  1. IA-64 Architecture Innovations John Crawford Architect & Intel Fellow Intel Corporation Jerry Huck Manager & Lead Architect Hewlett Packard Co.

  2. Agenda • Architecture Principles • Predication & Speculation • Branch Architecture • Software Pipelining

  3. Traditional Architectures: Limited Parallelism Original Source Code Sequential Machine Code Compiler Hardware parallelized code parallelized code multiple functional units Execution Units Available Used Inefficiently . . . . . . . . . . . . Today’s Processors often 60% Idle

  4. IA-64 Architecture: Explicit Parallelism Parallel Machine Code Original Source Code Compile Compiler Hardware multiple functional units IA-64 Compiler Views Wider Scope More efficient use of execution resources . . . . . . . . . . . . Increases Parallel Execution

  5. IA-64 Principles • Explicitly parallel: • Instruction level parallelism (ILP) in machine code • Compiler schedules across a wider scope • Enhanced ILP : • Predication, Speculation, Software pipelining, ... • Fully compatible: • Across all IA-64 family members • IA-32 in hardware and PA-RISC through instruction mapping • Inherently scalable • Massively resourced: • Many registers • Many functional units

  6. Predication Traditional Architectures IA-64 • Removes branches, converts to predicated execution • Executes multiple paths simultaneously • Increases performance by exposing parallelism and reducing critical path • Better utilization of wider machines • Reduces mispredicted branches cmp cmp then p1 p2 p1 p2 else p1 p2

  7. Predication Review • Two kinds of normal compares • Regular • Unconditional (nested IF’s) p1,p2,<-... (p1) p3= (p2) p3= (p2) p3,p4 <-cmp.unc... p2&p3 p2&p4 (p3)... (p4)... (p3)... Regular: p3 is set just once Unconditional: p3 and p4 are AND’ed with p2 Opportunity for Even More Parallelism

  8. Introducing Parallel Compares • Three new types of compares: • AND: both target predicates set FALSE if compare is false • OR: both target predicates set TRUE if compare is true • ANDOR: if true, sets one TRUE, sets other FALSE A B A C B D C Reduces Critical Path D

  9. Eight Queens Example if ((b[j] == true) && (a[i+j] == true) && (c[i-j+7] == true)) Unconditional Compares 8 queens control flow R1=&b[j] R3=&a[i+j] R5=&c[i-j+7] ld R2=[R1] ld.s R4=[R3] ld.s R6=[R5] P1,P2 <-cmp.unc(R2==true) (p1)chk.s R4 (p1)P3,P4 <-cmp.unc(R4==true) (p3)chk.s R6 (p3)P5,P6 <-cmp.unc(R5==true) (P5) br then else 1 P2 P1 2 4 P4 P3 5 P6 P5 Else Then 6 7

  10. if ((b[j] == true) && (a[i+j] == true) && (c[i-j+7] == true)) P1 Eight Queens Example 8 queens control flow Parallel Compares R1=&b[j] R3=&a[i+j] R5=&c[i-j+7] p1 <- true ld R2=[R1] ld R4=[R3] ld R6=[R5] p1,p2 <- cmp.and(R2==true) p1,p2 <- cmp.and(R4==true) p1,p2 <- cmp.and(R6==true) (p1) br then else P2 1 P1 2 P4 P3 P6 4 P5 Else Then 5

  11. if ((b[j] == true) && (a[i+j] == true) && (c[i-j+7] == true)) Eight Queens Example 8 queens control flow Parallel Compares R1=&b[j] R3=&a[i+j] R5=&c[i-j+7] p1 <- true ld R2=[R1] ld R4=[R3] ld R6=[R5] p1,p2 <- cmp.and(R2==true) p1,p2 <- cmp.and(R4==true) p1,p2 <- cmp.and(R6==true) (p1) br then else P2 1 P1 2 P4 P3 P1=False P1= true P6 4 P5 Else Else Then Then 5 Reduced from 7 cycles to 5

