Presentation Transcript
Slide1 l.jpg

Direct-Reading

Gas Detection Instruments

Presented by

Michael D. Shaw


Slide2 l.jpg

“DIRECT-READING”

Means that instrument provides display

in engineering units (usually ppm or percent)

Implication (not always true) that unit is reading in real time


Slide3 l.jpg

GASES OF INTEREST

Combustible

Oxygen (deficiency and enrichment)

Toxic


Slide4 l.jpg

MOST COMMON TECHNOLOGIES EMPLOYED

IN INDUSTRIAL HYGIENE APPLICATIONS


Slide5 l.jpg

CATALYTIC SENSORS

(also known as Pellistors)

Theory - Target gas is oxidized on catalytic element

The change in temperature causes

a change in resistance that is measured by the meter

Application – combustible gases


Slide6 l.jpg

CATALYTIC SENSORS

Advantage

Long life

Disadvantages

Different responses for each combustible gas

Can be poisoned

Most require at least 10% oxygen to work properly

Limited to percent-level detection


Slide7 l.jpg

METAL OXIDE SEMICONDUCTOR

(Also known as solid state, Figaro, or Taguchi sensors)

Theory – Target gas reacts with MOS (SnO2 ) and

changes its resistance – as measured by the meter

Application - Nearly all oxidizable gases


Slide8 l.jpg

METAL OXIDE SEMICONDUCTOR

Advantage

Inexpensive

Disadvantages

Not selective, and this is often misrepresented

Affected by humidity

Not truly analytical—better as “go/no-go” detectors


Slide9 l.jpg

NON-DISPERSIVE INFRARED (NDIR)

Theory – Target gas absorbs infrared light at a particular wavelength

Via Beer’s Law

calculations —concentration

can be determined

Application – Hundreds of compounds, especially organics


Slide10 l.jpg

BEER’S LAW ( FOR EXTRA CREDIT )

"The deeper the glass,The darker the brew,The less of the incidentLight that gets through"

I = I0ekP

I = intensity of light striking the detector

I0 = measured signal at zero concentration of target gas

k = system dependent constant

P = concentration of target gas

e = base for natural logarithms


Slide11 l.jpg

NON-DISPERSIVE INFRARED (NDIR)

Advantage

Extremely versatile

Disadvantages

Expensive

Can be fragile and complicated to service


Slide12 l.jpg

PHOTOIONIZATION DETECTOR (PID)

Theory - Ultraviolet light ionizes the target gas

Current produced is proportional to concentration

Application – Volatile Organic Compounds (VOC’s)


Slide13 l.jpg

PHOTOIONIZATION DETECTOR (PID)

Advantage

Detects a wide range of volatile organic compounds

Quite effective when used in conjunction

with chromatographic column → Portable GC’s

Disadvantages

Nonselective among organic vapors below

ionization potential of lamp

Affected by high humidity

UV lamps are expensive


Slide14 l.jpg

ELECTROCHEMICAL SENSORS

Theory – Target gas is adsorbed on an electrocatalytic sensing electrode, after passing through a diffusion medium, and is electrochemically reacted.

The current produced

by this reaction is

directly proportional

to the gas concentration.

Applications

Br2, CO, Cl2,

ClO2, C2H4,

ethylene oxide

HCHO, H2, hydrazine, HBr, HCl, HCN, H2S, NO, NO2, O3,

propylene oxide, SO2, and oxygen-- among others


Slide15 l.jpg

ELECTROCHEMICAL SENSORS

Advantages

Inexpensive

Linear output

Can be miniaturized

Disadvantages

Prone to interferences in unskilled hands

Affected by temperature— readily correctable


Slide16 l.jpg

WHAT IS THE MOST IMPORTANT THING

IN GAS DETECTION WHEN USING

DIRECT-READING INSTRUMENTS?

PROPER CALIBRATION!!

Without a clean zero gas and an accurate verified calibration standard—there is no point in doing any gas detection




Slide19 l.jpg

CONTINUOUS MONITORING SYSTEM

SINGLE POINT APPLICATION


Slide20 l.jpg

CONTINUOUS MONITORING SYSTEM

TWO POINT APPLICATION


Slide21 l.jpg

CONTINUOUS MONITORING SYSTEM

MULTI-POINT (THREE OR MORE) APPLICATION


Slide22 l.jpg

ARC-MAX®

DATA ACQUISITION, ARCHIVING,

AND REPORTING


Slide23 l.jpg

ARC-MAX® MAIN SCREEN


Slide24 l.jpg

ARC-MAX® SHIFT REPORT


Slide25 l.jpg

ARC-MAX® TRENDING


Slide26 l.jpg

ARC-MAX® ALARM LOG


Slide27 l.jpg

For Survey Applications,

We Recommend Our Nomad Data Logger

12-bit resolution

Models available for

0-100mV, 0-2.5V

and 4-20mA inputs

Self-contained units

also available for

temperature, humidity

and pH

Sampling rate adjustable—1 second to 10 hours in 1 second intervals

Storage capacity—16336 readings

Excellent software included



Slide29 l.jpg

Time history graph detail screen history graph

Zoomed in on particular portion of the curve



Slide32 l.jpg

CONCLUDING REMARKS history graph

We've looked at the most widely used operating

principles in direct-reading gas detection instruments

We've touched upon the importance of calibration

We've examined two approaches to data acquisition


Slide33 l.jpg

SPECIAL THANKS TO history graph

PROFESSOR GEORGE BYRNS
