Optical phenomena

Optical Phenomena

How light can trick us


Naturally occurring phenomena

Naturally Occurring Phenomena

  • Apparent depth

  • Flattened sun and sunsets

  • Mirages

  • Shimmering

  • Rainbows


Apparent depth

Apparent depth

  • The depth that an object appears to be due to the refraction of light in a transparent medium

  • Eg. Looking into water from above

  • Light will refract away from the normal travelling from water into air because air is faster

  • Our brains don’t acknowledge that the light is refracted, so we extend the refracted ray straight back, creating a virtual source of the light rays


Apparent depth1

Apparent Depth

objects in water appear closer to the surface

pencil in water appears bent


Flattened sun

“Flattened” Sun

  • When the sun nears the horizon, it appears to be flattened during a sunset

  • Light from the bottom of the sun is refracted more than light from the top

  • This is because the air lower in the atmosphere is more dense, slowing the light more

  • Rays from the bottom of the Sun have a greater angle of incidence


Flattened sun1

Flattened Sun


Mirages

Mirages

  • A virtual image that forms as a result of refraction and total internal reflection in Earth’s atmosphere

  • This is the result of light travelling through different air temperatures

  • The index of refraction decreases as air gets warmer, causing the light to bend farther away from the normal

  • Total internal reflection occurs in the hottest layer, usually on the Earth’s surface

  • The ray travels back through to the cooler air and bends back toward the normal


Mirages1

Mirages

  • When the light reaches our eyes, we think it travelled in a straight line

  • This results in an image of the sky appearing to be on the pavement or sand


Mirages2

Mirages


Shimmering

Shimmering

  • Also caused by light refracting through different air temperatures

  • Air closer to the lake is warmer, so the light refracts in the same pattern as it does near hot pavement

  • Total internal refraction occurs in the lowest, warmest layer causing multiple virtual images on the water’s surface


Shimmering1

Shimmering


Rainbows

Rainbows

  • Rainbows are a result of the dispersion of white light into its 7 colour components

  • Remember: red light is refracted less than violet due to its speedROYGBIV

  • Rainbows are produced by water droplets

    3 steps:

    Dispersion of white light by the rain drop

    Partial internal reflection at the back of the rain drop

    Refraction of the light exiting the rain drop


Rainbows1

Rainbows

  • Our eyes see the final refraction, and projects these rays backwards to form a virtual image of a rainbow

  • You can only see a rainbow when the sun is behind you


Rainbow

Rainbow
