Search trees red black and other dynamically balancedtrees

Search TreesRed-Black and Other Dynamically BalancedTrees

ECE573: Data Structures and Algorithms

Electrical and Computer Engineering Dept.

Rutgers University

http://www.cs.rutgers.edu/~vchinni/dsa/


Searching re visited

Searching - Re-visited

  • Binary tree O(log n)if it stays balanced

    • Simple binary tree good for static collections

    • Low (preferably zero) frequency of insertions/deletions

      but my collection keeps changing!

    • It’s dynamic

    • Need to keep the tree balanced

  • First, examine some basic tree operations

    • Useful in several ways!

ECE 573: Data Structures & Algorithms


Tree traversal

Tree Traversal

  • Traversal = visiting every node of a tree

  • Three basic alternatives

  • Pre-order

    • Root

    • Left sub-tree

    • Right sub-tree

¬

®

­

¯

°

x A + x + B C x D E F

L

R

L

L

R

ECE 573: Data Structures & Algorithms


Tree traversal1

11

Tree Traversal

  • Traversal = visiting every node of a tree

  • Three basic alternatives

  • In-order

    • Left sub-tree

    • Root

    • Right sub-tree

­

µ

¬

±

³

¯

®

²

´

A x B + C x D x E + F

°

L

L

R

ECE 573: Data Structures & Algorithms


Tree traversal2

11

Tree Traversal

  • Traversal = visiting every node of a tree

  • Three basic alternatives

  • Post-order

    • Left sub-tree

    • Right sub-tree

    • Root

µ

¬

³

´

¯

²

A B C + D E x x F + x

­

±

°

®

L

L

R

ECE 573: Data Structures & Algorithms


Tree traversal3

11

Tree Traversal

  • Post-order

    • Left sub-tree

    • Right sub-tree

    • Root

  • Reverse-Polish

    Normal algebraic form

    which traversal?

µ

¬

³

´

¯

²

­

±

°

(A (((BC+)(DEx) x) F +)x )

®

(A x(((B+C)(DxE))+F))

ECE 573: Data Structures & Algorithms


Trees searching

Trees - Searching

  • Binary search tree

    • Produces a sorted list by in-order traversal

  • In order: A D E G H K L M N O P T V

ECE 573: Data Structures & Algorithms


Trees searching1

Trees - Searching

  • Binary search tree

    • Preserving the order

    • Observe that this transformation preserves thesearch tree

ECE 573: Data Structures & Algorithms


Trees searching2

Trees - Searching

  • Binary search tree

    • Preserving the order

    • Observe that this transformation preserves thesearch tree

  • We’ve performed a rotation of the sub-tree about the T and O nodes

ECE 573: Data Structures & Algorithms


Trees rotations

Trees - Rotations

  • Binary search tree

    • Rotations can be either left- or right-rotations

    • For both trees: the inorder traversal is

      • A x B y C

ECE 573: Data Structures & Algorithms


Trees rotations1

Trees - Rotations

  • Binary search tree

    • Rotations can be either left- or right-rotations

    • Note that in this rotation, it was necessary to moveB from the right child of x to the left child of y

ECE 573: Data Structures & Algorithms


Trees red black trees

Trees - Red-Black Trees

  • A Red-Black Tree

    • Binary search tree

    • Each node is “coloured” red or black

    • An ordinary binary search tree with node colouringsto make a red-black tree

ECE 573: Data Structures & Algorithms


Trees red black trees1

Trees - Red-Black Trees

  • A Red-Black Tree

    • Every node is RED or BLACK

    • Every leaf is BLACK

When you examinerb-tree code, you will

see sentinel nodes (black) added as the leaves.

They contain no data.

Sentinel nodes (black)

ECE 573: Data Structures & Algorithms


Trees red black trees2

Trees - Red-Black Trees

  • A Red-Black Tree

    • Every node is RED or BLACK

    • Every leaf is BLACK

    • If a node is RED, then both children are BLACK

This implies that no path

may have two adjacent

RED nodes.

