Presentation Transcript

Slide2 l.jpg

The Earth’s crust is broken into about 12 rigid plates, which slide over a semi-molten plastic layer of the mantle.


Slide3 l.jpg

Tectonic Plates on Modern Earth which slide over a semi-molten plastic layer of the mantle.


There are three types of plate boundaries l.jpg
There are three types of plate boundaries: which slide over a semi-molten plastic layer of the mantle.

  • 1- Convergent

  • 2- Divergent

  • 3- Transform


Slide5 l.jpg

1. Convergent (aka subduction zone) boundaries – where one plate overrides another plate. Each plate is bounded by some combination of these three plate boundary types.

2. Divergent (aka spreading) boundaries – where plates are moving apart

3. Transform fault boundaries – where plates are moving past each other


Slide7 l.jpg

The material making up the plates can be divided in two types:

i. Oceanic crust

ii. Continental crust


Slide16 l.jpg

The driving force for plate tectonics is slow moving convection currents in the underlying

plastic mantle material.


Slide17 l.jpg


Slide18 l.jpg

How does convection work? No one knows—but they aren’t afraid to propose models!

Whole-mantle convection

Two mantle convection cells

Complex convection



Slide20 l.jpg

1600 - development of a comprehensive world map (missing details of some continents such as

Australia and Antarctica).

1620 - Francis Bacon noted the similarity of the shape of the continents on either side of the

Southern Atlantic – Africa and South America.


Slide21 l.jpg

1666 - details of some continents such as Francois Placet suggested that prior to the Great Flood the land was undivided by

oceans and that the Atlantic formed when Atlantis sank.

1858 - Antonio Snider developed a theory that when the Earth cooled from a molten mass

continents formed only on one side. This created instability causing the Americas to be

pulled away from the rest of the continents.


Slide22 l.jpg

1879 – details of some continents such as Sir George Darwin said that the Pacific Ocean was the scar left behind when the Moon

pulled away from the Earth. After this happened, the continents moved to create a

balanced planet.

1890s- Edward Suess suggested that at one stage all the continents were joined as one massive

continent, which he called Gondwana. His evidence for this was the location of

mountain ranges and common fossils.


Slide23 l.jpg

1924 - details of some continents such as Alfred Wegener developed the theory of Continental Drift to explain the similarities of

rocks, fossils and other geological structures on either side of the Atlantic. At this time it

was accepted that the continents sat like icebergs on the mantle and as the continents

eroded they rose out of the mantle. Wegener suggested as well as moving up and down

in the mantle, continents could move sideways in the mantle.

-Wegener was a meteorologist and his theory was not well accepted. (He died on an

expedition in Greenland collecting ice samples).


Slide24 l.jpg

1928 - details of some continents such as Arthur Holmes suggested that convection currents in the mantle as the driving force of

continental drift. He had no evidence to support his theory.

1950s- Extensive mapping of the ocean floor, especially the Mid-Atlantic Ridge.

1960s- Harry Hess suggested that sea floor separates at the mid-oceans ridges and new sea floor

is created by up welling of the mantle.

1970s- Theory of plate tectonics well accepted.


Slide25 l.jpg

Earth ~200 million years ago details of some continents such as


Day 2 l.jpg
Day 2 details of some continents such as


Continental drift evidence l.jpg
Continental Drift: Evidence details of some continents such as

  • Geographic fit of South America and Africa

  • Fossils match across oceans

  • Rock types and structures match across oceans

  • Ancient glacial features

  • Earthquake Patterns

  • Volcano Patterns


Slide30 l.jpg

Continental details of some continents such as

Drift:

Evidence

Tight fit of

the continents, especially using

continental shelves.


Slide31 l.jpg

Continental Drift: Evidence details of some continents such as

Fossil critters and plants


Slide32 l.jpg

Continental Drift: Evidence details of some continents such as

Correlation of mountains with nearly

identical rocks and structures


Slide33 l.jpg

Continental details of some continents such as

Drift:

Evidence

Glacial features

of the same age

restore to a

tight polar

distribution.


The rise of plate tectonics l.jpg
The Rise of Plate Tectonics details of some continents such as

WW II and the Cold War: Military Spending

U.S. Navy mapped seafloor with echo sounding (sonar) to find and hide submarines. Generalized maps showed:

oceanic ridges—submerged mountain ranges

fracture zones—cracks perpendicular to ridges

trenches—narrow, deep gashes

abyssal plains—vast flat areas

seamounts—drowned undersea islands

Dredged rocks of the seafloor included only basalt, gabbro, and serpentinite—no continental materials.


Slide38 l.jpg

The Rise of Plate Tectonics details of some continents such as

Hypothesis: Stripes indicate periodic reversal of the direction of Earth’s magnetic field.

To test this hypothesis, scientists determined the eruptive ages AND the polarity of young basalts using the newly developed technique of K-Ar radiometric dating.

The study validated the reversal hypothesis...


Slide39 l.jpg

The Rise of details of some continents such as

Plate Tectonics

And then (1962-1963) geologists realized that the patterns are SYMMETRICAL across oceanic ridges.

The K-Ar dates

show the youngest

rocks at the ridge.


The rise of plate tectonics40 l.jpg
The Rise of Plate Tectonics details of some continents such as

Meanwhile, U.S. military developed new, advanced seismometers to monitor Soviet nuclear tests.

By the late 1950s, seismometers had been deployed in over 40 allied countries and was recording 24 hrs/day, 365 days/year.

Besides the occasional nuclear test, it recorded every moderate to large earthquake on the planet. With these high-precision data, seismologists found that activity happens in narrow bands.



Slide42 l.jpg

Divergent boundaries: Chiefly at oceanic ridges details of some continents such as

(aka spreading centers)


Slide43 l.jpg

How magnetic reversals form at a spreading center details of some continents such as



Slide45 l.jpg

How rifting of a continents

continent could lead to formation of

oceanic lithosphere.

e.g., East Africa Rift

e.g., Red Sea

e.g., Atlantic Ocean


Slide46 l.jpg

Presumably, continents

Pangea was ripped apart by such continental

rifting & drifting.


Slide47 l.jpg

Subduction zones continents form at convergent boundaries if at least one side has oceanic (denser) material.

Modern examples: Andes, Cascades

Major features: trench, biggest EQs, explosive volcanoes


Slide48 l.jpg

Another subduction zone—this one with continents

oceanic material on both sides.

Modern example: Japan


Slide49 l.jpg

Earthquake continentsdepth indicates subduction zones


Slide50 l.jpg

Collison zones continents form where both sides of a convergent boundary consist of continental (buoyant) material.

Modern example: Himalayas

This probably used to be a subduction zone,

but all the oceanic material was subducted.


Slide52 l.jpg

Most continentstransform boundaries

are in the oceans.

Some, like the one in California, cut continents.

The PAC-NA plate boundary is MUCH more complex than this diagram shows.


Slide53 l.jpg

Hotspots, such as the one under Hawaii, continents

have validated plate tectonic theory.
