Presentation Transcript

What is a laser l.jpg
What is a Laser?

Light

Amplification by the

Stimulated

Emission of

Radiation


Slide3 l.jpg

Lasers in Vision Care

The excimer lasers removes tissue

from the cornea’s internal layers.


Slide5 l.jpg

Lasers demonstrations are used to attract and entertain the public at special events, theme parks, and casinos.


Slide6 l.jpg

Defense Lasers public at special events, theme parks, and casinos.


Slide7 l.jpg

Other Outdoor Lasers public at special events, theme parks, and casinos.

  • Deep Space Communications

  • Near-earth Object Imaging

  • Astronomy

  • Geographic Research

  • Atmospheric Research


Slide8 l.jpg
FAA Order 7400.2 Procedures for Handling Airspace Matters, Part 6. Miscellaneous Procedures, Chapter 29: Outdoor Laser Operations.


Faa laser policy l.jpg
FAA Laser Policy Part 6. Miscellaneous Procedures, Chapter 29: Outdoor Laser Operations.

Prior to 1995, the FAA policy limited laser exposure within the Nominal Ocular Hazard Distance (NOHD) in navigable airspace to less than the Maximum Permissible Exposure (MPE) that can result in tissue damage.


Slide10 l.jpg

Exceeding the MPE Part 6. Miscellaneous Procedures, Chapter 29: Outdoor Laser Operations.(Maximum Permissible Exposure)

Wavelength Effects

<300 nm: Corneal photokeratitis.

300 - 400 nm: Photochemical UV cataract.

400 - 780 nm: Photochemical and thermal retinal injury.

780 - 1400 nm: Cataract, retinal burns.

1400 - 3000 nm: Corneal burn, IR cataract.

>3000 nm: Corneal burn.

NOTE: Optical gain of the eye is about 105. In the retinal hazard region (400 – 1400 nm), irradiance of 1 mW/cm2 entering the eye is increased to 100 W/cm2 at the retina.


Mpe illumination temporary visual impairment l.jpg
< MPE Illumination & Temporary Visual Impairment Part 6. Miscellaneous Procedures, Chapter 29: Outdoor Laser Operations.

  • Glare – Obscuration of an object in a person's field of vision due to a bright light source near the same line-of sight (e.g., oncoming car headlights).

  • Flashblindness – A visual interference effect that persists after the source of illumination has ceased.

  • Afterimage – A reverse contrast shadow image left in the visual field after an exposure to a bright light that may persist for several minutes.


Slide12 l.jpg

FDA Laser Regulation Part 6. Miscellaneous Procedures, Chapter 29: Outdoor Laser Operations.

Since 1976, the Food and Drug Administration’s (FDA’s), Center for Devices and Radiological Health (CDRH) has regulated the manufacturers of all laser devices sold in the U.S. under Title 21 CFR Parts 1010 & 1040. These devices include lasers used to conduct outdoor laser light shows (demonstrations).


Slide13 l.jpg

CDRH Regulations Part 6. Miscellaneous Procedures, Chapter 29: Outdoor Laser Operations.

The manufacturer must certify that a laser product’s performance meets applicable CDRH performance standards and provide labeling to indicate compliance and laser hazard classification.


Slide14 l.jpg

FAA Involvement Part 6. Miscellaneous Procedures, Chapter 29: Outdoor Laser Operations.

In late 1995, the FAA received reports of 52 incidents of aircraft illuminations from laser lights in or near Las Vegas. Of these, 11 incidents resulted in temporary visual impairment of flight crewmembers, and 24 took place during critical phases of flight.


Slide15 l.jpg

NTSB Report # LAX96IA032: Part 6. Miscellaneous Procedures, Chapter 29: Outdoor Laser Operations.

A Southwest Airline’s First Officer (FO) was visually incapacitated on departure from Las Vegas. The captain assumed control of the aircraft. The FO experienced eye pain and was temporarily blinded in the right eye. Inability to see lasted for 30 seconds(10/95).


Slide16 l.jpg

At the FAA’s request, the FDA issued a moratorium ceasing all outdoor laser activities in the Las Vegas area on Dec. 11, 1995. Government and laser industry representatives met to develop appropriate guidelines.


Slide17 l.jpg

FAA Order 7400.2 was revised to establish zones of navigable airspace around airports to protect flight crewmembers from temporary visual impairment during critical flight operations.