(But any number of BLACK

nodes may be adjacent.)

ECE 573: Data Structures & Algorithms


Trees red black trees3

Trees - Red-Black Trees

  • A Red-Black Tree

    • Every node is RED or BLACK

    • Every leaf is BLACK

    • If a node is RED, then both children are BLACK

    • Every path from a node to a leaf contains the same number of BLACK nodes

From the root,

there are 3 BLACK nodes

on every path

ECE 573: Data Structures & Algorithms


Trees red black trees4

Trees - Red-Black Trees

  • A Red-Black Tree

    • Every node is RED or BLACK

    • Every leaf is BLACK

    • If a node is RED, then both children are BLACK

    • Every path from a node to a leaf contains the same number of BLACK nodes

The length of this path is the

black height of the tree

ECE 573: Data Structures & Algorithms


Trees red black trees5

Trees - Red-Black Trees

  • Lemma

    A RB-Tree with n nodes has

    height £2 log(n+1)

    • Proof .. See Cormen

  • Essentially,height £2 black height

  • Search time

    O( log n )

ECE 573: Data Structures & Algorithms


Trees red black trees6

Trees - Red-Black Trees

  • Data structure

    • As we’ll see, nodes in red-black trees need to know their parents,

    • so we need this data structure

struct t_red_black_node {

enum { red, black } colour;

void *item;

struct t_red_black_node *left,

*right,

*parent;

}

Same as a

binary tree

with these two

attributes

added

ECE 573: Data Structures & Algorithms


Trees insertion

Trees - Insertion

  • Insertion of a new node

    • Requires a re-balance of the tree

rb_insert( Tree T, node x ) {

/* Insert in the tree in the usual way */

tree_insert( T, x );

/* Now restore the red-black property */

x->colour = red;

while ( (x != T->root) && (x->parent->colour == red) ) {

if ( x->parent == x->parent->parent->left ) {

/* If x's parent is a left, y is x's right 'uncle' */

y = x->parent->parent->right;

if ( y->colour == red ) {

/* case 1 - change the colours */

x->parent->colour = black;

y->colour = black;

x->parent->parent->colour = red;

/* Move x up the tree */

x = x->parent->parent;

Insert node

4

Mark itred

Label the current node

x

ECE 573: Data Structures & Algorithms


Trees insertion1

Trees - Insertion

rb_insert( Tree T, node x ) {

/* Insert in the tree in the usual way */

tree_insert( T, x );

/* Now restore the red-black property */

x->colour = red;

while ( (x != T->root) && (x->parent->colour == red) ) {

if ( x->parent == x->parent->parent->left ) {

/* If x's parent is a left, y is x's right 'uncle' */

y = x->parent->parent->right;

if ( y->colour == red ) {

/* case 1 - change the colours */

x->parent->colour = black;

y->colour = black;

x->parent->parent->colour = red;

/* Move x up the tree */

x = x->parent->parent;

While we haven’t reached the root

and x’s parent is red

x->parent

ECE 573: Data Structures & Algorithms


Trees insertion2

Trees - Insertion

rb_insert( Tree T, node x ) {

/* Insert in the tree in the usual way */

tree_insert( T, x );

/* Now restore the red-black property */

x->colour = red;

while ( (x != T->root) && (x->parent->colour == red) ) {

if ( x->parent == x->parent->parent->left ) {

/* If x's parent is a left, y is x's right 'uncle' */

y = x->parent->parent->right;

if ( y->colour == red ) {

/* case 1 - change the colours */

x->parent->colour = black;

y->colour = black;

x->parent->parent->colour = red;

/* Move x up the tree */

x = x->parent->parent;

