Federal radionavigation plan public meeting faa headquarters washington dc 19 may 2003

Ongoing Loran Evaluations at theFederal Aviation Administration and theUS Coast GuardMitchell J. NarinsSystems EngineerFederal Aviation AdministrationNavigation Integrated Product Team

Federal Radionavigation Plan

Public Meeting

FAA Headquarters, Washington, DC

19 May 2003


Purpose of the evaluations
Purpose of the Evaluations

  • To determine whether an enhanced Loran system can provide the:

    • Accuracy

    • Availability

    • Integrity, and

    • Continuity

      a) to support Lateral Navigation through all phases of flight – including Non-Precision Approach (NPA)

      b) to support Harbor Entrance and Approach (HEA) for maritime

  • To determine what other ancillary benefits can be derived from the continued provision of enhanced Loran services

    • e.g., to support Stratum 1 timing and frequency users

  • To determine if provision of enhanced Loran services are cost-beneficial


North american loran system

TTX Stations:11 US, 1 Canadian

SSX Stations:13 US, 4 Canadian

LSU

Control Stations

North American Loran System


Program Participants

  • Government

    • FAA

      • Navigation Systems Engineering, AND-702

      • Navigation and Landing System Architecture, ASD-140

      • CNS Test and Evaluation, ACT-360

      • Flight Standards, AFS-400

      • Aircraft Certification, AIR-130

      • Special Programs, AVN-5

    • US Coast Guard

      • Aids to Navigation

      • Navigation Center

      • Loran Support Unit

    • Volpe National Transportation System Center


Industry

Booz|Allen|Hamilton

Free Flight Systems

Illgen Simulation Technologies, Inc.

JJMA

Locus, Inc.

Megapulse, Inc.

Peterson Integrated Geopositioning

Reelektronika

Rockwell Collins

WR Systems

Academia

Ohio University

Stanford University

US Coast Guard Academy

University of Rhode Island

University of Alaska

University of Wales

Program Participants


Aviation requirements rnp 0 3 target rnp 0 5 minimum
Aviation Requirements: RNP* 0.3 (target); RNP* 0.5 (minimum)

Performance RequirementValue

  • Accuracy (target) 307 metersAccuracy (minimum) 802 meters

  • Alarm Limit (target) 556 metersAlarm Limit (minimum) 926 meters

  • Integrity 10-7/hour

  • Time-to-alarm 10 seconds

  • Availability (minimum) 99.9%Availability (target) 99.99%

  • Continuity (minimum) 99.9%Continuity (target) 99.99%

    (Source: FAA Loran Evaluation Report, June 2002)

*Required Navigation Performance


Marine hea requirements primary
Marine HEA Requirements (Primary)

Performance RequirementValue

  • Accuracy (target) 10 meters, 95%Accuracy (threshold) 20 meters, 95%

  • Alarm Limit (target) 25 metersAlarm Limit (threshold) 50 meters

  • Integrity (target) 3x10-5

  • Time-to-alarm 10 seconds

  • Availability (threshold) 99.7%Availability (target/VTS) 99.9%

  • Continuity (threshold) 99.85% over 3 hours

    Continuity (target) 99.97% over 3 hours

    (Sources: FRP, DOT Task Force, TASC DGPS Mission Needs Analysis: Harbor Entrance and Approach, IMO Resolutions A.815(19) and draft revisions to A.860(20))


Marine hea requirements backup
Marine HEA Requirements (Backup)

Performance RequirementValue

  • Accuracy (backup) 20 meters, 95%

  • Alarm Limit (backup) 50 meters

  • Integrity (target) 3x10-5

  • Time-to-alarm 10 seconds

  • Availability (minimum) 99.7%

  • Continuity (minimum) 99.85% (over 3 hours)

    (Sources: FRP, DOT Task Force, TASC DGPS Mission Needs Analysis: Harbor Entrance and Approach, IMO Resolutions A.815(19) and draft revisions to A.860(20))


