Metr 51 scientific computing ii lecture 9 lidar plotting techniques

Metr 51: Scientific Computing IILecture 9: Lidar Plotting Techniques

Allison Charland

3 April 2012


Reminder

Reminder

  • Two weeks of Matlab left!

  • Matlab Final will be on April 19th

  • Then on to HTML and creating a personal webpage


Metr 51 scientific computing ii lecture 9 lidar plotting techniques

Doppler Lidar Theory

Movement of aerosols by wind

Infrared light reflected from aerosols

Emitted infrared light

The shift in frequency of the return echo is related to the movement of aerosols. The faster the aerosols move, the larger the shift in frequency. From this, the wind speed relative to the light beam can be measured.


Doppler wind lidar

Doppler wind lidar

  • Halo Photonics, Ltd. Stream Line 75

  • 1.5 micron

  • Eye-safe

  • 75 mm aperture all-sky optical scanner

  • Min Range: 80 m

  • Max Range: 10km

  • 550 user defined range gates (24 m)

  • Temporal resolution: 0.1-30 s

  • Measurements:

    • Backscatter Intensity

    • Doppler Radial Velocity


Lidar scanning techniques

Lidar Scanning Techniques

30o

70o

95o

  • Multiple elevation and azimuth angles can be adjusted to create different types of scans.

    • DBS (Doppler Beam Swinging):

      • Wind Profile

    • Stare: Vertically pointing beam

    • RHI (Range Height Indicator):

      • Fixed azimuth angle with varying elevation angles

    • PPI (Plan Position Indicator):

      • Fixed elevation angle with varying azimuth angles


Dbs data

DBS Data

Date & Time(UTC)

Height (m AGL)

Wind Direction & Wind Speed (ms-1)

  • Remove 225 heading

  • Use load to read in the data then create wind speed and direction profiles.

  • What if you have multiple files that you want to plot using one code?


Plotting multiple profiles

Plotting multiple profiles

  • You have three files that you want to plot: wind_profile_0900PST.txt, wind_profile_1200PST.txt, and wind_profile_1500PST.txt

  • Create a character string array called filenames

    filenames = [‘wind_profile_0900PST.txt’;…

    ‘wind_profile_1200PST.txt’;‘wind_profile_1500PST.txt’];

    Hint: filenames must all be the same character length

  • Create a variable for the number of files you have

    Num = 3;


Plotting multiple profiles1

Plotting multiple profiles

  • Now you want to create a for loop that will go from 1 to the number of files you have and load and plot each file.

  • Each time you loop through you want to reset the filename that is being read.

  • Set your values of height, wind direction and wind speed.

  • Plot your variables.

  • Clear variables so that the next time through the loop they will be replaced.


Plotting multiple profiles2

Plotting multiple profiles

for i =1:Num

f = filenames(i,:);

load f;

data = f;

clear f;

height = data(:,1);

wind_dir = data(:,2);

wind_speed = data(:,3);

figure(1);clf;

plot(wind_dir, height, ‘+k’); hold on;

plot(wind_speed, height, ‘k’); hold on;

clear data; clear height; clear wind_dir; clear wind_speed;

end %for


Plotting multiple profiles3

Plotting multiple profiles

  • To plot each profile as a separate figure replace figure(1);clf; with figure(i);clf;

  • To save each figure as a jpeg, use saveasafter your figure is complete

    figure_name = [‘profile_’i’.jpg’];

    saveas(gcf,figure_name);

  • Each time through the loop the figure_name will be reset and saved with the new number i.


Stare lidar data

Stare Lidar Data

Date & Time(UTC) There is one data file per hour


Stare data

Stare Data

  • The load command cannot be used for stare data because the number of columns changes throughout the data file from 3 to 4 after each scan.

  • Fastest way to plot stare data is using xlsread

  • This reads in an excel spreadsheet then later using loops the data can be separated into specific variables.

  • The first step is to load the stare data file into excel space delimited then save it as an excel file with the extension .xlsx (for Microsoft 2010).


Stare data1

Stare Data

  • Before loading the data, set up the height array.

  • Heights will always be the same throughout a stare file.

  • height = 0:225;

  • height = (height + 0.5)*24;

  • height = height';


Stare data2

Stare Data

  • Read in the datafile

  • data = xlsread(filename.xlsx);

  • j = hour; %The hour of the particular data file

  • fprintf('Completed %2.0f \n', j)

  • Set conditions for start of data columns

  • c1=2;

  • if j > 1

  • k=17;

  • p=18;

  • elseif j==1

  • k=9;

  • p=10;

  • end

  • if j >= 4

  • c1=1;

  • end %if

  • if j >= 18

  • c1=2;

  • end %if


Splitting the data

Splitting the data

count = 0;

n = 2100;

for i=1:n

count = count +1;

time(count) = data(k,c1);

k=k+226;

V = data(p:p+100,3)';

V_2 = data(p+100:p+224,2)';

V_new(count,:) = [V V_2];

B = data(p:p+100,4)';

B_2 = data(p+100:p+224,3)';

B_new(count,:) = [B B_2];

p=p+226;

end %for

fprintf('Completed split \n')


Stare data3

Stare Data

  • Change time from UTC to PST

  • Depends on Daylight Savings

  • for w = 1:length(time)

  • if time(w) < 7;

  • time(w) = 24 - (7-time(w));

  • else

  • time(w) = time(w)-7;

  • end %if

  • end %for


Transpose the data

Transpose the data

Transpose the data

B_new = B_new';

V_new = V_new';

time =time' ;


Plotting stare data

Plotting Stare Data

figure(1);clf;

pcolor(time,height,V_new);hold on;

shading interp;

ylim([0 2400])

xlabel('Time (PST) ');

ylabel('Height (m AGL)');

title('Vertical Velocity (m s^-^1)')

caxis([-5 4])

colorbar

Show Example


Stare data4

Stare Data

  • The example shown is the raw data.

  • A filter algorithm can be used to eliminate invalid data including near the surface and aloft where the signal is no longer retrieved.

  • The algorithm code will be available on D2L.

  • Multiple files could be read in and plotting using the same technique as earlier to plot multiple wind profiles.

  • The problem is that the figures created will have so much detail that there may be issues copying them.
