Presentation Transcript


By adesola fatilewa national population commission at dar es salaam tanzania 9 th 13 th june 2008 l.jpg

DATA CAPTURE – PROCESSING 2006 POPULATION & HOUSING CENSUSOFNIGERIAPresented at UN Regional Workshop on Census Data Processing

By

Adesola Fatilewa

NATIONAL POPULATION COMMISSION

At Dar-es-Salaam, Tanzania

9th -13th June 2008


Slide2 l.jpg

MAP OF NIGERIA 36 STATES AND FCT ABUJA


About nigeria l.jpg

ABOUT NIGERIA

  • NIGERIA IS THE MOST POPULATED COUNTRY ON THE AFRICAN CONTINENT AND THE 10th BIGGEST IN THE WORLD.

  • AN AREA OF ABOUT 9.28 MILLION SQ. KMS.

  • POPULATION OF 140.2million BY 2006 CENSUS

  • COMPRISES OF 36 STATES AND FEDERAL CAPITAL TERRITORY

  • 774 LOCAL GOVERNMENT AREAS - LGA (DISTRICTS)

  • DELINEATED INTO OVER 662,000 ENUMERATION AREAS


Background l.jpg

Background

  • Since the late nineties NPopC was being inundated with proposals on various document scanning systems.

  • As at 2005, statements were being made,suggesting that the idea of using scanning technology was utopia.


P rocessing pre test and trial census l.jpg

Processing Pre-test and Trial Census

  • A scanning system was used to process the second pre-test of April 2004.

  • Number of documents processed was about of 100,000 forms as survey covered one local government area (Lga) in each of the 36 States of the country and the Federal Capital Territory.

  • The forms were only optical mark readable and editing was mainly to correct alignment errors.


Processing pre test and trial census continued l.jpg

Processing Pre-test and Trial Census Continued

  • Another solution provider supplied five scanners along with two servers for the processing of the Trial Census.

  • Trial Census which took place in April 2005 covered about 5% of the country, which translated to about 10million population.

  • Processing was distributed between two

    data processing centres (DPCs); Lagos and Kano


Lessons learnt l.jpg

Lessons learnt

  • staff were identified for suitable roles in data processing of the main census

  • staff gained experience on the new technology

  • alignment and recognition problems detected and rectified

  • decision taken on appropriate archiving system for storage and retrieval of documents

  • need to have various reports to enable management follow progress of processing

  • decision to completely eliminate manual coding and editing


Data capture 2006 census l.jpg

Data capture 2006 census

  • Scanning technology was fully deployed in processing Nigeria 2006 Population and Housing Census.

  • This was achieved with 21 scanners distributed in 7DPCs located strategically across the country.

  • Immediately after the census, OMR/ICR forms (questionnaires) used to collect data started arriving at the DPCs.

  • Inventory control was done using an EA tracking system


Data capture 2006 census9 l.jpg

Data capture 2006 census

  • Documents were enveloped by EA, tied in convenient batches and stacked on labelled shelves

  • At the end of the receiving/archiving exercise, batches were retrieved for data capture


Paper preparation before scanning l.jpg

Paper Preparation before Scanning

Envelope

Envelope

BatchHeader

BatchHeader

ARCHIVE

NPC0x

cut the paper

with cutting machine

Otherwise:paper damaged, introduce dirt on the scanned image, reject increased

NPC0x

Bring the envelopes with the questionnaires from the Archive room

Remove the envelopes

STORE IN Program

Print and add Batch Header

Jog the paper with the supplied jogger


Data processing steps at dpcs l.jpg

Server

Jog Docs

Scanner

Edit Stations

Data Processing Steps at DPCs

  • Schematic diagram


Scanner views l.jpg

Scanner Views

Scanner Feeder

Questionnaire processing


Scanning l.jpg

Scanning

  • Sheets loaded on the feeder in batches separated by batch header went through transport system of scanners HR80 SC

  • Scanner speed was 8000 sheets/hr barring jams and other loading difficulties.

  • Scanning was effected by ProScan software and scanned documents were collected at the output tray.

  • The sheets were returned into their envelopes and sent back to archive


Sc80hc prosort keops l.jpg

SC80HC + ProSort + kEOPs

5. kEOPs recognition

Work

Data

Storage

4. Data + Images

2.Scanner

CS Pro

8. DVD

7. Export

Archive

Data

Storage

3. Paper

Archive

Batch Header

NPC0x

HQ

9. TAPE

MANUAL WORK

1. Preparation for Scanning:

cut & jogg

Carto

6. Correction Balancing

8. Local reports


Editing l.jpg

Editing

  • Two levels of Editing:

    • First level at DPC

    • Second level at DVU at NPopC hq. in Abuja


First level editing l.jpg

XML format stored in SAN on servers networked to scanners

Forms in XML loaded onto edit stations

The editing system used was called KEOPs and it was designed to check geographic ids against the batch headers, check ‘mandatory fields’

Transactions or whole batches could be passed for ‘balancing correction level’ which was handled by more experienced staff designated ‘Supervisor’,

First Level Editing


Typical keops edit screen l.jpg

Typical KEOPs Edit Screen


Export l.jpg

EXPORT


Second level editing l.jpg

Second Level Editing

  • Data in ASCII,was encrypted, backup on cds at the DPC and sent to NPopC Hq., Abuja

  • Data is decrypted, validated, collated and further edited at Abuja

  • Data is then checked for completeness to ensure that each delineated EA for any local government had data associated with it

  • CsPro package was then utilized to edit data and aggregate appropriately


Second level editing continued l.jpg

Second Level Editing Continued

  • Structure checks

  • Range checks

  • Skip pattern checks

  • Inter-record and intra-record consistency checks

  • Imputation methods applied for missing or invalid values:

    • Hot deck’

    • and ‘Cold deck’ or a combination of both


Occupational coding l.jpg

Occupational Coding

  • The only data that was not coded on the field was occupation

  • The occupational coding was effected automatically using a computer-assisted coding system

  • ‘Exceptional Coding’ was applied where coding clerk could not find an appropriate occupation code for an occupation


Slide22 l.jpg

Challenges

  • Ensuring that documents for particular geographic locations were archived in sections of the archive and shelves designated for them

  • That all forms were separated before taking them for scanning

  • Breakdown of jogger

  • Rate of getting documents ready for scanning was slower than rate of scanning

  • Difficulty in maintaining belts and fixing them over pulley

  • That correct batch headers were properly placed on EA batches and that after scanning, EAs were correctly returned to their marked envelopes


Challenges continued l.jpg

Challenges Continued

  • Instances of poor field work which resulted in ‘missing values’ of ‘mandatory fields’, outright wrong values for fields

  • Difficulty in linking forms for households of greater than 8 persons

  • Integration of the two solution providers: form design and equipment and software solutions were provided by two different companies

  • Cleaning of blank records of data associated with them at data capture

  • Dealing with sensitivity of Nigerians to census figures

  • lack of reliable and uninterrupted power supply


Conclusion l.jpg

Conclusion

  • The Commission was proud that the decision to deploy a new technology for part of the processing of Nigeria 2006 Population and Housing Census was a success

  • About 35million forms were scanned and edited using 21 scanners, over 220 edit stations and data in XML format and ASCII stored in about 76TB of SANs. All scanning and first level editing was completed within nine months of enumeration period.

  • About 1000 Nigerians were trained and gained expertise in various aspects of the scanning technology

  • There is a need for intensive trainings in these areas of OMR/OCR forms design and development of appropriate scanning softwares.


Slide25 l.jpg

End

  • Thank you for your attention