Timing and frequency specifications
Timing and Frequency Specifications

Performance SpecificationValue

  • Frequency Accuracy (threshold) 1 in 1012 (averaged over 24 hrs)

  • No External Antenna (desired)

  • Backward Compatibility (desired)

  • Integrity Data Minimum of USE/NO USE Flag

  • Higher Accuracy Time of Day Time Tag (Year/DOY/Second)

    Leap Second information

  • Timing Accuracy <100nsec

  • Differential Data Daily Correction

    (Source: DOT Task Force, T1X1 letter of Oct 2002)


Timing user spectrum

0.1 ns

1 ns

10 ns

100 ns

1 µs

10 µs

100 µs

1 ms

10 ms

100 ms

1 s

PTTI/R&D

- NIF

Scientific/

Experimental

  • High Precision Military

  • GPS Monitor Stations

  • GPS Weapons

  • AT3 Airborne Geolocation Demo

  • Bistatic Radar

  • Other Applications

National Timing Labs

Advanced Comms

  • Power Systems

  • Fault Location

  • Phasor Meas

  • Data Sharing

CDMA2000

- Base Stations

  • Low Precision Military

  • Ground Terminals

  • VHF Special Comms

  • Wide Area Data Logging

  • Seismic monitoring

  • Nuclear Blast Detection

  • Digital Time Servers

  • NTP, etc

Timing user survey not intendend to be a complete representation of all users. Requirements have been generalized and averaged over user groups

Astronomy

  • Authentication

  • Internet login

Financial Transactions

Could be served by eLORAN

Timing User Spectrum


Frequency user range

10-15

10-14

10-13

10-12

10-11

10-10

10-9

10-8

10-7

10-6

10-5

VLBI

National Timing Labs

  • High Precision Military

  • GPS Monitor Stations

  • Various Applications

  • High Precision Metrology

  • Equipment Calibration

  • Stratum 1 Comms

  • Telcos

  • Military GT

  • Digital Wideband

CDMA2000

- Base Stations

  • Low Precision Metrology

  • Equipment Calibration

  • Low Precision Military

  • Combat Control Systems

  • Oscillator Manufacturers

  • Cal of low-cost xtal

  • Misc

  • Broadcast TV

  • Digital Modular Radio

  • IEEE P802.16 Wireless

Frequeny user survey not intendend to be a complete representation of all users. Requirements have been generalized and averaged over user groups

Could be served by eLORAN

Frequency User Range


Loran c navigation current capabilities future needs
Loran-C NavigationCurrent Capabilities/Future Needs*

Note: Most stringent requirements shown in aviation orange.

* Includes Stratum 1 timing and frequency capability.



Status of ongoing loran evaluations and system recapitalization

Status of Ongoing Loran Evaluations and System Recapitalization

  • Accuracy

    • Availability

      • Integrity

        • Continuity

Final Report due to the Departments of Transportation and Homeland Security

March 2004


Loran Evaluation Activities

  • To determine Loran Accuracy Potential:

    • ASF* studies and calibration (for both conductivity and terrain)

    • Receiver/Integrated receiver studies

    • Loran Accuracy Performance Panel (LORAPP)

    • Differential Loran study

  • To determine Loran Availability Potential:

    • H-Field Antenna/P-static testing

    • CONUS All-in-view receiver analysis

    • Noise analysis

    • SSX and TFE modification evaluations

  • To determine Loran Integrity Potential:

    • Loran Integrity Performance Panel (LORIPP)

    • Time of Transmission/ASF studies

  • To determine Loran Continuity Potential:

    • Receiver/Integrated receiver/antenna studies

*additional secondary factors


Loran Issue 1: Accuracy

  • Current Accuracy: 0.25 nm, 2drms, 95%

  • Target Accuracy (NPA): 0.16 nm (307 m) - RNP 0.3

     0.43 nm (802 m) - RNP 0.5

  • Target Accuracy (HEA): 8 – 20 m, 2drms, 95%

    IssuesPotential Mitigations

    • Old timing sources New cesium clocks

    • Old timing equipment New timing suite

    • Tube technology Solid State Transmitter (SSX) technology

    • Simple propagation model New ASF* tables/algorithms

    • No real-time corrections LORAPP (Differential Loran)