  12. Five Predicate Compare Types • (qp) p1,p2 <- cmp.relation • if(qp) {p1 = relation; p2 = !relation}; • (qp) p1,p2 <- cmp.relation.unc • p1 = qp&relation; p2 = qp&!relation; • (qp) p1,p2 <- cmp.relation.and • if(qp & (relation==FALSE)) { p1=0; p2=0; } • (qp) p1,p2 <- cmp.relation.or • if(qp & (relation==TRUE)) { p1=1; p2=1; } • (qp) p1,p2 <- cmp.relation.or.andcm • if(qp & (relation==TRUE)) { p1=1; p2=0; } Tbit (Test Bit) Also Sets Predicates

  13. Predication Benefits • Reduces branches and mispredict penalties • 50% fewer branches and 37% faster code* • Parallel compares further reduce critical paths • Greatly improves code with hard to predict branches • Large server apps- capacity limited • Sorting, data mining- large database apps • Data compression • Traditional architectures’ “bolt-on” approach can’t efficiently approximate predication • Cmove: 39% more instructions, 23% slower performance* • Instructions must all be speculative * Source: S. Mahlke, 1995

  14. Speculation Review IA-64 Traditional Architectures ld.s instr 1 instr 2 • Memory latency is a major performance bottleneck in today’s systems • CPU to memory gap increasing instr 1 instr 2 . . . br Barrier br Load use chk.s use Allows elevation of load, even above a branch

  15. Hoisting Uses IA-64 ld.s instr 1 instr 2 • The uses of speculative data can also be executed speculatively • distinguishes speculation from simple prefetch br chk.s use Enables Further Parallelism

  16. Introducing the NaT(“Not a Thing”) IA-64 • NaT is the GR’s 65th bit that indicates: • whether or not an exception has occurred • branch to fixup code required • NaT set during ld.s, checked by Chk.s ld.s instr 1 instr 2 ;Exception Detection Propagate Exception br ;Exception Delivery chk.s use

  17. Propagation • All computation instructions propagate NaTs to reduce number of checks • Cmp propagates “false” when writing predicates • RISC architectures require more instructions for equivalent integrity • e.g., non faulting load ld8.s r3 = (r9) ld8.s r4 = (r10) add r6 = r3, r4 ld8.s r5 = (r6) p1,p2 = cmp(...) Allows single chk on result chk.s r5 sub r7 = r5,r2

  18. Exception Deferral: More Than Skin Deep • Deferral allows the efficient delay of costly exceptions • OS controlled deferral by hardware of: • Page faults • Protection violations • … • NaTs enable deferral with recovery • Efficiently support structured exception handling in C/C++ ld.s instr 1 instr 2 uses br Recovery code ld uses br home chk.s (Home Block) Complete Solution for Exception Management

  19. Control Speculation Summary • All loads have a speculative form that sets the NaT bit when deferring exceptions • Computational instructions propagate NaTs • OS controls deferral of faults but supported directly in HW - “no-fault speculation” • Minimizes overhead of data that is not used • Chk more effective than non-faulting load

  20. Store Barrier Traditional Architectures instr 1 instr 2 . . . Store(*) Barrier Load (*) use Traditional architectures limited by the Store Barrier

  21. Introducing Data Speculation • Compiler can issue a load prior to a preceding, possibly-conflicting store Traditional Architectures IA-64 instr 1 ld8.a instr 1 instr 2 instr 2 . . . st8 Barrier st8 ld8 use ld.c use Unique feature to IA-64

  22. ld8.a instr 1 use instr 2 ld8.a instr 1 instr 2 st8 st8 Recovery code ld8 uses br home chk.a ld.c use Data Speculation • Uses can be hoisted Synergy with control speculation yields greater performance

  23. ld.a reg# =... chk.a reg# ? st Advanced Load Address Table - ALAT • ld.a inserts entries. • Conflicting stores remove entries • Also: ld.c.clr, chk.a.clr, • Presence of entry indicates success • chk.a branches when no entry is found reg # Address reg # Address reg # Address ...