If x is to the left of it’s granparent

x->parent->parent

x->parent

ECE 573: Data Structures & Algorithms


Trees insertion3

Trees - Insertion

/* Now restore the red-black property */

x->colour = red;

while ( (x != T->root) && (x->parent->colour == red) ) {

if ( x->parent == x->parent->parent->left ) {

/* If x's parent is a left, y is x's right 'uncle' */

y = x->parent->parent->right;

if ( y->colour == red ) {

/* case 1 - change the colours */

x->parent->colour = black;

y->colour = black;

x->parent->parent->colour = red;

/* Move x up the tree */

x = x->parent->parent;

y is x’s right uncle

x->parent->parent

x->parent

right “uncle”

ECE 573: Data Structures & Algorithms


Trees insertion4

Trees - Insertion

while ((x != T->root)&& (x->parent->colour == red) ) {

if ( x->parent == x->parent->parent->left ) {

/*If x's parent is a left, y is x's right'uncle’*/

y = x->parent->parent->right;

if ( y->colour == red ) {

/* case 1 - change the colours */

x->parent->colour = black;

y->colour = black;

x->parent->parent->colour = red;

/* Move x up the tree */

x = x->parent->parent;

If the uncle is red, change

the colours of y, the grand-parent

and the parent

x->parent->parent

x->parent

right “uncle”

ECE 573: Data Structures & Algorithms


Trees insertion5

Trees - Insertion

while ((x != T->root)&& (x->parent->colour == red) ) {

if ( x->parent == x->parent->parent->left ) {

/* If x's parent is a left, y is x's right 'uncle' */

y = x->parent->parent->right;

if ( y->colour == red ) {

/* case 1 - change the colours */

x->parent->colour = black;

y->colour = black;

x->parent->parent->colour = red;

/* Move x up the tree */

x = x->parent->parent;

ECE 573: Data Structures & Algorithms


Trees insertion6

Trees - Insertion

while ( (x != T->root) && (x->parent->colour == red) ) {

if ( x->parent == x->parent->parent->left ) {

/* If x's parent is a left, y is x's right 'uncle' */

y = x->parent->parent->right;

if ( y->colour == red ) {

/* case 1 - change the colours */

x->parent->colour = black;

y->colour = black;

x->parent->parent->colour = red;

/* Move x up the tree */

x = x->parent->parent;

x’s parent is a left again,

mark x’s uncle

but the uncle is black this time

New x

ECE 573: Data Structures & Algorithms


Trees insertion7

Trees - Insertion

while ( (x != T->root) && (x->parent->colour == red) ) {

if ( x->parent == x->parent->parent->left ) {

/* If x's parent is a left, y is x's right 'uncle' */

y = x->parent->parent->right;

if ( y->colour == red ) {

/* case 1 - change the colours */

x->parent->colour = black;

y->colour = black;

x->parent->parent->colour = red;

/* Move x up the tree */

x = x->parent->parent;

else {

/* y is a black node */

if ( x == x->parent->right ) {

/* and x is to the right */

/* case 2 - move x up and rotate */

x = x->parent;

left_rotate( T, x );

.. but the uncle is black this time

and x is to the right of it’s parent

ECE 573: Data Structures & Algorithms


Trees insertion8

Trees - Insertion

while ( (x != T->root) && (x->parent->colour == red) ) {

if ( x->parent == x->parent->parent->left ) {

/* If x's parent is a left, y is x's right 'uncle' */

y = x->parent->parent->right;

if ( y->colour == red ) {

/* case 1 - change the colours */

x->parent->colour = black;

y->colour = black;

x->parent->parent->colour = red;

/* Move x up the tree */

x = x->parent->parent;

else {

/* y is a black node */

if ( x == x->parent->right ) {

/* and x is to the right */

/* case 2 - move x up and rotate */

x = x->parent;

left_rotate( T, x );

.. So move x up and

rotate about x as root ...

