Presentation Transcript


Staggered prt practical considerations

Staggered PRTPractical Considerations

Sebastian Torres

CIMMS/NSSL

Technical Interchange Meeting

Spring 2005


Outline

BATCH MODE

STAGGERED PRT

Outline

  • Staggered PRT refresher

  • Choosing the PRTs

  • Away with the Batch Mode!

  • Ground clutter filter performance

Improvement in Doppler velocity retrieval using Staggered PRT


The staggered prt technique

T1

T2

T1

T2

time

`

Simple algorithm

The Staggered PRT Technique

  • Transmitter alternates two PRTs

    • T1 < T2, PRT ratio: k = T1/T2 = m/n

  • Maximum unambiguous range

    • Reflectivity: ra = ra2

    • Doppler velocity: ra = ra1

  • Maximum unambiguous velocity

    • Velocity Dealiasing Algorithm (VDA)

    • va = m va1 = n va2


Staggered prt pros and cons

Max. unambiguous velocity can be extended by means of a simple algorithm

Longer PRTs can be used to avoid overlaid echoes

Velocity fields are “clean”

Spectral processing is complicated due to non-uniform spacing of samples

Ground clutter filtering is a challenge

Longer PRTs may result in larger errors of estimates

Staggered PRT Pros and Cons


Choice of prts

Choice of PRTs

What are the magicalvalues of T1 and T2?


Choice of prts1

Choice of PRTs

  • How do we choose T1 and T2 for the operational environment?

  • Constraints

    • System limits

    • Range coverage

    • Design considerations

    • Errors of estimates


System limits

System Limits

  • Maximum RF duty cycle for the WSR-88D transmitter is 0.2%

    • Duty cycle = t /Ts

    • 1.57 ms/Ts≤ 0.002 => Ts≥ 780 ms

  • Signal processor memory allocation in the RVP-8 limits the number of range bins to 3072

    • Typical sample spacing: 1.67 ms (250 m)

    • 1.67 ms x 3072 = 5.12 ms => Ts≤ 5.12 ms


Range coverage i

Range Coverage (I)

  • Maximum unambiguous range

    • ra = cTs/2

    • The longer the PRT the better!

  • WSR-88D requirements:

    • Reflectivity up to 460 km

      • ra2≥ 460 km => T2≥ 3.07 ms

    • Doppler velocity up to 230 km

      • ra1≥ 230 km => T1 ≥ 1.53 ms


Range coverage ii

Range Coverage (II)

  • Actual requirements for intermediate to higher elevations can be relaxed

    • Most storms tops are below 18 km

    • For a height of 18 km, the slant range (r) is ~ 300 km at an elevation (qe) of 2.4 deg and ~ 150 km at 6 deg


Range coverage iii

Range Coverage (III)

  • Actual requirements for range coverage at intermediate elevations are300 km or less

  • For example

    • At 2.4 deg: ra1≥ 230 km => T1 ≥ 1.53 ms ra2≥ 300 km => T2≥ 2 ms

    • At 6.0 deg: ra1≥ 150 km => T1 ≥ 1 ms ra2≥ 150 km => T2≥ 1 ms


Design constraints

Design Constraints

  • Algorithm assumes T1 < T2

  • Preferred PRT ratio is k = 2/3

    • Fewest number of rules for the VDA

    • Spectral GCF performs best with this ratio (Sachidananda et al, 1999)

  • T1 / T2 = 2/3

  • Note: None of the existing PRTs in the WSR-88D satisfy this condition!

    • RVP-8 and 88D transmitter not limited to 8 PRTs

    • Possible ORPG impact

      • RDA/RPG ICD does not include the PRT

      • VCP definitions use PRT numbers


Errors of estimates

Errors of Estimates

  • Echo coherency is required for precise Doppler measurements

    • The spectrum width should be much smaller than the Nyquist interval

    • Median value of sv in severe storms is about 4 m/s

    • T1 < 2.2 ms

      • However, larger sv would require shorter T1


Acceptable prts

System limits

Range coverage

Design constraints

Signal coherency

PRT ratio

Acceptable PRTs

Acceptable PRTs

T1 = 1.5350 ms

T2 = 2.3025 ms


Errors of estimates1

Errors of Estimates

Can these values of T1 and T2 do the work?