  24. Architectural Support for Data Speculation • Instructions • ld.a - advanced loads • ld.c - check loads • chk.a - advance load checks • Speculative Advanced loads - ld.sa - is an advanced load with deferral • ALAT - HW structure containing outstanding advanced loads

  25. Speculation Benefits • Reduces impact of memory latency • Study demonstrates performance improvement of 79% when combined with predication* • Greatest improvement to code with many cache accesses • Large databases • Operating systems • Scheduling flexibility enables new levels of performance headroom * August, et.al, 1998

  26. Agenda • Architecture Principles • Predication & Speculation • Branch Architecture • Software Pipelining

  27. Branch Instruction 128-bit bundle 41-bits 127 0 • Two basic branch formats • Relative: IP := IP + Offset21 • Indirect: IP := BR[I] • 8 branch registers for efficient branch execution • Call/Return linking through branch registers • Loop branches with 64-bit loopcount register (LC) • Enables perfect branch prediction of counted loops • Traditional architectures always mispredict last iteration • Incurs misprediction stall costing many cycles QP Branch Instruction 1 Instruction 0 Template IP-Offset 21-bits

  28. Branch Predicates Conditional branches Unconditional branches • Compiler directed static prediction augments dynamic prediction • Better predict highly correlated branches (always/never taken) • Frees space in H/W predictor • Can give hint for dynamic predictor (p0) BR #label_A; (p1) BR #label_A; P1=true P1=false “always true” A A B

  29. Compare & Branch in Same Cycle Queens Loop: Parallel Compares & Compare-branch R1=&b[j] R3=&a[i+j] R5=&c[i-j+7] p1 <- true ld R2=[R1] ld R4=[R3] ld R6=[R5] p1,p2 <- cmp.and(R2==true) p1,p2 <- cmp.and(R4==true) p1,p2 <- cmp.and(R6==true) (p1) br then else 1 2 4 From 5 Cycles Down to 4

  30. ld8 r6 = (ra) (p1) br exit1 chk r6, rec0 (p2) chk r7, rec1 (p4) chk r8, rec2 }{ (p1) br exit1 (p3) br exit2 (p5) br exit3 } ld8 r7 = (rb) (p3) br exit2 ld8 r8 = (rc) (p5) br exit3 Multi-way Branch w/o Speculation Hoisting Loads IA-64 ld8.s r6 = (ra) ld8.s r7 = (rb) ld8.s r8 = (rc) ld8.s r6 = (ra) ld8.s r7 = (rb) ld8.s r8 = (rc) P1 chk r6, rec0 (p1) br exit1 P2 Chk r7, rec1 (p3) br exit2 P3 P4 Chk r8, rec2 (p5) br exit3 P5 P6 3 branch cycles 1 branch cycle • Multiway branches: more than 1 branch in a single cycle • Allows n-way branching Supports Aggressive Speculation

  31. Software Pipelining • Overlapping execution of different loop iterations vs. • More iterations in same amount of time

  32. Software Pipelining • IA-64 features that make this possible • Full Predication • Special branch handling features • Register rotation: removes loop copy overhead • Predicate rotation: removes prologue & epilogue • Traditional architectures use loop unrolling • High overhead: extra code for loop body, prologue, and epilogue Especially Useful for Integer Code With Small Number of Loop Iterations

  33. 3 ops Basic Loop Example Basic Copy Loop For (i=0; i<n; i++) { *b++ =*a++; } /* MemCopy */ • Simple Non-overlapping iterations • 2 cycles per iteration • 3 operations in loop body Execution (Cycles) 1 2 3 4 5 6 7 8 ld1 br.cloop st1 // setup ra/rb/lc, .label loop { ld8 r35 = [ra],8 }{ st8 [rb],8 = r35 br.cloop #loop // check n!=0 } ld2 br. cloop st2 ld3 br. cloop st3 ld4 br. cloop st4

  34. Loop Support: Unrolling Unrolled Copy Loop Test for loop count 0,1 ld8 r34 = [ra],8 .label loop ld8 r35 = [ra],8 st8 [rb],8 = r34 br.cle #e-exit ld8 r34 = [ra],8 st8 [rb],8 = r35 br.cloop #loop st8 [rb],8 = r34 br #thru .label e-exit st8 [rb],8 = r35 .label thru • Overlapped iterations • 1 cycle per word • 1.6X performance improvement • 3.3X code expansion Execution cycles 1 2 3 4 5 Prologue ld1 ld2 st1 br.cle Main loop br.cloop ld3 st2 st3 br.cle ld4 10 ops Epilogue st4 Incurs Code Expansion Penalties

  35. ld1 r34 Software Register Renaming Traditional Architecture . . . R32 R33 R34 R35 . . .

  36. st1 r34 ld2 r35 Software Register Renaming Traditional Architecture . . . R32 R33 R34 R35 . . .