ECE 573: Data Structures & Algorithms


Trees insertion9

Trees - Insertion

while ( (x != T->root) && (x->parent->colour == red) ) {

if ( x->parent == x->parent->parent->left ) {

/* If x's parent is a left, y is x's right 'uncle' */

y = x->parent->parent->right;

if ( y->colour == red ) {

/* case 1 - change the colours */

x->parent->colour = black;

y->colour = black;

x->parent->parent->colour = red;

/* Move x up the tree */

x = x->parent->parent;

else {

/* y is a black node */

if ( x == x->parent->right ) {

/* and x is to the right */

/* case 2 - move x up and rotate */

x = x->parent;

left_rotate( T, x );

ECE 573: Data Structures & Algorithms


Trees insertion10

Trees - Insertion

while ( (x != T->root) && (x->parent->colour == red) ) {

if ( x->parent == x->parent->parent->left ) {

/* If x's parent is a left, y is x's right 'uncle' */

y = x->parent->parent->right;

if ( y->colour == red ) {

/* case 1 - change the colours */

x->parent->colour = black;

y->colour = black;

x->parent->parent->colour = red;

/* Move x up the tree */

x = x->parent->parent;

else {

/* y is a black node */

if ( x == x->parent->right ) {

/* and x is to the right */

/* case 2 - move x up and rotate */

x = x->parent;

left_rotate( T, x );

.. but x’s parent is still red ...

ECE 573: Data Structures & Algorithms


Trees insertion11

Trees - Insertion

while ( (x != T->root) && (x->parent->colour == red) ) {

if ( x->parent == x->parent->parent->left ) {

/* If x's parent is a left, y is x's right 'uncle' */

y = x->parent->parent->right;

if ( y->colour == red ) {

/* case 1 - change the colours */

x->parent->colour = black;

y->colour = black;

x->parent->parent->colour = red;

/* Move x up the tree */

x = x->parent->parent;

else {

/* y is a black node */

if ( x == x->parent->right ) {

/* and x is to the right */

/* case 2 - move x up and rotate */

x = x->parent;

left_rotate( T, x );

.. The uncle is black ..

uncle

.. and x is to the left of its parent

ECE 573: Data Structures & Algorithms


Trees insertion12

Trees - Insertion

while ( (x != T->root) && (x->parent->colour == red) ) {

if ( x->parent == x->parent->parent->left ) {

/* If x's parent is a left, y is x's right 'uncle' */

y = x->parent->parent->right;

if ( y->colour == red ) {

/* case 1 - change the colours */

x->parent->colour = black;

y->colour = black;

x->parent->parent->colour = red;

/* Move x up the tree */

x = x->parent->parent;

else {

/* y is a black node */

if ( x == x->parent->right ) {

/* and x is to the right */

/* case 2 - move x up and rotate */

x = x->parent;

left_rotate( T, x );

else { /* case 3 */

x->parent->colour = black;

x->parent->parent->colour = red;

right_rotate( T, x->parent->parent );

}

.. So we have the final case ..

ECE 573: Data Structures & Algorithms


Trees insertion13

Trees - Insertion

while ( (x != T->root) && (x->parent->colour == red) ) {

if ( x->parent == x->parent->parent->left ) {

/* If x's parent is a left, y is x's right 'uncle' */

y = x->parent->parent->right;

if ( y->colour == red ) {

/* case 1 - change the colours */

x->parent->colour = black;

y->colour = black;

x->parent->parent->colour = red;

/* Move x up the tree */

x = x->parent->parent;

else {

/* y is a black node */

if ( x == x->parent->right ) {

/* and x is to the right */

/* case 2 - move x up and rotate */

x = x->parent;

left_rotate( T, x );

else { /* case 3 */

x->parent->colour = black;

x->parent->parent->colour = red;

right_rotate( T, x->parent->parent );

}

.. Change colours

and rotate ..