Dealing with spaced pairs

T1

T2

T1

T2

R1

R2

R2

R1

time

Dealing with Spaced Pairs

  • Uniform PRT uses contiguous pairs

  • Staggered PRT uses spaced pairs

    • Usual formulas for the standard error of estimates have to be modified

    • Formulas for the spectrum width don’t even apply


Spectral moment estimators with staggered prt i

Staggered PRT assumes echoes don’t extend beyond ra2

T1

T2

I II I II III

Spectral Moment Estimators with Staggered PRT (I)

  • Reflectivity

    • Three zones:

      • I: Short PRT pulses only

      • II: All pulses

      • III: Long PRT pulses only

    • Zone II estimates are more accurate for large spectrum widths


Reflectivity errors

Reflectivity Errors

Solid lines: short (or long) PRT pulses only

Dashed lines: all pulses

SNR = 40 dB

DT = 60 msk = 2/3


Spectral moment estimators with staggered prt i1

Spectral Moment Estimators with Staggered PRT (I)

  • Velocity

    • v1 from short PRT pairs is dealiased using v2 from long PRT pairs

  • Spectrum Width

    • Depends on power and lag-1 autocorrelation estimates

      • Use short or long PRT lag?

      • Long PRTs will exhibit saturation for large spectrum widths


Velocity errors

Velocity Errors

Solid lines: short PRT pairs

Dashed lines: long PRT pairs

SNR = 40 dB

DT = 60 msk = 2/3


Spectrum width errors

Spectrum Width Errors

Solid lines: short (or long) PRT pulses for power

Dashed lines: all pulses for power

Lines without markers:short PRT pairs for autocorrelation

Lines with markers:long PRT pairs for autocorrelation

SNR = 40 dB

DT = 60 msk = 2/3


Replacing the batch mode

Replacing the Batch Mode

Can Staggered PRT performbetter than the Batch Mode?


Factors to consider

Factors to Consider

  • Range coverage

    • Different for Surveillance (reflectivity) and Doppler (velocity and spectrum width)

    • Must meet NEXRAD requirements but can be adjusted using maximum height of storms

  • Acquisition time

    • Dictated by antenna rotation rate

    • Must keep same or shorter dwell time

  • Errors of estimates

    • Must meet NEXRAD requirements


Vcp 11 scans using the batch mode

VCP 11 Scans using the Batch Mode


Range coverage i1

Range Coverage (I)


Range coverage ii1

Extended using long PRT powers

Range Coverage (II)

rad: short PRT

ras: long PRT

T1 = 2rad/c

T2 = 2ras/c

ras = (3/2) rad


Maximum unambiguous velocity

Maximum unambiguous velocity

Batch Mode

Staggered PRT


Acquisition time

Acquisition Time


Errors of estimates i

Errors of Estimates (I)

  • According to NEXRAD requirements, standard errors of estimates are specified at SNR > 8 dB and sv = 4 m/s

  • For the Batch Mode, we use standard formulas (contiguous pairs)

  • For the Staggered PRT, we use modified formulas (spaced pairs)


Errors of estimates ii

Requires average of 4 gates in range

All slightly larger than 1 m/s

All better than with the BM

All less than 1 m/s

Errors of Estimates (II)

Batch Mode

Staggered PRT


Solutions to the issue of larger errors of estimates

Solutions to the Issue of Larger Errors of Estimates

  • Collect more samples per radial

    • This requires reducing the antenna rotation rate

      • For example, at 2.5 deg need to collect 21 pairs instead of 15, adding about 8 seconds to the scan

  • Use Sachi’s one-overlay resolution technique and reduce the PRTs

    • Computationally complex

  • Use oversampling and whitening

    • Even a small oversampling factor would work


What about other vcps

What about other VCPs?

  • Requirements don’t change!

  • Everything depends on the required range coverage and the dwell time

    • The shorter the dwell time and/or the larger the required range coverage, the larger the errors

      • Larger errors increase the likelihood of catastrophic errors in the Staggered PRT velocity dealiasing algorithm


Ground clutter filtering with staggered prts

Ground Clutter Filtering with Staggered PRTs

Can we remove the clutteras well as with uniform PRT?


Ground clutter filtering

Ground Clutter Filtering

  • Batch mode

    • Surveillance pulses are filtered with the two-pulse canceller

      • About 30 dB of suppression

    • Doppler pulses are filtered with GMAP

  • Staggered PRT

    • Staggered PRT pulses are filtered with a spectral GCF (Sachidananda)

      • Filter can incorporate elements of GMAP


Gcf performance

GCF Performance

Batch Mode - 2 pulse canceller

Batch Mode - GMAP

No GCF

Staggered PRT


Conclusions

Conclusions

  • Unambiguous range coverage for velocity estimates is greatly improved with Staggered PRT

  • Staggered PRT yields larger Nyquist velocity intervals

  • For the same dwell times, errors of estimates are better for reflectivity and slightly worse for velocity

  • Ground clutter suppression using a spectral filter is much better for reflectivity and comparable for velocity

  • Staggered PRT is a viable candidate to replace the legacy Batch Mode at intermediate elevation angles


An image is worth a thousand words

BATCH MODE

STAGGERED PRT

An image is worth a thousand words …