  37. ld3 r34 st2 r35 Software Register Renaming Traditional Architecture . . . R32 R33 R34 R35 . . .

  38. st3 r34 ld4 r35 Software Register Renaming Traditional Architecture . . . R32 R33 R34 R35 . . .

  39. st4 r35 Software Register Renaming Traditional Architecture . . . R32 R33 R34 R35 . . .

  40. ld1 R35 Introducing Rotating Registers • GR 32-127, FR32-127 can rotate • Separate Rotating Register Base for each: GRs, FRs • Loop branches decrement all register rotating bases (RRB) • Instructions contain a “virtual” register number • RRB + virtual register number = physical register number. . . . 36: Palm 35: 34: 33: 32: . . . Palm Sunny Springs is RRB=0

  41. st1 R35 ld2 R34 Introducing Rotating Registers • GR 32-127, FR32-127 can rotate • Separate Rotating Register Base for each: GRs, FRs • Loop branches decrement all register rotating bases (RRB) • Instructions contain a “virtual” register number • RRB + virtual register number = physical register number. IA-64 Palm . . . 36: Palm 35: Springs 34: 33: 32: . . . Palm Sunny Springs is RRB=0

  42. st2 R35 ld3 R34 Introducing Rotating Registers • GR 32-127, FR32-127 can rotate • Separate Rotating Register Base for each: GRs, FRs • Loop branches decrement all register rotating bases (RRB) • Instructions contain a “virtual” register number • RRB + virtual register number = physical register number. IA-64 Palm Springs . . . Palm 35: Springs 34: is 33: 32: 127: . . . Palm Sunny Springs is RRB=-1

  43. st3 R35 ld4 R34 Introducing Rotating Registers • GR 32-127, FR32-127 can rotate • Separate Rotating Register Base for each: GRs, FRs • Loop branches decrement all register rotating bases (RRB) • Instructions contain a “virtual” register number • RRB + virtual register number = physical register number. IA-64 Palm Springs is . . . Springs 34: is 33: Sunny 32: 127: 126: . . . Palm Sunny Springs is RRB=-2

  44. st4 R35 Introducing Rotating Registers • GR 32-127, FR32-127 can rotate • Separate Rotating Register Base for each: GRs, FRs • Loop branches decrement all register rotating bases (RRB) • Instructions contain a “virtual” register number • RRB + virtual register number = physical register number. IA-64 Palm Sunny Springs is . . . is 33: Sunny 32: 127: 126: 125: . . . Palm Sunny Springs is RRB=-3

  45. 5 ops Loop Support: Rotating Registers Software Pipelined Copy Loop // setup ra/rb/lc/ec, check n > 2 { ld8 r35 = [ra],8 } .label loop { ld8 r34 = [ra],8 st8 [rb] = r35,8 br.ctop #loop }{ st8 [rb] = r35,8 } • Modulo Scheduled Iterations • 1 cycle per word • 1.6X performance improvement • additional upside for higher latency conditions • 1.7X code expansion Execution cycles 1 2 3 4 5 Prologue ld1 ld2 st1 br.ctop Main loop ld3 br. ctop st2 ld4 st3 br. ctop Epilogue st4

  46. IA-64 . . . (p16) ld1 R34 (p17) st R35 0 18: 0 17: 0 16: 0 63: 0 62: . . . Introducing Rotating Predicate Registers • PR16-63 can rotate, with separate Rotating Register Base • Loop branches decrement all register rotating base (RRB) • Instructions contain a “virtual” predicate register number • RRB + virtual register number = physical register number. LC=3 EC=2 IA-64 Code . . . 0 18: (p17) st R35 0 17: 1 (p16) ld R34 (p16) ld R34 16: 0 63: 0 62: . . . RRB=0 Initialize

  47. IA-64 IA-64 IA-64 . . . . . . . . . (p16) ld2 R34 (p16) ld1 R34 (p17) st1 R35 (p17) st R35 0 0 0 18: 18: 18: 0 0 0 17: 17: 17: 1 0 1 16: 16: 16: 0 0 1 63: 63: 63: 0 0 0 62: 62: 62: . . . . . . . . . Introducing Rotating Predicate Registers • PR16-63 can rotate, with separate Rotating Register Base • Loop branches decrement all register rotating base (RRB) • Instructions contain a “virtual” predicate register number • RRB + virtual register number = physical register number. LC=2 EC=2 IA-64 Code . . . 0 17: (p17) st R35 (p17) st R35 1 16: 1 (p16) ld R34 (p16) ld R34 63: 0 62: 0 61: . . . RRB=-1 Branch 1