ECE 573: Data Structures & Algorithms


Trees insertion14

Trees - Insertion

while ( (x != T->root) && (x->parent->colour == red) ) {

if ( x->parent == x->parent->parent->left ) {

/* If x's parent is a left, y is x's right 'uncle' */

y = x->parent->parent->right;

if ( y->colour == red ) {

/* case 1 - change the colours */

x->parent->colour = black;

y->colour = black;

x->parent->parent->colour = red;

/* Move x up the tree */

x = x->parent->parent;

else {

/* y is a black node */

if ( x == x->parent->right ) {

/* and x is to the right */

/* case 2 - move x up and rotate */

x = x->parent;

left_rotate( T, x );

else { /* case 3 */

x->parent->colour = black;

x->parent->parent->colour = red;

right_rotate( T, x->parent->parent );

}

ECE 573: Data Structures & Algorithms


Trees insertion15

Trees - Insertion

while ( (x != T->root) && (x->parent->colour == red) ) {

if ( x->parent == x->parent->parent->left ) {

/* If x's parent is a left, y is x's right 'uncle' */

y = x->parent->parent->right;

if ( y->colour == red ) {

/* case 1 - change the colours */

x->parent->colour = black;

y->colour = black;

x->parent->parent->colour = red;

/* Move x up the tree */

x = x->parent->parent;

else {

/* y is a black node */

if ( x == x->parent->right ) {

/* and x is to the right */

/* case 2 - move x up and rotate */

x = x->parent;

left_rotate( T, x );

else { /* case 3 */

x->parent->colour = black;

x->parent->parent->colour = red;

right_rotate( T, x->parent->parent );

}

This is now a red-black tree ..

So we’re finished!

ECE 573: Data Structures & Algorithms


Trees insertion16

Trees - Insertion

while ( (x != T->root) && (x->parent->colour == red) ) {

if ( x->parent == x->parent->parent->left ) {

/* If x's parent is a left, y is x's right 'uncle' */

y = x->parent->parent->right;

if ( y->colour == red ) {

/* case 1 - change the colours */

x->parent->colour = black;

y->colour = black;

x->parent->parent->colour = red;

/* Move x up the tree */

x = x->parent->parent;

else {

/* y is a black node */

if ( x == x->parent->right ) {

/* and x is to the right */

/* case 2 - move x up and rotate */

x = x->parent;

left_rotate( T, x );

else { /* case 3 */

x->parent->colour = black;

x->parent->parent->colour = red;

right_rotate( T, x->parent->parent );

}

}

else ....

There’s an equivalent set of

cases when the parent is to

the right of the grandparent!

ECE 573: Data Structures & Algorithms


Red black trees analysis

Red-black trees - Analysis

  • Addition

    • InsertionComparisons O(log n)

    • Fix-up

      • At every stage,x moves up the tree at least one levelO(log n)

    • OverallO(log n)

  • Deletion

    • AlsoO(log n)

  • More complex

  • ... but gives O(log n) behaviour in dynamic cases

ECE 573: Data Structures & Algorithms


Red black trees what you need to know

Red Black Trees - What you need to know?

  • Code?

    • This is not a course for masochists!

      • You can find it in a text-book

  • You need to know

    • The algorithm exists

    • What it’s called

    • When to use it

      • ie what problem does it solve?

    • Its complexity

    • Basically how it works

    • Where to find an implementation

      • How to transform it to your application

ECE 573: Data Structures & Algorithms


Key points

Key Points

  • Red-Black Trees

    • A complex algorithm

    • Gives O(log n) addition, deletion and search

  • Software engineers

    • Know about algorithms

    • Know when to use them

    • Know performance

    • Know where to find an implementation

    • Are too clever to re-invent wheels ...

      • They re-use code

      • So they have more time for

        • Sailing, eating, drinking, ...

          Anything else I should put here

ECE 573: Data Structures & Algorithms


Avl and other balanced trees

AVL and other balanced trees

  • AVL Trees

    • First balanced tree algorithm

    • Discoverers: Adelson-Velskii and Landis

  • Properties

    • Binary tree

    • Height of left and right-subtrees differ by at most 1

    • Subtrees are AVL trees

AVL Tree

AVL Tree

ECE 573: Data Structures & Algorithms


Avl trees height

AVL trees - Height

  • Theorem

    • An AVL tree of height h has at leastFh+3+1 nodes

  • Proof

    • Let Sh be the size of the smallest AVL tree of height h

    • Clearly, S0= 1 and S1= 2

    • Also,Sh = Sh-1+ Sh-2 + 1

    • A minimum height tree must be composed of min height trees differing in height by at most 1

    • By induction ..

