS

TO ADOPT AND IMPLEMENT PUBLIC POLICY MANDATES FOR MITIGATION, PREPAREDNESS, EMERGENCY RESPONSE, AND RECOVERY AND RECONSTRUCTION

OBJECTIVES


Objectives6 l.jpg

USE STATE-OF-ART TOOLS FOR ASSESSING HAZARDS AND RISK (E.G., GROUND SHAKING MAPS AND HAZUS)

USE PROVEN TECHNOLOGY FOR REDUCING VULNERABILITY IN THE BUILT ENVIRONMENT(E.G., ENERGY DISSIPATION)

OBJECTIVES


Processes for becoming earthquake resilient l.jpg

INCREASED PUBLIC AWARENESS

IMPROVED PROFESSIONAL EDUCATION AND TRAINING

EXPANDED MONITORING AND WARNING SYSTEMS

MODERN BUILDING CODES FOR NEW BUILDINGS

MODERN STANDARDS FOR NEW INFRASTRUCTURE

STRENGTHENING AND RETROFIT FOR EXISTING STRUCTURES

EXPANDED INTERNATIONAL COOPERATION

PROCESSES FOR BECOMING EARTHQUAKE RESILIENT


Starting points l.jpg

IN-COUNTRY BASIC AND APPLIED RESEARCH

LESSONS FROM THE OCTOBER 8, 2005 DISASTER

MAPS

INFORMATION

GUIDELINES FOR APPLICATIONS BY EMERGENCY MANAGERS, BUILDING OFFICIALS, AND URBAN PLANNERS

STARTING POINTS


Lessons from pakistan earthquake l.jpg

LESSONS FROM PAKISTAN EARTHQUAKE

  • THE EARTHQUAKE OCCURRED ALONG THE MAIN BOUNDARY THRUST ZONE (MBT).

  • THE MBT RUNS ALONG THE HIMALAYAN ARC FOR ABOUT 2,500 KM..


Lessons from pakistan earthquake10 l.jpg

LESSONS FROM PAKISTAN EARTHQUAKE

  • CONSTRUCTION WAS MAINLY CONCENTRATED ON THE FLOOD- PLAIN DEPOSITS OF THE NEEHLAN, JAHLUM, AND KUNHAR RIVERS.

  • BUILDINGS IM MUZAFFARABAD SITED ON SAND AND GRAVEL DEPOSITS WERE SEVERELY DAMAGED.

  • BUILDINGS SITED ON ROCK WERE NOT SEVERELY DAMAGED.


Slide11 l.jpg

  • HAZARD MAPS

  • INVENTORY

  • VULNERABILITY

  • LOCATION

  • MITIGATION

  • PREPAREDNESS

  • EMERGENCY RESPONSE

  • RECOVERY and

  • RECONSTRUCTION

RISK ASSESSMENT

RISK MANAGEMENT

ACCEPTABLE RISK

RISK

UNACCEPTABLE RISK

TOWARDS EARTHQUAKE RESILIENCE

DATA BASES AND INFORMATION

COMMUNITY

HAZARDS: GROUND SHAKING GROUND FAILURE SURFACE FAULTING TECTONIC DEFORMATION TSUNAMI RUN UP AFTERSHOCKS


Slide12 l.jpg

IMPORTANCE AND VALUE OF STRUCTURE

EXPOSURE MODEL

VULNERABILTY MODEL

SEISMOTECTONIC SETTING

LOCATION OF STRUCTURE

QUALITY OF DESIGN AND CONSTRUCTION

RESISTANCE TO LATERAL FORCES

POLITICAL PROCESS

MITIGATION COSTS

EXPERIENCE AND RESEARCH

DAMAGE ALDORITHM

INCORPORATE NEW KNOWLEDGE

INSPECTION AND REGULATION

EARTHQUAKE HAZARDS MODEL

ACCEPTABLE RISK

IMPLEMENTATION OF SEISMIC SAFETY POLICY

ASSESSMENT OF RISK


Options for earthquake disaster resilience l.jpg

OPTIONS FOR EARTHQUAKE DISASTER RESILIENCE

WHAT IS THE BENEFIT/COST OF EACH ONE?