  48. IA-64 IA-64 IA-64 IA-64 IA-64 . . . . . . . . . . . . . . . (p16) ld3 R34 (p16) ld2 R34 (p16) ld1 R34 (p17) st R35 (p17) st1 R35 (p17) st2 R35 0 0 0 0 0 18: 17: 17: 18: 18: 0 1 0 0 1 16: 17: 16: 17: 17: 1 1 1 1 0 63: 16: 63: 16: 16: 0 0 1 0 1 62: 63: 62: 63: 63: 0 0 0 0 0 61: 62: 61: 62: 62: . . . . . . . . . . . . . . . Introducing Rotating Predicate Registers • PR16-63 can rotate, with separate Rotating Register Base • Loop branches decrement all register rotating base (RRB) • Instructions contain a “virtual” predicate register number • RRB + virtual register number = physical register number. LC=1 EC=2 IA-64 Code . . . 1 16: (p17) st R35 (p17) st R35 1 63: 1 (p16) ld R34 (p16) ld R34 62: 0 61: 0 60: . . . RRB=-2 Branch 2

  49. IA-64 IA-64 IA-64 IA-64 IA-64 IA-64 IA-64 . . . . . . . . . . . . . . . . . . . . . (p16) ld4 R34 (p16) ld1 R34 (p16) ld2 R34 (p16) ld3 R34 (p17) st R35 (p17) st2 R35 (p17) st1 R35 (p17) st3 R35 0 0 1 1 0 0 0 17: 17: 16: 18: 18: 18: 16: 1 0 1 1 0 1 0 17: 17: 17: 63: 16: 16: 63: 1 1 1 1 1 1 0 62: 16: 16: 16: 62: 63: 63: 1 1 1 0 0 0 0 63: 61: 62: 63: 63: 62: 61: 0 0 0 0 0 0 0 60: 61: 62: 61: 62: 60: 62: . . . . . . . . . . . . . . . . . . . . . Introducing Rotating Predicate Registers • PR16-63 can rotate, with separate Rotating Register Base • Loop branches decrement all register rotating base (RRB) • Instructions contain a “virtual” predicate register number • RRB + virtual register number = physical register number. LC=0 EC=2 IA-64 Code . . . 1 63: (p17) st R35 (p17) st R35 1 62: 1 (p16) ld R34 (p16) ld R34 61: 0 60: 0 59: . . . RRB=-3 Branch 3

  50. IA-64 IA-64 IA-64 IA-64 IA-64 IA-64 IA-64 IA-64 IA-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . (p16) ld1 R34 (p16) ld4 R34 (p16) ld R34 (p16) ld3 R34 (p16) ld2 R34 (p17) st3 R35 (p17) st R35 (p17) st2 R35 (p17) st3 R35 (p17) st1 R35 0 1 0 1 0 1 0 0 1 17: 16: 17: 18: 18: 63: 63: 18: 16: 1 1 1 1 0 0 0 1 1 17: 16: 17: 62: 63: 62: 63: 17: 16: 1 1 1 1 0 1 1 1 1 16: 63: 62: 61: 16: 16: 63: 61: 62: 0 0 1 0 0 0 1 0 1 61: 61: 62: 63: 62: 60: 63: 60: 63: 0 0 0 0 0 0 0 0 0 61: 60: 61: 59: 62: 62: 62: 60: 59: . . . . . . . . . . . . . . . . . . . . . . . . . . . Introducing Rotating Predicate Registers • PR16-63 can rotate, with separate Rotating Register Base • Loop branches decrement all register rotating base (RRB) • Instructions contain a “virtual” predicate register number • RRB + virtual register number = physical register number. LC=0 EC=1 IA-64 Code . . . 1 62: (p17) st R35 (p17) st R35 1 61: (p16) ld R34 0 (p16) ld R34 (p16) ld R34 60: 0 59: 0 58: . . . RRB=-4 Branch 4