      • Sh =Fh+3+1

ECE 573: Data Structures & Algorithms


Avl trees height1

AVL trees - Height

  • Now, for large i, Fi+1 / Fi = f,

    where f = ½(1 + Ö5)

    orFi» c (½(1 + Ö5))i

    • Sh =Fh+3 + 1 = O( bh )

  • n³Sh,so n is W( bh )

    andh £logb n or h is O(log n)

ECE 573: Data Structures & Algorithms


Avl trees height2

AVL trees - Height

  • Now, for large i, Fi+1 / Fi = f,

    where f = ½(1 + Ö5)

    orFi» c (½(1 + Ö5))i

    • Sh =Fh+3 + 1 = O( bh )

  • n³Sh,so n is W( bh )

    andh £logb n or h is O(log n)

  • In this case, we can show

    • h £1.44logb (n+2) - 1.328

his no worse than 44% higher than the optimum

ECE 573: Data Structures & Algorithms


Avl trees rebalancing

AVL Trees - Rebalancing

  • Insertion leads to non-AVL tree

    • 4 cases

    • 1 and 4 are mirror images

    • 2 and 3 are mirror images

1

2

3

4

ECE 573: Data Structures & Algorithms


Avl trees rebalancing1

AVL Trees - Rebalancing

  • Case 1 solved by rotation

    • Case 4 is the mirror image rotation

ECE 573: Data Structures & Algorithms


Avl trees rebalancing2

AVL Trees - Rebalancing

  • Case 2 needs a double rotation

    • Case 3 is the mirror image rotation

ECE 573: Data Structures & Algorithms


Avl trees data structures

AVL Trees - Data Structures

  • AVL trees can be implemented with a flag to indicate the balance state

  • Insertion

    • Insert a new node (as any binary tree)

    • Work up the tree re-balancing as necessary to restorethe AVL property

typedef enum { LeftHeavy, Balanced, RightHeavy } BalanceFactor;

struct AVL_node { BalanceFactor bf; void *item; struct AVL_node *left, *right; }

ECE 573: Data Structures & Algorithms


Dynamic trees red black or avl

Dynamic Trees - Red-Black or AVL

  • Insertion

    • AVL : two passes through the tree

      • Down to insert the node

      • Up to re-balance

    • Red-Black : two passes through the tree

      • Down to insert the node

      • Up to re-balance

        but Red-Black is more popular??

ECE 573: Data Structures & Algorithms


Dynamic trees a cautionary tale

Dynamic Trees - A cautionary tale

  • Insertion

    • If you read Cormen et al,

      • There’s no reason to prefer a red-black tree

    • However, in Weiss’ text

      M A Weiss, Algorithms, Data Structures and Problem Solving with C++, Addison-Wesley, 1996

    • you find that you can balance a red-black tree in one pass!

    • Making red-black more efficient than AVLif coded properly!!!

ECE 573: Data Structures & Algorithms


Dynamic trees a cautionary tale1

Dynamic Trees - A cautionary tale

  • Insertion

    • If you read Cormen et al,

      • There’s no reason to prefer a red-black tree

    • However, in Weiss’ text

      M A Weiss, Algorithms, Data Structures and Problem Solving with C++, Addison-Wesley, 1996

    • you find that you can balance a red-black tree in one pass!

    • Making red-black more efficient than AVLif coded properly!!!

Moral: You need to read the literature!

ECE 573: Data Structures & Algorithms


Dynamic trees a cautionary tale2

Dynamic Trees - A cautionary tale

  • Insertion in one pass

    • As you proceed down the tree,if you find a node with two red children,make it red and the children black

    • This doesn’t alter the number of black nodes in any path

    • If the parent of this node was red,a rotation is needed ...