HOW QUICKLY CAN EACH OPTION BE IMPLEMENTED?


Benefit cost l.jpg

BENEFIT/COST

BUILDING CODE WITH SEISMIC DESIGN PROVISIONS

PREVENTS COLLAPSE AND REDUCES LOSS OF LIFE AND DAMAGE

1 < BENEFIT/COST < 1,000


Benefit cost15 l.jpg

BENEFIT/COST

STANDARDS FOR LIFELINE SYSTEMS

PROTECTS COMMUNITY INFRASTRUCTURE

1 < BENEFIT/COST < 1,000


Benefit cost16 l.jpg

BENEFIT/COST

DEMOLITION OF COLLAPSE HAZARD BUILDINGS

PREVENT COLLAPSE AND LOSS OF LIFE

1 < BENEFIT/COST < 1,000


Benefit cost17 l.jpg

BENEFIT/COST

SEISMIC ZONATION

AVOIDS LOCATIONS MOST SUSCEPTIBLE TO STRONG SHAKING, SURFACE FAULTING, SOIL AMPLIFICATION, AND SOIL FAILURE

1 < BENEFIT/COST < 100


Benefit cost18 l.jpg

BENEFIT/COST

RETROFIT AND STRENGTHENING

PREVENT COLLAPSE; ELIMINATE VULNERABILITIES; REDUCE DAMAGE

1 < BENEFIT/COST < 100


Benefit cost19 l.jpg

BENEFIT/COST

EDUCATION AND TRAINING TO IMPLEMENT CHANGE

EXPANDS PROFESSIONAL AND POLITICAL CAPACITY

1 < BENEFIT/COST < 100


Benefit cost20 l.jpg

BENEFIT/COST

SOILREMEDIATION

PREVENTS LIQUEFACTION, LANDSLIDES, AND LATERAL SPREADS

1 < BENEFIT/COST < 100


Benefit cost21 l.jpg

BENEFIT/COST

PERFORMANCE BASED DESIGN

PREVENTS LOSS OF FUNCTION AND USE OF MOST IMPORTANT STRUCTURES

1 < BENEFIT/COST < 100


Benefit cost22 l.jpg

BENEFIT/COST

URBAN AND LAND-USE PLANNING

FACILITATES AVOIDANCE STRATEGIES

1 < BENEFIT/COST < 10


Benefit cost23 l.jpg

BENEFIT/COST

DISASTER SCENARIONS

FACILITATES PREPARATION FOR EXPECTED AND UNEXPECTED

1< BENEFIT/COST < 10


Benefit cost24 l.jpg

BENEFIT/COST

RELOCATION AND REROUTING

REDUCES LIKELIHOOD OF DAMAGE AND LOSS

1< BENEFIT/COST < 10


Benefit cost25 l.jpg

BENEFIT/COST

NON-STRUCTURAL MITIGATION

PROTECTS CONTENTS AND EQUIPMENT

1 < BENEFIT/COST < 1,000


Slide26 l.jpg

  • HAZARD MAPS

  • INVENTORY

  • VULNERABILITY

  • LOCATION

  • MITIGATION

  • PREPAREDNESS

  • EMERGENCY RESPONSE

  • RECOVERY and

  • RECONSTRUCTION

RISK ASSESSMENT

RISK MANAGEMENT

ACCEPTABLE RISK

RISK

UNACCEPTABLE RISK

TOWARDS EARTHQUAKE RESILIENCE

DATA BASES AND INFORMATION

COMMUNITY

HAZARDS: GROUND SHAKING GROUND FAILURE SURFACE FAULTING TECTONIC DEFORMATION TSUNAMI RUN UP AFTERSHOCKS
