1 / 54

Dentin_pulp complex

Dentin_pulp complex. Dentin and pulp are embryologically, histologically, and functionally the same tissue and therefore are considered as a complex. Tooth. Tooth Crown. Dentin. Pulp. Tooth Root. Both dentin and pulp have a common origin from the dental papilla. Pulp. Dentin. Pulp.

kert
Download Presentation

Dentin_pulp complex

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript


  1. Dentin_pulp complex

  2. Dentin and pulp are embryologically, histologically, and functionally the same tissue and therefore are considered as a complex

  3. Tooth Tooth Crown Dentin Pulp Tooth Root

  4. Both dentin and pulp have a common origin from the dental papilla.

  5. Pulp Dentin

  6. Pulp Dentin Odontoblast cell layer

  7. Dentin Pulp

  8. Types of Dentin Dentin Primary physiologic dentin Secondary physiologic dentin Tertiary dentin or reparative dentin or reactionary dentin or irregular secondary dentin Circumpulpal dentin Intertubular dentin Mantle dentin Peritubular dentin

  9. Types of Dentin Primary dentin: is the dentin formed in a tooth before the completion of the apical foramen of the root. Primary dentin is noted for its regular pattern of tubules. Secondary dentin: is the dentin that is formed after the completion of the apical foramen and continues to form throughout the life of the tooth. Peritubular (intratubular) dentin: dentin that creates the wall of the dentinal tubule. Intertubular dentin: dentin found between the tubules. Mantle dentin: the first predentin that forms and matures within the tooth. Circumpulpal dentin: the layer of dentin around the outer pulpal wall.

  10. Odontoblasts and process Pulp Dentin Odontoblast process Odontoblast cells

  11. Dentinal Matrix Dentinal matrix Hole for dentinal tubules

  12. Dentinal tubules

  13. Dentinal tubules

  14. Dentinal tubules Peritubular dentin Intertubular dentin

  15. Dentinal tubules Predentin

  16. Dentinal tubules Peritubular dentin Intertubular dentin

  17. Odontoblast layer Predentin Dentinal tubules

  18. Dentinal Tubules Coronal dentin Root dentin

  19. Dentinal tubules

  20. Dentinal tubules Intraubular or peritubular dentin Intertubular dentin

  21. Interglobuler Dentin Dentino Enamel Junction Inter- globuler dentin Dentinal Tubules

  22. Inter- globuler dentin

  23. Dentin Cementum Granular layer of Tomes Hyaline layer

  24. Primary physiological dentin Secondary physiological dentin

  25. Secondary physiological dentin Primary physiological dentin Tertiary dentin

  26. Deantal caries Sclerotic dentin

  27. Dead tracts Tertiary dentin Secondary physiological dentin Primary physiological dentin

  28. Incremental line of von Ebner

  29. Enamel Dentin Lines of Owen Lines of Retzius Dentino-enamel Junction

  30. Neonatal lines in Dentin

  31. Functions of the Dental Pulp • Nutrition: blood supply for pulp and dentin. • Sensory: changes in temp., vibration and chemical that affect the dentin and pulp. • Formative: the pulp involve in the support, maintenance and continued formation of dentin. • Defensive: triggering of inflammatory and immune response. • Protective: Development and formation of secondary and tertiary dentin which increase the coverage of the pulp.

  32. Anatomy of Pulp Pulp horns or cornua Pulp Chamber or coronal pulp, located in the crown of the tooth. Root canal or radicular pulp, is the portion of the pulp located in the root area. The apical foramen is the opening from the pulp at the apex of the tooth. Accessory canals or lateral canal, extra canal located on the lateral portions of the root.

  33. Lateral or accessory canal

  34. Lateral Canal

  35. Odontoblastic process Predentin Cell bodies Odontoblasts Cell-free zone Cell-rich zone

  36. Microscopic Zones in Pulp

  37. Dentin Odontoblasts layer Predentin Cell rich zone Pulp core Cell free zone

  38. Contents of the Pulp • Cells: Odontoblast, Fibroblast, white-blood cells, Undifferentiated mesenchymal cells, Macrophages and Lymphocytes. No fat cell. • Fibrous Matrix: Mostly reticular fibres and collagen fibres (Type I and Type III). • Ground substance: Act as a medium to transport nutrients to cells and metabolites of the cell to the blood vessels.

  39. Vascularity and Nerves of the Pulp • The pulp organ is extensively vascular with vessels arising from the external carotids to the superior or inferior alveolar arteries. It drain by the same vein. • Blood flow is more rapid in the pulp than in most area of the body, and the blood pressure is quite high. • The walls of the pulpal vessels become very thin as their enter the pulp. • Nerves : Several large nerves enter the apical canal of each Molar and Premolar and single ones enter the anterior teeth. This trunks transverse the radicular pulp, proceed to the coronal area and branch peripherally.

  40. Nerves and vessels in pulp Blood and vessels enter and exit the dental pulp by way of the apical and accessory foramina. Pulp is richly innervated; nerves enter the pulp through the apical foramen, along with afferent blood vessels and together form the neuro-vascular bundle.

  41. Nerves in pulp

  42. Dental Pulp Nerve Blood vessel

  43. Clinically Importance features of the Dental Pulp • With age the pulp becomes less cellular. The number of cells in the dental pulp decreases as cell death occurs with age. • The volume of the pulp chamber with continued deposition of dentine. In older teeth, the pulp chamber decreases in size; in some cases the pulp chamber can be obliterated. An increase in calcification in the pulp occurs with age. • An increase in calcification in the pulp occurs with age.

  44. Free True Denticle Free True Denticle

  45. Free True Denticle

  46. Free True Denticle Odontoblast Dentinal Tubules Predentin

  47. Free False Denticle
