Presentation Transcript
Slide1 l.jpg

Textbook:

Meteorology

Understanding the Atmosphere

2nd Edition

Ackerman & Knox

Prof. Steve Ackerman

University of Wisconsin

2009 Teaching Excellence Award

American Meteorological Society



Topics i propose we cover in this course l.jpg
topics I propose we cover in this course

and of course Chapter 1) Introduction


Chapter 1 introduction l.jpg
chapter 1: Introduction

1.1 Weather vs climate

1.2 Atmospheric composition

  • Focus on greenhouse gases

    1.3 Atmospheric structure

  • Focus on the ozone hole


History of meteorology l.jpg
History of meteorology

  • Babylonians, Chinese: astrometeorology

  • Aristotle: “meteorologia”

  • 16th-17th century: instruments and scientific method (Descartes)

    • barometer (Torricelli, 1643, mercury)

    • thermometer (Galileo, 1592, Fahrenheit, 1714)

  • 1843: real-time data via telegraph

  • 1920’s: polar front theory (Bergen school)

  • 1940’s: upper-air observations (radiosondes)

  • 1950’s: radar

  • 1960’s: first satellites and NWP models


Weather our own weather server l.jpg

Chapter 1.1: weather vs. climate

weather …our own weather server

more weather links


Slide7 l.jpg

Hurricane Katrina

8/28/05 17 UTC


Slide10 l.jpg

precipitation

topography


Slide11 l.jpg

January mean temperature

North America

Europe

London

Boston

Scotland in March

Off Labrador in March



Slide13 l.jpg

  • Weather:

    • A depiction of the state of the atmosphere at one point in time.

  • Climate:

    • A depiction of the ‘typical’ weather, based on observations taken over a period of time.


Which one is a statement about weather which one about climate l.jpg

Yesterday’s high in Laramie was 69°F

That’s 4 degrees below the average high for this time of the year.

Which one is a statement about weather, which one about climate?

Click here for the current Laramie weather forecast


Weather or climate l.jpg
weather or climate ?

from 3-monthly to daily precip


Weather or climate16 l.jpg
weather or climate ?

image source


What is an anomaly l.jpg
What is an ‘anomaly’?

  • A departure from ‘normal’.

    • Especially climate data are often shown as anomalies, e.g. a drought.



Slide19 l.jpg

The atmosphere, like any other fluid, behaves chaotically

Edward Lorenz, 1963: Deterministic nonperiodic flow. Journal of Atmospheric Sciences. Vol.20 : 130—141.

Edward Lorenz in Wikipedia


Climate is not constant l.jpg
“climate” is not constant!

last 150,000 years

last 1,000 years




Regional variations in long term change usa l.jpg
regional variations in long-term change: USA

US temperature trend 1941-2005



Can we predict climate fluctuations l.jpg
Can we predict climate fluctuations?

  • We know that weather becomes unpredictable after ~10 days

  • So how can the CPC produce a seasonal outlook for the drought?

  • Climate anomalies tend to persist for some time, months to seasons.

  • Why ?



El ni o has global impacts l.jpg
El Niño has global impacts... equatorial Pacific


El ni o has some effect on precipitation in the us l.jpg
El Niño has some effect on precipitation in the US. equatorial Pacific

winter precipitation anomaly

Why?


1998 el ni o sst jet stream l.jpg
1998 El Niño: SST & jet stream equatorial Pacific

anomalous

sea surface temperature

jet stream


Slide30 l.jpg

Coupled atmosphere-ocean models predict the SST out to about a year.

An El Niño is predicted for next winter …

source


Slide32 l.jpg

Conclusion: there is some limited guidance for the season ahead, but wrong predictions should not be a surprise.

  • That does not mean that long-term climate change is even less certain.

  • We cannot predict that July 2035 will be an ‘unusually’ warm month compared to what is typical then, but we are confident that that the 2030s will be warmer than the current decade.

  • This is based on climate model predictions that take into account changes in greenhouse gases, earth surface conditions, and clouds.