      *additional secondary factors


Flights to support characterization of asfs conducted in august 2002 and march 2003
Flights to support characterization of ASFsConducted in August 2002 and March 2003


Typical results

Loran 2

Loran 7

Loran 7

Loran 1

~9.0 m

~3.0 m

GPS 1

GPS 7

Loran 3

GPS 8

~6.0 m

GPS 3

Loran 8

GPS 2

GPS 7

~13.0 m

~6.5 m

~2.0 m

Typical Results

NPA Requirement: 307 m !


Loran Issue 2: Availability

  • Current Availability:0.997

  • Target Availability (NPA): 0.999 - 0.9999

  • Target Availability (HEA): 0.997 – 0.999 

    IssuesPotential Mitigations

    • Precipitation Static H-Field Antenna*

    • Atmospheric Noise H-Field, AIV Receiver

    • Loss of Station Power UPS

    • Lightning New Lightning Protection

    • Chain/Stick Availability All-in-view receivers

    • Tube overloads Solid State Transmitters

      *Awaiting safety certification


Loran Issue 3: Integrity

  • Current Integrity: 10 sec. alert @ + 100ns or other specified error conditions

  • Target Integrity (NPA): 0.9999999*

    556m HPL, 10 sec. alert

  • Target Integrity (HEA): 0.99997**

    IssuesPotential Mitigations

    • Presumed Integrity/ Loran Integrity Panel (LORIPP)

      Auto Blink System Loran Accuracy Panel (LORAPP)

*For Aviation: The probability of providing Hazardous or Misleading Information (HMI) is 1 x 10-7

**For Maritime: The probability of providing Hazardous or

Misleading Information (HMI) is 3 x 10-5


Status of integrity hmi analysis
Status of Integrity (HMI) Analysis

  • Results to date:

    • Developed initial algorithms and fault-trees

      • Loran integrity

      • Horizontal protection limit (HPL)

      • Work continues

    • Analyzed RNP 0.3 performance

      • Appears feasible throughout CONUS

      • May require changes in the system infrastructure, policy, processes, etc.

      • May require continued operation of Canadian stations

      • Work continues

    • Analyzed RNP 0.3 approaches

      • May be feasible with the improved infrastructure

      • Work continues



Loran Issue 4: Continuity

  • Current Continuity: 0.997

  • Target Continuity (NPA): 0.999 - 0.9999

  • Target Continuity (HEA): 0.9985 – 0.9997

    IssuesPotential Mitigations

    Same as Availability plus:

    • Receiver acquisition time New DSP technology

      New SSX Switch Units

      AIV/Integrated Receiver



Prototype brassboard locus loran card installed in rockwell collins multi mode receiver
Prototype Brassboard Locus Loran Card Installed in Rockwell Collins Multi-Mode Receiver

  • Flight Testing to begin this month

  • Integrated GPS/Loran receiver for general aviation also being developed by Free Flight Systems and Locus


Summary
Summary Collins Multi-Mode Receiver

  • FY ’02 – Excellent progress, Goals achieved

    • LORIPP is well on its way to showing that aviation integrity requirements can be met

    • Flight tests showed that Loran can provide excellent accuracy (approaching GPS accuracies) when used in conjunction with appropriate ASF information

  • FY ’03 – Work continues:

    • Development of integrated prototype avionics and H-field antennas to evaluate Loran for all phases of flight in both stand-alone and multi-sensor configurations

    • Development of better ASF models that include spatial factors based on both conductivity and terrain factors and temporal factors based on multiple seasonal measurements

    • Publication of final H-Field/P-static test results

    • Publication of interim LORIPP and LORAPP findings

  • FY ’04 – Wrapping it up

    • 31 March 2004 – Final Report due to DOT and DHS