Available online at:http://www.faa.gov/airports_airtraffic/air_traffic/publications/at_orders/media/AIR.pdf


Slide18 l.jpg

FAA Order 7400.2 airspace around airports to protect flight crewmembers from temporary visual impairment during critical flight operations. FLIGHT ZONES


Slide19 l.jpg

FAA Order 7400.2 airspace around airports to protect flight crewmembers from temporary visual impairment during critical flight operations. FLIGHT ZONES


Slide20 l.jpg

Potential Visual Effects airspace around airports to protect flight crewmembers from temporary visual impairment during critical flight operations.

vary with Laser Power and Distance from Source


Slide21 l.jpg

FAA Responsibilities: airspace around airports to protect flight crewmembers from temporary visual impairment during critical flight operations.

  • FAA Order 7400.2requires the FAA to conduct an aeronautical study for purposed outdoor laser activities to determine the potential effects upon aircraft operations.

  • FAA issues a letter of determination (Objection or Non-Objection).


Slide22 l.jpg

Research was needed to validate the newly established exposure limits were adequate to ensure aviation safety for pilots in a cockpit environment.


Slide23 l.jpg

FAA/USAF exposure limits were adequate to ensure aviation safety for pilots in a cockpit environment.

Flight Simulator Study


Slide24 l.jpg

Effects of Laser Illumination on Operational and Visual Performance of Pilots Conducting Terminal Operations

  • 34 Subjects

  • 12 Approach and 4 Departure Maneuvers

  • Frequency Doubled Nd:YAG (532 nm) Laser

  • 4 Levels of Laser Exposure (included one zero level exposure)


Slide25 l.jpg

FAA 737 Flight Simulator Performance of Pilots Conducting Terminal Operations

View of final approach to runway at 100 feet AGL

Kodak DC240, aperture f/2.8, shutter speed 1/6 s


Slide26 l.jpg

Irradiance level: 0.5 Performance of Pilots Conducting Terminal OperationsµW/cm2

Simulates the effect of a 5 mW green laser pointer as seen from 3,000 feet away, or a 300 mW laser from 16,000 feet away


Slide27 l.jpg

Irradiance level: 5 Performance of Pilots Conducting Terminal OperationsµW/cm2

Simulates the effect of a 5 mW green laser pointer as seen from 1,000 feet away, or a 300 mW laser from 6,700 feet away


Slide28 l.jpg

Irradiance level: 50 Performance of Pilots Conducting Terminal OperationsµW/cm2

Simulates the effect of a 5 mW green laser pointer as seen from 330 feet away, or a 300 mW laser from 2,400 feet away


Slide29 l.jpg

Results of the simulator study indicated that the changes made to FAA Order 7400.2 were adequate to protect aviators from visual impairment in the Critical and Laser-Free Zones around airports.


Slide30 l.jpg

Office of Aerospace Medicine Technical Reports made to FAA Order 7400.2 were

Available at:http://www.faa.gov/library/reports/medical/oamtechreports/index.cfm


Slide31 l.jpg

Guidance for Laser Proponents and Regulatory Personnel Include:

SAE Aerospace Recommended Practice and Aerospace Standard Reports

  • ARP 5535 – Observers for Laser Safety in the Navigable Airspace

  • ARP 5572 – Control Measures for Laser Safety in Navigable Airspace

  • AS 4970 – Human Factors Considerations for Outdoor Laser Operations in the Navigable Airspace


Slide32 l.jpg

  • American National Standards Include:

  • Institute (ANSI):

    • ANSI Z136.1- American National Standard for Safe Use of Lasers

    • ANSI Z136.6- American National Standard for Safe Use of Lasers Outdoors

  • International Civil Aviation Organization (ICAO):

    • SARP (Standard and Recommended Practice)

    • Manual on Laser Emitters and Flight Safety


Slide33 l.jpg

Laser Pointers – A New Dilemma Include:

As incidents associated with laser displays declined, the increased availability and popularity of handheld lasers presented an increasing threat to aviators. Between 1 January 2004 and 31 January 2005, there were 90 reports of laser illumination. More importantly, 93% occurred in the last 3 months of the study period.


Slide34 l.jpg

In recent years, more powerful handheld lasers have become affordable. Greenlasers are especially popular because they can appear up to 35 times brighter than some redlaser pointers with similar output power.


Slide35 l.jpg

Green laser affordable. pointers are now responsible for > 86% of aircraft lazing incidents. Their light (532 nm) is near the human eyes’ peak photopic and scotopic sensitivity.


Slide37 l.jpg

Laser Pointers on Steroids affordable.

