  1. Implementing Secure Converged Wide Area Networks (ISCW) Module 6: Cisco IOS Threat Defense Features

  2. Module 6: Cisco IOS Threat Defense Features Lesson 6.4: Introducing Cisco IOS IPS

  3. Objectives • Compare and contrast Intrusion Detection Systems and Intrusion Protection Systems. • Describe the Cisco IPS products and technologies. • Define IDS and IPS types and options. • Compare Network Based and Host Based IPS systems (HIPS and NIPS).

  4. Intrusion Detection System • IDS is a passive device: • Traffic does not pass through the IDS device. • Typically uses only one promiscuous interface. • IDS is reactive: • IDS generates an alert to notify the manager of malicious traffic. • Optional active response: • Further malicious traffic can be denied with a security appliance or router. • TCP resets can be sent to the source device.

  5. Intrusion Protection System • IPS is an active device: • All traffic passes through IPS. • IPS uses multiple interfaces. • Proactive prevention: • IPS denies all malicious traffic. • IPS sends an alert to the management station.

  6. Combining IDS and IPS • IPS actively blocks offending traffic: • Should not block legitimate data • Only stops “known malicious traffic” • Requires focused tuning to avoid connectivity disruption • IDS complements IPS: • Verifies that IPS is still operational • Alerts you about any suspicious data except “known good traffic” • Covers the “gray area” of possibly malicious traffic that IPS did not stop

  7. Cisco IOS IPS Products and Technologies • Cisco IOS IPS uses a blend of Cisco IDS and IPS products: • Cisco IDS Series appliances • Cisco Catalyst Series IDS services modules • Cisco network module hardware IDS appliances • Cisco IOS IPS uses a blend of technologies: • Profile-based intrusion detection • Signature-based intrusion detection • Protocol analysis-based intrusion detection

  8. IDS and IPS Types and Options

  9. Network-Based and Host-Based IPS • NIPS: Sensor appliances are connected to network segments to monitor many hosts. • HIPS: Centrally managed software agents are installed on each host. • CSAs defend the protected hosts and report to the central management console. • HIPS provides individual host detection and protection. • HIPS does not require special hardware.

  10. Comparing HIPS and NIPS

  11. NIPS Features • Sensors are network appliances that you tune for intrusion detection analysis: • The operating system is “hardened.” • The hardware is dedicated to intrusion detection analysis. • Sensors are connected to network segments. A single sensor can monitor many hosts. • Growing networks are easily protected: • New hosts and devices can be added without adding sensors. • New sensors can be easily added to new networks.

  12. NIDS and NIPS Deployment

  13. Signature-Based IDS and IPS • Observes and blocks or alarms if a known malicious event is detected: • Requires a database of known malicious patterns. • The database must be continuously updated.

  14. ! ! Policy-Based IDS and IPS • Observes and blocks or alarms if an event outside the configured policy is detected • Requires a policy database

  15. Anomaly-Based IDS and IPS • Observes and blocks or alarms if an event outside known normal behavior is detected: • Statistical versus nonstatistical anomaly detection • Requires a definition of “normal”

  16. Honeypot-Based IDS and IPS • Observes a special system and alarms if any activity is directed at the system: • The special system is a trap for attackers and not used for anything else. • The special system is well-isolated from the system’s environment. • The system is typically used as IDS, not IPS.

  17. Signature Categories • Four types of signatures: • Exploit signatures match specific known attacks. • Connection signatures match particular protocol traffic. • String signatures match string sequences in data. • DoS signatures match DoS attempts. • Signature selection is based on: • Type of network protocol • Operating system • Service • Attack type • Number of available signatures: • About 1500 for IPS sensors, 1200 for IOS IPS

  18. Exploit Signatures • DNS reconnaissance and DoS • Worms, viruses, Trojan horses, adware, malware • Port sweeps • Port scans • TCP SYN attack • Fragmentation attacks • IP options • ICMP reconnaissance and DoS

  19. Signature Examples

  20. Summary • The intrusion detection system (IDS) is a software- or hardware-based solution that passively listens to network traffic. • An intrusion prevention system (IPS) is an active device in the traffic path that listens to network traffic and permits or denies flows and packets into the network. • In a network-based system, or network intrusion prevention system (NIPS), the IPS analyses individual packets that flow through a network. • In a host-based system, a host-based intrusion prevention system (HIPS) examines the activity on each individual computer or host. • IDS and IPS uses any one of four approaches to identifying malicious traffic: • Signature-based • Policy-based • Anomaly-based • Honeypot-based

  21. Q and A

  22. Resources • Cisco Intrusion Prevention System • http://cisco.com/en/US/partner/products/sw/secursw/ps2113/index.html • Cisco Intrusion Prevention System Support • http://cisco.com/en/US/partner/products/sw/secursw/ps2113/tsd_products_support_series_home.html
