  1. Sybase ASE: DB Fragmentation Rev. 6.2012 Sybase Administration Tools available at: http://andrewmeph.wordpress.com mailto: andrew.me.ph@gmail.com

  2. Note and disclaimer: • The tools posted on the blog will require the same setup: • Sybase Client installed (for tools connecting to ASE server). • Administrative login user (for tools doing ASE administration). • A set of two or more .dll files supplied with the installation – performing licensing and environment operability checks. • All the tools have been tested to run bug-free. Nonetheless, the tools are provided “as is.” Responsibility for running a tool lies with the user. Comments and bug reports are welcome. They will be addressed and rectified. Please send the comments either directly by mail or through the blog. • As with any tool, it is recommended to start using it in the development environment before trying it on the Production Server.

  3. DB fragmentation: Quick info Every DBA knows that most DB operations are performed in pages. But few really know how their tables are organized. How many pages a “hot” table occupies? How many extents? Allocation Units? Beyond the [data/index] cluster ratio reported by OPTDIAG, how dispersed are the pages within extents, allocation units? Does it matter at all? DB Fragmentation analyzer opens a window into DB internals: • It allows to check each table’s fragmentation beyond the page level – on the level of extents and allocation units. • It allows to walk through table page chains to see how ordered the chain is. • It allows to take a decision on selecting tables for maintenance on a level more sophisticated than data/index clustered ratio. • It allows to inspect what different lock schemes, partitioning options do with data in tables. • It is for those curious to see beyond the limitation of a database page and those who take IO (and optimizer) seriously.

  4. DB fragmentation: FAQ DB Fragmentation Assistant Pre-requisites: • Must be run as sa user. • ODBC and Open Client aliases must be the same (synchronize DSEDIT and DSN SRV names before running the tool). • For large tables, it is recommended to skip page linkage test since this will be too time-consuming and heavy. DB Fragmentation Assistant Features: • [Esc] keyboard key aborts operation at any step. • Information collected by the tool may be verified by DBCC TABLEALLOC and DBCC INDEXALLOC commands.

  5. DB fragmentation: startup [Fragmentation Assistant] tab is designed to specify tables one wants to analyze. • Filter tables by name or choose a single table. • Click “Load Tables”. • Double click on the selected table so that its OAM and FIRST pages are listed correctly. • Leave “OAM Only” checked for large tables. • Click on the Walk Selected button.

  6. DB fragmentation: WALK Single When you “walk” through table pages the following data is displayed: • Data Cluster Ratio • Index Cluster Ratio • Large IO Efficiency • Number of Allocation Pages a table occupies (PG/AU Ratio) • Number of Extents a table occupies (PG/EX Ratio) • If Page Chain is checked, fragmentation % is calculated (how many linkage leaps across extents are there). By the end of each check one gets a full picture of how the specified table is materialized in terms of database pages.

  7. DB fragmentation: WALK ALl It is possible to walk through a single table or a group of tables: • Write filter for table name. • Load Tables. • Delete unwanted tables from the list [DEL keyboard key]. • Click “Walk All” button. When all the tables will be walked through, you will get a report in the Operation Log tab listing all the information collected for all the tables (exportable to .csv).

  8. DB fragmentation: page details During the walk, you will get a list of pages that has been walked through. Double click on the row for a particular page will display that page details.

  9. DB fragmentation: LOG Operation Log looks like this:

  10. DB fragmentation: feedbacks • The tool is being reworked from time to time to address changes in the ASE and align it better with ASE administrators needs. • In order to make the software better and more convenient your feedback is encouraged. • Feedback and bug reports may be made either directly to andrew.me.ph@gmail.com or posted as comments to the tool page published on the wordpress.com blog. • The blog is available at http://andrewmeph.worpress.com. • More tools are available there, as well as general comments on Sybase ASE, RS (and in future IQ) products. • You are welcome to post your own ideas there which may be later transformed into customized tools and posted there for download.
