synthetic content approach for benchmarking mobile 3d graphics work in progress

Synthetic content approach for benchmarking mobile 3D graphics:Work-in-progress

Kari J. Kangas, Mika Qvist, Kari Pulli

Nokia

outline
Outline
  • Introduction and motivation
  • Related work
  • Synthetic benchmark content approach
    • Tracing, analyzing, synthesizing
    • Preliminary results
  • Future work
  • Summary
introduction
Introduction
  • Phones already support 2D/3D vector graphics
    • OpenGL ES, Java M3G, SVG, (OpenVG)
  • Vector graphics HW is coming
    • Technologies are adapted from desktop PCs very quickly
  • Vector graphics performance
    • Essential part of interactive vector graphics user experience
    • Very complex issue compared to traditional bitmap graphics; performance is highly content dependent
why opengl es benchmarking
Why OpenGL ES benchmarking?
  • Performance optimization
    • Find performance bugs
    • Monitor the progress of optimization work
  • Understand 3D graphics platforms
    • How various content affects performance
  • Performance estimates for content developers
  • Benchmark data is needed as early as possible
why benchmarking is challenging
Why benchmarking is challenging?
  • Immature platforms
    • Fragile SW environment, no GUI
  • Binary breaks
    • Source code is needed
  • Lack of versatile benchmark suites
    • Content ranges from simple UI controls to M3G to native OpenGL ES
    • We need speculative content
synthetic benchmark content approach
Synthetic benchmark content approach
  • Key question: is synthetic content similar enough to the real content from the performance point of view?
  • Analyze existing OpenGL ES content
    • Tracer, trace player, analyzer
  • Create synthetic benchmark content
    • Synthetic content tool
  • Ensure the synthetic content matches the original content from the performance point of view
  • Use synthetic content for benchmarking
related work
Related work
  • Workload characterization
    • Dunwoody & Linton [1990], Mitra and Chiuen [1999], and Antochi et al. [2004]
    • Analyzing workload features
  • Render-time estimation
    • Funkhouser and Sequin [1993]
  • Benchmark suites
    • SPMark04, 3DMarkMobile06
tracing opengl es content
OpenGL ES tracer

Store OpenGL ES calls & parameters

OpenGL ES impl.

Render graphics

Applications used as is

No changes, no source code

Real-time tracing

Full trace vs. sample frames

Tracing OpenGL ES content

OpenGL ES

application

OpenGL ES

Call trace

OpenGL ES

tracer

OpenGL ES

OpenGL ES

Implementation

analyzing opengl es trace
OpenGL ES trace player

Replay the graphics in controlled env.

OpenGL ES analyzer

Extract content features

Content features

Condensed representation

Off-line analysis

Analyzing OpenGL ES trace

Call trace

Trace player

Analyzer

Content

features

content features an example
Content features: an example

FNUM TXF TXBW TXIBW TXCBW TEXA TEXAM TEXC TEXCM TRIR TRIBFC TRIAA TRIRP PRIC VERIN TRIIN TPP ODE VSS

10 1539632 4.55 0.049 1.366 13 0.71 259 11.68 3797 35.55 404.7 990330 1489 7672 4694 3.15 3.22 184128

11 1405320 4.09 0.055 1.226 33 1.11 259 11.68 4332 36.91 452.0 1235221 1571 8131 4989 3.18 4.02 195112

12 1462472 4.32 0.078 1.296 49 1.38 259 11.68 5744 34.89 324.4 1213106 2136 10986 6714 3.14 3.95 263632

13 1646844 4.99 0.065 1.497 32 1.15 259 11.68 4704 33.72 375.5 1170905 1604 8362 5154 3.21 3.81 200688

14 1419244 4.23 0.036 1.269 5 0.50 259 11.68 1886 22.75 566.8 825884 855 4260 2550 2.98 2.69 102240

15 1477088 4.40 0.051 1.320 18 0.80 259 11.68 1868 23.93 642.8 913369 690 3456 2076 3.01 2.97 82944

16 1513716 4.57 0.066 1.370 19 0.85 259 11.68 1872 25.75 625.0 868731 701 3532 2130 3.04 2.83 84768

17 1540548 4.63 0.054 1.389 30 0.99 259 11.68 2611 29.41 466.7 860060 917 4706 2872 3.13 2.80 112944

18 1620824 4.90 0.085 1.471 38 1.18 259 11.68 3894 33.23 349.6 909023 1296 6742 4150 3.20 2.96 161808

19 1598616 4.85 0.051 1.454 18 0.85 259 11.68 2685 29.09 504.8 961196 1054 5382 3274 3.11 3.13 129168

20 1495388 4.45 0.058 1.336 19 0.85 259 11.68 3142 31.80 605.3 1297206 1054 5430 3322 3.15 4.22 130288

21 1712896 5.25 0.038 1.576 17 0.82 259 11.68 1269 27.03 900.8 834102 522 2644 1600 3.07 2.72 63456

22 1502388 4.44 0.049 1.333 21 0.92 259 11.68 4422 31.21 362.2 1101661 1508 7757 4741 3.14 3.59 186168

23 1482496 4.41 0.051 1.322 27 0.87 259 11.68 4953 36.87 278.2 870045 1677 8691 5337 3.18 2.83 208584

24 1501376 4.47 0.048 1.341 35 0.82 259 11.68 4897 37.06 294.9 908773 1586 8403 5231 3.30 2.96 201672

25 1580848 4.70 0.066 1.409 30 1.15 259 11.68 4608 26.63 400.2 1353148 1556 7899 4787 3.08 4.40 189544