Class 3B handheld lasers

are available on the Internet. Within the NOHD, momentary exposure (≤ 0.25 s) can cause eye damage.

Wavelengths: 405, 473, 532, 635, 650 nm

Power output: 5 – 400 mW

Range: up to 20 miles

.


Slide38 l.jpg

DOT Secretary Announces New Policy affordable.

On January 12, 2005, Secretary of Transportation, Norman Mineta, announced the publication of a new Advisory Circular, entitled “Reporting of Laser Illumination of Aircraft” (AC No: 70-02).


Slide39 l.jpg

Advisory Circular: AC 70-02 affordable.

New FAA policy

(AC 70-02) was established to protect aircrews and passengers, improve reporting and enforcement, and to discourage future laser incidents.


Slide40 l.jpg

Since Issuance of AC 70-02: affordable.

  • The reporting process has improved,

  • Communication and coordination between local air traffic authorities and law enforcement have been enhanced, and

  • Arrests of perpetrators have increased.


Slide41 l.jpg

The Frequency of Laser Incidents by Year affordable.

Reports of illumination incidents for both the aircraft and, more importantly, the cockpit, have increased dramatically from 2004 through 2007.


Slide42 l.jpg

Dec. 29, 2004 affordable. - A New Jersey man was charged under federal Patriot Act anti-terrorism laws (fines up to $500,000 and/or 25 years in prison) after he allegedly shone a green laser pointer at a commuter aircraft from about 4,100 feet. Charges were later reduced to lying to a federal agent.


Slide43 l.jpg

August 15, 2007 affordable. - The FBI arrested a 47-YO man from Clint (TX) for shining a laser at commercial airplanes. The confiscated device was a Class 3B laser about the size of a flashlight. The FBI believed he may be connected to three similar illumination incidents. The suspect could have faced up to 20 years in prison.

http://www.kfoxtv.com/news/13903480/detail.html


Slide44 l.jpg

June 4, 2008 affordable. - A 24-YO man was charged with four counts of discharging a laser and causing the pilots to be temporary visual impaired or disoriented. The green beam was directed at two planes landing at Cleveland (OH) Hopkins International Airport: a Life Flight helicopter, and a Cleveland police helicopter. Police found the suspect in the rear passenger seat of a car holding the laser. He was later convicted and sentenced to 3 years in prison.

http://blog.cleveland.com/metro/2008/06/man_accused_of_pointing_laser.html


Slide45 l.jpg

May 8, 2008 affordable. – A police helicopter pilot was temporarily blinded by a laser illumination as he flew over Lancashire (UK). The pilot took "evasive action" while in mid-air to avoid crashing to the ground during the incident. A 45-YO man was arrested. It was the third incident in seven days where a helicopter pilot had been dazzled by lasers. The pens used had been bought on eBay and were believed to be more powerful than a normal laser pen.

http://www.lep.co.uk/news/Man-arrested-in-helicopter-laser.4061881.jp


Slide46 l.jpg

March 5, 2008 affordable. - Transport Canada reports indicate laser incidents are occurring with an alarming frequency. There have been 11 incidents reported in Ontario since last March, but many more may have gone unreported. A total of 33 pilots across Canada have reported being flashed by a laser beam while flying.

http://www.thestar.com/News/GTA/article/309525


Slide47 l.jpg

August 15, 2007 affordable. - Australia introduced 2-year jail terms and fines of up to $30K for shining lasers on aircraft in flight. The government says incidents are happening 2-3/week in Australia. Authorities have reports of 170 lasing incidents since January 2006. The government announced it would ban imports of high-intensity laser pointers (effective July 1, 2008).

[email protected] .com


Slide48 l.jpg

March 30, 2008 affordable. - Six aircraft flying into Sydney (Australia) Airport were hit by blinding green lights in what safety officials say is the city's worst laser attack. It was the first recorded "cluster attack" in which three or four people used lasers to make a coordinated attack on aircraft coming into the airport over heavily populated suburbs. Air traffic control closed the approach flight path and diverted incoming aircraft to a different runway, forcing delays in some flights. The laser attacks were from 10:15 to 10:30 pm.

http://www.smh.com.au/news/national/laser-snipers-hit-planes/2008/03/29/1206207485440.html


Slide49 l.jpg

April 2008 affordable. - A new law proposed by the Premier of New South Wales declares possession of the handheld lasers a serious crime, punishable by up to 14 years in prison, depending on the device’s power. Weaker lasers could carry a $5,000 fine or 2 years in jail, and there would be exemptions only for teachers, construction crews, and certain scientists.