    • May need to be a single or a double rotation

ECE 573: Data Structures & Algorithms


Trees insertion17

Trees - Insertion

  • Adding 4 ...

Discover two red

children here

Swap colours around

ECE 573: Data Structures & Algorithms


Trees insertion18

Trees - Insertion

  • Adding 4 ...

Red sequence,

violates

red-black property

Rotate

ECE 573: Data Structures & Algorithms


Trees insertion19

Trees - Insertion

  • Adding 4 ...

Rotate

Add the 4

ECE 573: Data Structures & Algorithms


Balanced trees yet more variants

Balanced Trees - Yet more variants

  • Basically the same ideas

    • 2-3 Trees

    • 2-3-4 Trees

      • Special cases of m-way trees ... coming!

      • Variable number of children per node

      • A more complex implementation

      • 2-3-4 trees

        • Map to red-black trees

          Possibly useful to understand red-black trees

ECE 573: Data Structures & Algorithms


Key points1

Key Points

  • AVL Trees

    • First dynamically balanced tree

    • Height within 44% of optimum

    • Rebalanced with rotations

    • O(log n)

      • Less efficient than properly coded red-black trees

  • 2-3, 2-3-4 trees

    • m-way trees - Yet more variations

    • 2-3-4 trees map to red-black trees

ECE 573: Data Structures & Algorithms


M way trees

m-way trees

  • Only two children per node?

  • Reduce the depth of the tree to O(logmn)with m-way trees

  • m children, m-1 keys per node

  • m = 10 : 106 keys in 6 levels vs20 for a binary tree

  • but ........

ECE 573: Data Structures & Algorithms


M way trees1

m-way trees

  • But you have to search through the m keys in each node!

  • Reduces your gain from having fewer levels!

  • A curiosity only?

ECE 573: Data Structures & Algorithms


B trees

B-trees

  • All leaves are on the same level

  • All nodes except for the root and the leaveshave

    • at least m/2 children

    • at most m children

  • B+ trees

    • All the keys in the nodes are dummies

    • Only the keys in the leaves point to “real” data

    • Linking the leaves

      • Ability to scan the collection in orderwithout passing through the higher nodes

Each node is at least

half full of keys

ECE 573: Data Structures & Algorithms


B trees1

B+-trees

  • B+ trees

    • All the keys in the nodes are dummies

    • Only the keys in the leaves point to “real” data

    • Data records kept in a separate area

ECE 573: Data Structures & Algorithms


B trees scanning in order

B+-trees - Scanning in order

  • B+ trees

    • Linking the leaves

      • Ability to scan the collection in orderwithout passing through the higher nodes

ECE 573: Data Structures & Algorithms


B trees use

B+-trees - Use

  • Use - Large Databases

    • Reading a disc block is much slower than reading memory ( ~ms vs ~ns )

    • Put each block of keys in one disc block

Physical disc

blocks

ECE 573: Data Structures & Algorithms


B trees insertion

B-trees - Insertion

  • Insertion

    • B-tree property : block is at least half-full of keys

    • Insertion into block with m keys

      • block overflows

      • split block

      • promote one key

      • split parent if necessary

      • if root is split, tree becomes one level deeper

ECE 573: Data Structures & Algorithms


B trees insertion1

B-trees - Insertion

  • Insertion

    • Insert 9

    • Leaf node overflows,split it

    • Promote middle (8)

    • Root overflows,split it

    • Promote middle (6)

    • New root node formed

    • Height increased by 1

ECE 573: Data Structures & Algorithms


B trees on disc

B-trees on disc

  • Disc blocks

    • 512 - 8k bytes

      100s of keys

    • Use binary search within the block

  • Overall

    • O( log n )

    • Matched to hardware!

  • Deletion similar

    • But merge blocks to maintain B-tree property (at least half full)

ECE 573: Data Structures & Algorithms


  • Login
