Presentation Transcript


Slide1 l.jpg

SKULL BASE

REVIEW AND PATHOLOGY

Melissa Durand

Hartford Hospital Noon Conference

October 20, 2006


Slide2 l.jpg

Skull Base Anatomy Review

  • Skull Base Boundaries

  • Upper surface of ethmoid bones and orbital plate of frontal bone to the occiptal bone

  • Three Key Bones

  • Sphenoid

  • Temporal

  • Occipital


Slide3 l.jpg

Skull Base Anatomy Review

Temporal Bone

Temporal bone- petrous portion

Sphenoid Bone

Occipital Bone

  • Key Fissures

  • Petrosphenoidal fissure

  • Petrooccipital fissure

  • Key Sutures

  • Sphenosquamous Suture

  • Occipitomastoid Suture


Slide4 l.jpg

Skull Base Anatomy Review

  • Key Openings

  • Foramen spinosum

  • Foramen ovale

  • Foramen lacerum

  • Foramen rotundum

  • Foramen magnum

  • Foramen of vesalius

  • Jugular foramen

  • Superior orbital fissure

  • Inferior orbital fissure

  • Optic canal

  • Vidian canal

  • Hypoglossal canal

  • Pterygopalatine fossa


Slide5 l.jpg

Skull Base Anatomy Review


Slide6 l.jpg

Pterygopalatine fossa

Pterygoid canal

Foramen rotundum- higher level

Foramen ovale

Sphenoid spine- lower level

Petro-occipital fissure

Skull Base Anatomy Review

f. lacerum

Foramen spinosum


Slide7 l.jpg

Skull Base Anatomy Review

  • Foramen magnum

  • Medulla oblongata

  • Vertebral arteries

  • Anterior/Posterior spinal arteries

  • Hypoglossal canal

  • CN XII

  • Hypoglossal artery

*

*


Slide8 l.jpg

Skull Base Anatomy Review

  • Jugular Foramen

  • Pars nervosa: CN IX, inferior petrosal sinus

  • Pars vascularis: CN X, XI, jugular bulb

*

* Carotid canal


Slide9 l.jpg

  • Foramen Ovale

  • CN V3

  • Lesser petrosal nerve

  • Accessory meningeal artery

  • Emissary veins

  • Foramen of Vesalius

  • Emissary vein

  • Accessory meningeal artery- asc intracranial branch

Skull Base Anatomy Review

  • Foramen Spinosum

  • Middle meningeal artery/vein

  • CV V3, recurrent branch

  • Lesser superficial petrosal nerve


Slide10 l.jpg

Skull Base Anatomy Review

  • Foramen Lacerum

  • Ascending pharyngeal artery- meningeal branch

  • Nerve of pterygoid canal

  • Vidian Canal

  • aka pterygoid canal

  • Pterygopalatine fossa - foramen lacerum

  • Vidian nerve

  • Vidian artery


Slide11 l.jpg

Skull Base Anatomy Review

  • Foramen rotundum

  • CN V2

  • Artery of foramen rotundum

  • Emissary veins


Slide12 l.jpg

Skull Base Anatomy Review

  • Pterygopalatine Fossa

  • Pterygopalatine ganglia V2

  • Pterygopalatine plexus

  • Communicates with:

  • Inferior orbital fissure

  • Orbital apex

  • Sphenopalatine foramen

  • Pterygomaxilary fissure

  • Foramen rotundum

  • Vidian canal

  • Greater/lesser palatine canals and foramina


Slide13 l.jpg

Skull Base Anatomy Review

Cavernous Sinus

Receives:Superior opthalmic vein Inferior opthalmic vein Sphenoparietal sinus

Drains via: Petrosal sinuses Basilar plexus Pterygoid plexus

Connection: Circular sinus

Contains: CN III, IV, V1, V2, VI

  • Meckel’s Cave

  • Posterior aspect of cavernous sinus

  • Gasserian ganglion (sensory root ganglion of CN V)


Slide14 l.jpg

  • Inferior Orbital Fissure

  • Infraorbital artery, vein, and nerve (V2 branch)