Slide33 l.jpg
Predicted global mean temperature change between 2000 and 2100 for 5 different CO2 emission scenarios.

source


Slide34 l.jpg

Both study the atmosphere 2100

Key atmospheric observations



Slide36 l.jpg

360 ppm 2100




Slide39 l.jpg

The long-term rise in CO 2100 2 levels parallels fossil fuel use.




Pop quiz l.jpg
Pop quiz 2100

  • The Earth’s atmosphere consists mostly of:

    • a: carbon dioxide;

    • b: oxygen;

    • c: water vapor;

    • d: nitrogen.


Slide43 l.jpg

Discussion 2100 : our atmosphere is key to the habitability of the Earth. Are we alone in that regard, or do other planets have an atmosphere as well ?



Pop quiz45 l.jpg
Pop quiz 2100

  • Compared to the Earth, both Mars and Venus:

    • a: are warmer;

    • b: have a higher surface pressure;

    • c: are closer to the Sun;

    • d: have relatively more CO2 in their atmosphere.



Slide48 l.jpg

radiosonde balloon 2100

satellites

real-time soundings plotted



Pop quiz50 l.jpg
Pop quiz 2100

  • The lowest two layers of the atmosphere are:

    • a: thermosphere, stratosphere;

    • b: troposphere, ionosphere;

    • c: mesosphere, stratosphere;

    • d: troposphere, stratosphere.



Slide55 l.jpg

Aurora Australis, May ’91 2100

Space Shuttle Discovery


Slide56 l.jpg

O 2100 3


Good vs bad ozone l.jpg

“Good”: Stratospheric ozone, which screens out much of the incident UV radiation from the sun.

“Bad”: Tropospheric ozone, an anthropo-genic air pollutant , damages health and the environment.

“Good” vs. “Bad” Ozone


Chapman cycle textbook p 446 449 l.jpg
Chapman cycle the incident UV radiation from the sun.textbook, p. 446-449

Formation:

  • O2 +hn 2O (l<0.25 mm - UV-c)

  • O + O2 + M  O3 + M

  • O3 +hn O + O2 (l<0.31 mm - UV-b)

  • O + O3 2 O2

Destruction:


Cfc gases destroy the good ozone l.jpg
CFC gases destroy the “good” ozone the incident UV radiation from the sun.

Montreal protocol (1987): complete phase-out of CFC production


Slide60 l.jpg

UV radiation penetrating to the Earth surface the incident UV radiation from the sun.

Laramie (2.2 km)

UV-c

UV-b

UV-a

(skin cancer, eye cataracts ...)


Slide61 l.jpg

O the incident UV radiation from the sun.3

M


Surface observations l.jpg
Surface observations the incident UV radiation from the sun.


Surface observations63 l.jpg
Surface observations the incident UV radiation from the sun.

temperature (°F)

sea level pressure (mb)

weather

5

wind direction and speed

visibility (miles)

dewpoint (°F)

cloudiness

learning applet


Slide64 l.jpg

Weather symbols the incident UV radiation from the sun.


Slide65 l.jpg

Cloud cover the incident UV radiation from the sun.


Sea level pressure l.jpg
Sea level pressure the incident UV radiation from the sun.

If reported value greater than 500:

Initial 9 is missing. Place it on left, then divide by 10.

For example: 827 becomes 982.7 mb.

If reported value less than 500:

Initial 10 is missing. Place it on left, then divide by 10.

For example: 027 becomes 1002.7 mb.


Slide67 l.jpg

speed the incident UV radiation from the sun.

wind

1 Knot = 1.15 MPH

direction


Current surface observations l.jpg
current surface observations the incident UV radiation from the sun.


Summary l.jpg
summary the incident UV radiation from the sun.

  • Chapter 1, intro to the atmosphere

    • weather vs climate

    • vertical structure of the atmosphere

    • atmospheric gas composition

  • Chapter 15, human influence on climate

    • climate change (p. 441-443 and p. 453-464)

      - to be revisited
