  1. Benign bone tumors DR: Gehan mohamed

  2. Benign bone tumors • Osteoma • osteoid osteoma • giant osteoid osteoma (osteoblastoma) • osteochondroma

  3. Definition of osteoma: • A benign tumor composed of bony tissue, often developing from the skull.

  4. Osteoma in the frontal sinus

  5. Osteoma :formed of bone

  6. osteoma

  7. Osteoid Osteoma • An osteoid osteoma is a benign (non-cancerous), small tumor that usually grows in the long bones of a person. • Cell of origin : osteoblast. • Signs/Symptoms: • Pain specially at night relieved by NSAID and eliminated by excision. • Age: • 10-30 years • Sex: • M > F (2:1) • Anatomic Distribution: • It arises in the Metaphysis of bones • Over 50% of cases in femur or tibia • Nearly every location, most frequent in femur, tibia, humerus, bones of hands and feet, vertebrae and fibula

  8. Osteoid osteoma :Central radiolucent nidus surrounded by thickened sclerotic bone

  9. Osteoid osteoma :Central hemorrhagic nidus surrounded by dense rim of sclerotic bone

  10. Histopathologic picture of osteoid osteoma: • It is formed of : - osteoid which is the unmineralized, organic portion of the bone matrix that forms prior to the maturation of bone tissue. - irregular bone trabecula

  11. Histologic features of osteoid osteoma: the nidus of an osteoid osteoma demonstrates irregular masses of eosinophilic osteoid matrix (white arrow) and intensely stained bone trabeculae (black arrow) rimmed by osteoblasts (arrowhead).

  12. Osteoid osteoma: formed of woven bone trabecula and osteoid

  13. Osteoid Osteoma • Prognosis/Treatment: • Surgical excision is treatment of choice • Recurrence can occur with incomplete excision of the tumor.

  14. Osteoblastoma (Giant Osteoid Osteoma) • It is similar with osteoid osteoma in histology • But osteoblastoma differ in : Anatomic Distribution: - Predilection for vertebral column than long bones so Tumors of the spine can cause scoliosis and neurological symptoms. The lesion may clinically present with myleopathic and/or radicular symptoms. - much larger size (more than 2 cm up to 11.0 cm)

  15. Osteochondroma

  16. Exostosis (Osteochondroma) • Is a benign tumor . • Also known as exostosis • Children and teenagers most affected, Male >> female. • Clinically appear as slowly growing masses, painful if press on nerve tissue • Solitary or multiple • Multiple Hereditary Exostosis autosomal dominant disease with inactivation of both copies of EXT gene in growth plate chondrocytes

  17. Osteochondroma • Benign projection of bone with cartilaginous cap • Occurs in epiphyseal plate and grows laterally • Exhibits cortex and medullary portion • Conversion to sarcoma rare (<1%) but higher in patients with hereditary syndrome. • May convert to malignancy if cartilage cap becomes thicker and contains disorganized calcifications

  18. Osteochondroma • Develops in bones of endochondral origin and arises from the metaphysis near the growth plate of long tubular bones. • Occasionally develops from bones of the pelvis, scapula and ribs. • Ultrasound safe and inexpensive way to evaluate thickness of cartilaginous capsule • MRI method of choice to evaluate thicknesss of cartilaginous cap to rule out malignant conversion

  19. - Radiograph can demonstrate that cortex of osteochondroma blends with cortex of normal bone

  20. Osteochondroma:it consists of : -Fibrocartilagenous cap on top -Newly made bone trabecula Forms inner portion Medullary cavity of osteochondroma and bone are continuous