26 1552052 4.62 0.062 1.386 37 1.09 259 11.68 4883 27.48 274.5 972134 1651 8675 5373 3.25 3.16 208200

27 2337220 6.96 0.048 2.088 25 0.68 259 11.68 5677 31.37 536.6 2090740 1780 9524 5964 3.35 6.81 228544

Example data from OpenGL analyzer

synthetic content tool
OpenGL ES application

Win32, WinCE/PocketPC, Symbian

Benchmark

OpenGL ES frame, drawn repeatedly

Benchmark suite

Collection of benchmarks

Extensible framework

Diverse benchmark actions

Action composition

Support for animation

Synthetic content tool

Content

features

Benchmark

suite

Synthetic

Content

Tool

benchmarks old sct
Benchmarks: old SCT

["Quake1 frame 11": FILLRATE]

Surface : WINDOW

FrameBufferFormat : 16/5/6/5/0/-

PrimitiveType : TRIANGLES

TriangleSize : 8*8

TriangleCount : 1008

Overdraw : 3

VertexType : FIXED

ColorType : OFF

TexCoordType : FIXED

InterleavedArrays : LOOSE

ShadeModel : FLAT

Blending : OFF

DepthTest : ON

AlphaTest : OFF

ColorMask : 0xF

DepthMask : ON

LogicOp : OFF

Fog : OFF

PerspectiveCorrectionHint : FASTEST

Transformation : PERSPECTIVE

Texture0 : ON

Texture0Count : 4

Texture0Size : 128*128

Texture0Type : RGB565

Texture0MinFilter : GL_LINEAR

Texture0MagFilter : GL_LINEAR

Texture0EnvMode : GL_REPLACE

Texture0Rotate : 0

Texture0Scale : 1

Texture1 : OFF

[“Lighting": TRANSFORMATION]

Surface : WINDOW

FrameBufferFormat : 16/5/6/5/0/-

TriangleSize : 2*1

TriangleCount : 8192

Overdraw : 4

InterleavedArrays : LOOSE

ColorType : OFF

LightCount : 0, 1, 2

TransPerTriangle : 1.0

SharingDistance : 0

VertexType : FIXED

Transformation : COMPLEX

Fog : OFF

Blending : OFF

BackfacingTrianglePercent : 100

Normalization : OFF

Monolithic benchmarks with lots of parameters, no reuse

benchmark new sct
Benchmark: new SCT

["DispSetup":[email protected]]

Surface : PBUFFER

["ClearSetup":[email protected]]

ClearColor : {0,0,0,1}

["ClearScreen":[email protected]]

ClearColor : ON

ClearDepth : ON

["EndFrame":[email protected]]

Dummy : 1 # ignore

[“Camera":[email protected]]

Projection : ORTHO

["FlatSetup":[email protected]]

ShadeModel : GL_FLAT

[“Mem":[email protected]]

Operation : FILLZ

[“Cpu":[email protected]]

Iterations : 1000

[“Mesh":[email protected]]

Iterations : 1

PrimitiveType : GL_TRIANGLE_STRIP

TriangleWidth : 176

TriangleHeight : 208

TriangleCount : 2

VertexType : GL_FIXED

ColorType : GL_UNSIGNED_BYTE

TexCoordType : GL_FIXED

TexCoordUnits : 2

NormalType : GL_FIXED

InterleavedArrays : OFF

UseVBO : OFF

["Max. screen clear rate benchmark":BENCHMARK]

InitActions : DispSetup+ClearSetup+Camera

BenchmarkActions : ClearScreen+EndFrame

[“Marketing benchmark":BENCHMARK]

InitActions : DispSetup+FlatSetup+Camera

BenchmarkActions : Mesh+EndFrame

[“Composite benchmark":BENCHMARK]

InitActions : DispSetup+FlatSetup+Camera

BenchmarkActions : Mem+Cpu+Mesh+EndFrame

Reusable benchmark actions, support for composition, …

comparing real and synthetic content
Rendering time per frame

Trace vs. synthetic content

Different platforms

Compare

Different platforms

Modify SCT to improve the match

New parameters

Improved actions

Comparing real and synthetic content

Trace

player

Rendering time

OGLES1

Call

trace

Trace

player

Rendering time

OGLES2

Synthetic

content

Rendering time

OGLES1

Content

features

Synthetic

content

Rendering time

OGLES2

example
Example

Early OpenGL SCT proto: trace from Quake 2 demo 2, 600 MHz P3, 256 MB RAM

(SW OpenGL)

example16
Example

Early OpenGL SCT proto: trace from Quake 2 demo 2, 3 GHz Xeon, 2 GB RAM, nVidia QuadroFX 500

SCT Proto was VERY primitive (single triangle rendered repeatedly, etc.)

preliminary results
Preliminary results
  • Real content vs. synthetic content
    • Real OpenGL ES content analyzed by hand, very rough content features
    • ~20 FPS real vs. 24 FPS synthetic on a mobile 3D hardware
  • Understanding 3D performance
  • Understanding content
  • Creating “realistic” synthetic content
future work
Future work
  • OpenGL ES tracer, trace player, analyzer
  • OpenGL ES content analysis
  • Creating accurate synthetic content
    • Mapping content features to SCT input
    • Designing good benchmark actions, action compositions
  • Different types of workloads
    • CPU, memory, audio playback, game physics engine
summary
Summary
  • Outline of the synthetic content approach
  • Preliminary results indicate that it should be possible to match synthetic content performance to the real content: work-in-progress
thank you

Thank you!

Questions?