http://thelede.blogs.nytimes.com/2008/04/21/australia-takes-on-laser-lunatics/?hp


Slide50 l.jpg

Percentage of Cockpit Illuminations affordable.

by Altitude, Flight Zone and Year

K Feet

2004

2005

2006

2007

TOTAL

Laser Free Zone

0 – 0.9

0.0%

3.4%

2.7%

7.7%

5.2%

1 – 1.9

6.7%

7.5%

13.1%

11.8%

11.3%

LFZ Total

6.7%

11.0%

15.8%

19.6%

16.5%

Critical Flight Zone

2 – 2.9

6.7%

9.6%

11.3%

16.3%

13.3%

3 – 3.9

26.7%

11.0%

12.6%

13.8%

13.1%

4 – 4.9

20.0%

10.3%

14.4%

8.8%

11.0%

5 – 5.9

0.0%

11.0%

7.2%

6.3%

7.4%

6 – 6.9

6.7%

7.5%

10.8%

8.8%

9.1%

7 – 7.9

6.7%

5.5%

6.8%

4.7%

5.5%

8 – 8.9

13.3%

10.3%

6.3%

4.1%

6.2%

9 – 9.9

13.3%

3.4%

2.3%

3.0%

3.1%

CFZ Total

93.3%

68.5%

71.6%

65.8%

68.6%

>10K Total

0%

20.5%

12.6%

14.6%

14.9%

Aircraft Cockpit Illumination by Altitude

Note: 16.5% of illuminations of the aircraft cockpit are below 2000 feet AGL. Almost 69% of illuminations are in the CFZ.


Slide51 l.jpg

Laser Incident Rate by Region and Year affordable.

The incident rate was highest in the AWP (0.86/100K flight operations) for the 2004-2006 period.


Traffic volume by region l.jpg
Traffic Volume by Region affordable.

By region, the percentage of traffic volume is disproportionate to the rate of illuminations.

Note: The Western Pacific region’s incident rate was 3.6 times higher than that of the Southern region (0.86 and 0.24/100K flight operations, respectively) although both had similar traffic volumes (22 and 21%, respectively).

The percentage of traffic volume for a particular region is the number of flight operations in that region divided by the total number for the NAS.


Slide53 l.jpg

Airports with 10 or More Laser Incidents affordable.

Incident clusters specific to a particular airport can distort the incident rate (per 100K flight operations) for an entire region. Clusters occur at random over periods of a few days or months.


Slide54 l.jpg

Visual and Physiological Effects and Operational Problems by Altitude

ZONE

VISUAL EFFECTS

PAIN/

INJURY

OPERATIONAL

PROBLEM

COCKPIT

ILLUMINATIONS

GLARE

FLASH-

BLINDNESS

AFTER-IMAGE

LASER FREE

4

6

9

5

10

18

CRITICAL

8

14

9

7

13

37

≥10K

5

5

1

0

1

9

TOTAL

17

25

19

12

24

64

Of 746 cockpit illuminations where altitude was provided, 8.6% described one or more adverse effects (2004-2007). These include visual effects (8.2%), pain and/or possible injury (1.6%), and operational problems (3.2%).


Slide55 l.jpg

Percentage of Laser Illuminations Altitude

by

Month

Type of Flight

Laser Illuminations occur most frequently in November, December, and February, and least frequently in May, June, and July. About 66% of all illuminations are of commercial aircraft.


Slide56 l.jpg

Percentage of Laser Illuminations by Time of Day Altitude

Note: Laser Illuminations occur most frequently from 6:30 – 11:30 p.m.


Slide57 l.jpg

Summary Altitude

  • The incidence of illumination is significantly higher in the Western Pacific region.

  • Almost 70% of laser incidents occur between 2K and 10K feet AGL

  • Almost 70% of all incidents occur between the hours of 7 to 11 pm (25% between 9 – 10 pm) .

  • The fewest incidents occur during the months of May, June, and July (16%).

  • Percentage of incidents by type of flight:

    • 66% Commercial

    • 6% Helicopters (Med Evac./Law Enf.)


Slide58 l.jpg

Conclusions Altitude

  • Incidents associated with authorized laser operations are rare, but illumination reports from handheld lasers have increased in recent years. This may be due to increased awareness and a better reporting system (AC 70-2).

  • Handheld lasers are cheaper and more powerful.

  • Better consumer awareness may be needed concerning misuse and potential penalties (e.g., FDA labeling).

  • Continued monitoring by aviation & law enforcement is warranted.
