1. IB Biology Review Chapter 35: Plant Structure
2. What are the two types of plants IB focuses on? Angiosperms
Monocots / Monocotyledonous
Eudicots / Dicots / Dicotyledonous
What do the names mean?
Monocot: One cotyledon
Dicot: Two cotyledons
What is a cotyledon?
Seed leaf
3. What are the main structures in a plant? Leaves
Stem
Roots
Flowers
4. How does leaf structure differ in monocots and eudicots? Monocots
Parallel leaf veins
Eudicots
Netlike leaf veins
5. How does the arrangement of vascular tissue differ in monocots and eudicots? Monocots
Scattered throughoutstem
Eudicots
In a ring on the edge of the stem
6. How does the root structure differ in monocots and eudicots? Monocots
Fibrous root
No main root
Eudicots
Taproot
Primary root
7. How does the number of flower parts differ in monocots and eudicots? Monocots
Petals etc. in multiples of 3
Eudicots
Petals etc. in multiples of 4 or 5
8. Function of Leaf Tissues Palisade Mesophyll
main photosynthetic cells (have many chloroplasts) in leaf
located near top of leaf (sun) to maximize rate of photosynthesis
Spongy Mesophyll
near bottom of leaf where CO2 enters stomata and oxygen and water leaves
air spaces between cells allow gas movement
Xylem
centrally located next to palisade mesophyll
provides easy water and nutrient supply to palisade cells for photosynthesis
9. Function of Leaf Tissues cont. Phloem
centrally located next to palisade mesophyll
takes away sugars produced by photosynthesis
Guard cells and stomata
located on the bottom of the leaf because that is where gas and water vapor exchange occur
this way, no interference with photosynthesis
Upper epidermis
Top layer of cells where sun hits the leaf, covered with cuticle
Cuticle
waxy coating to prevent water loss
10. Leaf and Leaf Tissue Structure Cuticle
Upper / lower epidermis
Palisade mesophyll
Xylem
Phloem
Spongy mesophyll
Guard Cell
Stoma
11. Stem Structure in Eudicots Consists of
Epidermis
Vascular Bundle
Xylem
Phloem
Cortex
Endodermis
Pith
BE ABLE TO DRAW THIS
12. Function of Roots What do roots do for the plant?
Absorb nutrients
Absorb water
Keep the plant in the ground
For some, roots store excess energy
What are root hairs?
Small root-like projections off the root
Increase surface area of root
13. What are two modifications of leaves? Spines (as on a cactus)
protect the plant from herbivory
Tendrils (as on pea plant)
help the plant cling to objects for support and growth
14. What are two modifications of stems? Stolons (as on raspberry plant)
horizontal stems that grow along the ground surface and allow the plant to extend itself into adjacent areas fast
a form of asexual reproduction
Bulbs (like onion)
Vertical underground shoots consisting of enlarged leaves that store food
15. What are two modifications of roots? Storage roots (like sweet potato)
purpose is storage of starch and water
Pneumatophores/ air roots (as in mangroves and bald cypress trees)
these roots extend above the surface of the water in waterlogged soils to allow oxygen to get to the roots
16. Two Types of Plant Growth Apical
Vertical growth / height
Lateral
“Sideways” growth / width
Which group of plants (monocots/eudicots) usually has both apical and lateral growth?
Eudicots
17. Apical and Lateral Growth Where does growth occur?
Apical meristems
Extend the length of root or stem
Cell division occurs in meristematic region (zone of elongation) at the end of root or stem
Lateral Meristems
Increase girth of stem
Cell division occurs in vascular cambium around stem
18. Function of Auxin plant hormone that stimulates cell elongation
one of the processes that auxin controls is phototropism
directional growth toward the source of light
shoot tips respond to light intensity by producing more auxin on the side with less light, making that side grow longer, thus bending the shoot tip toward the light
19. Function of Auxin
20. 1. Outline three differences between the structures of dicotyledonous (eudicot) and monocotyledonous plants. (6 marks) Monocots
One cotyledon
Parallel leaf veins
Scattered vascular tissues
Fibrous root system
Flower parts in multiples of 3
21. 2. The leaves of plants are adapted to absorb light and use it in photosynthesis. Draw a labelled diagram to show the arrangement of tissues in a leaf. (6 marks) Award [1] for each of the following structures, shown in the correct relative position and labelled. Individual cells are not needed but do not penalize if they are shown.
upper epidermis;
palisade layer / mesophyll;
spongy layer / mesophyll;
lower epidermis;
xylem (in a major or minor vein);
phloem (in a major or minor vein);
guard cells; (do not accept stoma/stomata only)
22. 3. Draw and label the tissues within a leaf and explain the relationship between the distribution of those tissues and their function. (12 marks) palisade mesophyll: Main photosynthetic cells in leaf, located near top of leaf to maximize rate of photosynthesis
spongy mesophyll: Near bottom of leaf where Co2 enters stomata and oxygen and water leaves – air spaces between cells allow gas movement.
xylem: Centrally located next to palisade mesophyll to provide easy water and nutrient supply to palisade cells for photosynthesis
phloem: Centrally located next to palisade mesophyll to take away sugars produced by photosynthesis
guard cells: Located on the bottom of the leaf because that is where gases enter. This way, no interference with photosynthesis
upper epidermis: On top of leaf – they have a waxy coating to prevent water loss (sun is hitting top)
23. 4. Identify and describe modifications of roots, stems, and leaves for different functions ( 10 marks) Storage roots (like sweet potato): purpose is storage of starch and water
Pneumatophores / air roots (as in mangroves and bald cypress trees): these roots extend above the surface of the water in waterlogged soils to allow oxygen to get to the roots
Stolons: horizontal stems that grow along the ground surface and allow the plant to extend itself into adjacent areas fast. Is a form of asexual reproduction
Bulbs (like onion): vertical underground shoots consisting of enlarged leaves that store food
Spines (as on a cactus): protect the plant from herbivory
Tendrils (as on pea plant): help the plant cling to objects for support and growth
24. 5. Compare growth due to apical and lateral meristems in dicotyledonous plants. (3 marks) Apical meristems
Extend the length of root or stem
Cell division occurs in meristematic region (zone of elongation) at the end of root or stem
Lateral Meristems
Increase girth of stem
Cell division occurs in vascular cambium around stem
25. 6. Explain the role of auxin in phototropism. (6 marks) shoots of plants grow towards light / positively phototropic;
roots grow away from light / regularly phototropic;
shoot tips produce auxin;
acts as a growth promoter
allows cell expansion;
is distributed in the tip from the lighter to the darker side;
plant bends towards the light;