  • Optic Canal

  • Optic nerve

  • Opthalmic artery

Skull Base Anatomy Review

  • Superior Orbital Fissure

  • CN III, IV, V1, VI

  • Middle meningeal artery- orbital branch

  • Recurrent meningeal artery

  • Superior opthalmic vein


Slide15 l.jpg

Skull Base Anatomy Review

  • Key Openings

  • Foramen spinosum

  • Foramen ovale

  • Foramen lacerum

  • Foramen rotundum

  • Foramen magnum

  • Foramen of vesalius

  • Jugular foramen

  • Superior orbital fissure

  • Inferior orbital fissure

  • Optic canal

  • Vidian canal

  • Hypoglossal canal

  • Pterygopalatine fossa


Slide16 l.jpg

Skull Base Pathology

Meningioma

Metastases

Myeloma

Neuroma

Schwannoma

Vascular Aneurysm

Chordoma

Chondrosarcoma

Dermoid tumors

Epidermoid tumors

Glomus tumors


Slide17 l.jpg

Case 1


Slide18 l.jpg

Chondrosarcoma

  • CT Findings:

  • Irregular, destructive mass

  • Centered off midline

  • Petro-occipital fissure

  • Calcifications, 70%; “rings/arcs”

  • MRI Findings:

  • Low T1 signal, high T2 signal

  • Enhance with contrast

  • Scalloped, well circumsribed margins


Slide19 l.jpg

Chondrosarcoma

  • Origin:

  • Preexisting cartilaginous lesion, synchondroses, cartilage endplates

  • Location:

  • Paranasal sinuses, skull base, parasellar region

  • Long bones, pelvis, sternum, ribs

  • Clinical:

  • 45 yo, median age

  • Classic, mesenchymal, or dedifferentiated


Slide20 l.jpg

Case 2


Slide21 l.jpg

Chordoma

  • CT/MRI Findings:

  • Expansile lytic lesion, midline

  • Well delineated mass arising from bone

  • Large soft tissue component

  • Variable calcification

  • Anteroposterior extension

  • Heterogeneous enhancement on T1, T2

  • Dark on T1, bright on T2

  • DDx:

  • Chondroma

  • Chondrosarcoma

  • Clivus meningioma


Slide22 l.jpg

Chordoma

  • Origin

  • Notochord remnants

  • Location

  • Clivus 35%

  • Sacrum 50%, Vertebral bodies 15%

  • Clinical

  • age 30-70

  • Slow growing, locally aggressive

  • CN VI- CN deficits

  • Mets late

  • Tx: surgery, radiation


Slide23 l.jpg

Case 3


Slide24 l.jpg

Glomus Tumor

  • Glomus jugulare CT/MRI Findings:

  • Center: jugular foramen

  • Limit: hyoid bone

  • Enhance w/ contrast

  • Salt and pepper appearance on MRI

  • Bone erosion


Slide25 l.jpg

Glomus Tumor

  • Origin:

  • Chemoreceptor cells

  • Location:

  • 10% multiple

  • glomus jugulare: jugular bulb

  • glomus tympanicum: cochlear promontory;

  • Clinical:

  • Pulsatile tinnitus

  • Hearing loss

  • arrythmia, BP fluctuation


Slide26 l.jpg

References

Erdem E, et al, “Comprehensive Review of Intracranial Chordoma”, Radiographics 2003; 23: 995-1009.

Grossman, R et al, Neuroradiology: The Requisites, Mosby, Philadelphia, 2003

Peretti P et al, “Chordoma”, www.emedicine.com/Radio/topic169.htm, 2005.

Pluta R et al, “Glomus Tumors”, www.emedicine.com/med/topic2994.htm, 2006.

Small J et al, “Chondrosarcoma”, http://brighamrad.harvard.edu/education/online/tcd/tcd.html.

Weissleder, R et al, Primer of Diagnostic Imaging, Mosby, Philadelphia, 2003

http://www.med.wayne.edu/diagRadiology/Anatomy_Modules/axialpages/Home_Page.html
