Reaction Stoichiometry

Reaction Stoichiometry. Introduction. Reaction stoichiometry involves the mass relationships between reactants and products in a chemical reaction. It is based on chemical equations similar to the ones studied in the last section.

ingo
Download Presentation

Reaction Stoichiometry

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Reaction • Stoichiometry

  2. Introduction Reaction stoichiometry involves the mass relationships between reactants and products in a chemical reaction. It is based on chemical equations similar to the ones studied in the last section. All reaction stoichiometry calculations start with a balanced equation. You will need to be familiar with gram/mole relationships as studied earlier this year.

  3. The mole enables chemists to move from the microscopic world of atoms and molecules to the real world of grams . • Stoichiometry problems are classified between the information given in the problem and the information you are expected to find, the unknown. • The given and the unknown may be expressed in grams or moles. • The masses in the reaction are usually expressed in grams. • Definition of mole: • mole of a substance = grams of substance/MW of substance

  4. You will need to use: • molar ratios in a balanced equation. • molar masses of reactants and products. • balancing equations. • conversions between grams and moles.

  5. Mole Ratios A mole ratio converts moles of one compound in a balanced chemical equation into moles of another compound. All stoichiometry problems use mole ratios.

  6. Example Reaction between magnesium and oxygen to form magnesium oxide. ( fireworks) 2 Mg(s) + O2(g) 2 MgO(s) (balanced) Mole Ratios: 2 : 1 : 2

  7. Stoichiometry (working with ratios) Ratios are found within a chemical equation. 2HCl + Ba(OH)2 2H2O + BaCl2 1 1 coefficients give MOLAR RATIOS 2 moles of HCl react with 1 mole of Ba(OH)2 to form 2 moles of H2O and 1 mole of BaCl2

  8. Practice Problems 1) N2 + 3 H2 ---> 2 NH3 Write the mole ratios for N2 to H2 and NH3 to H2.

  9. Review: Molar Mass A substance’s molar mass (molecular weight) is the mass in grams of one mole of the compound. CO2 = 44.01 grams per mole H2O = 18.02 grams per mole Ca(OH)2 = 74.10 grams per mole

  10. Review: Chemical Equations C2H5OH + 3O2® 2CO2 + 3H2O reactants products 1 mole of ethanol reacts with 3 moles of oxygen to produce 2 moles of carbon dioxide and 3 moles of water

  11. Types of Stoichiometry Problems

  12. Problem Type 1: Given and unknown quantities are in moles Amount in moles of known substance Amount in moles of unknown substance How many moles of lithium hydroxide are required to react with 20 moles of CO2

  13. Given: amount of CO2 = 20 moles Unknown: amount of LiOH in moles Amount of CO2 in moles Amount of LiOHin moles mol CO2 x molLiOH / mol CO2 = molLiOH 20 molCO2x 2 molLiOH / 1 molCO2 = 40 molLiOH mole ratio

  14. Problem Type 1 Mole – Mole Conversions When N2O5 is heated, it decomposes: 2N2O5(g) 4NO2(g) + O2(g) a. How many moles of NO2 can be produced from 4.3 moles of N2O5? 2N2O5(g) 4NO2(g) + O2(g) Units match ? mol 4.3 mol

  15. Mole – Mole Conversions When N2O5 is heated, it decomposes: 2N2O5(g) 4NO2(g) + O2(g) a. How many moles of NO2 can be produced from 4.3 moles of N2O5? 2N2O5(g) 4NO2(g) + O2(g) 4.3 mol ? mol Units match 4.3 mol N2O5 = moles NO2 8.6

  16. b. How many moles of O2 can be produced from 4.3 moles of N2O5? 2N2O5(g) 4NO2(g) + O2(g) ? mol 4.3 mol 4.3 mol N2O5 = mole O2 2.2

  17. Problem Type 1: Given and unknown quantities are in moles Amount in moles of known substance Amount in moles of unknown substance How many moles of ammonia are produced when 6 moles of hydrogen gas react with an excess of nitrogen gas.

  18. Given: amount of H2 = 6 moles Unknown: amount of NH3 in moles Amount of NH3in moles Amount of H2 in moles (mol H2) x (mol NH3 / mol H2) = mol NH3 (6 mol H2) x (2 mol NH3/ 3 mol H2) = 4 mol NH3 Mole ratio

  19. Problem Type 2: Given amount is in moles and unknown quantity is in grams Amount in moles of known substance Amount in grams of unknown substance Problem Type 3: Given amount is in grams and unknown quantities are in moles Amount in grams of known substance Amount in moles of unknown substance

  20. Problem Type 2 mole ↔ gram In plants when carbon dioxide reacts with water it produces glucose and oxygen: 6CO2 + 6H2O(l) C6H12O6(s) + 6O2(g) How many grams of C6H12O6 is produced when 3.0 molof water react with carbon dioxide? • 6CO2 + 6H2O C6H12O6+ 6O2 3.0 mol ? grams Units match 3.0 mol H2O = g C6H12O6 90

  21. Problem Type 2 mole ↔ gram In plants when carbon dioxide reacts with water it produces glucose and oxygen: 6CO2 + 6H2O(l) C6H12O6(s) + 6O2(g) How many grams of CO2 is needed to react with 3.0 molof water? • 6CO2 + 6H2O C6H12O6+ 6O2 ? grams 3.0 mol Units match 3.0 mol H2O = g CO2 132

  22. Problem Type 2 mole ↔ gram When magnesium burns in air, it combines with oxygen to form magnesium oxide according to the following equation: 2Mg+ O2(g) 2MgO(s) How many grams of MgO is produced from 2.0 mol of magnesium? • 2Mg + O22MgO 2.0 mol ? grams Units match 2.0 mol Mg = g MgO 80

  23. Problem Type 3 gram ↔ mole When N2O5 is heated, it decomposes: 2N2O5(g) 4NO2(g) + O2(g) a. How many moles of N2O5 were used if 210g of NO2 were produced? 2N2O5(g) 4NO2(g) + O2(g) ? moles 210g Units match 210 g NO2 = moles N2O5 2.28

  24. Problem Type 3 gram ↔ mole Nitric acid is produced from the catalytic oxidation of ammonia • NH3(g) + O2(g) NO(g) + H2O(g) a. How many moles of NO were producedfrom 824g of NH3? • 4NH3(g) + 5O24NO(g) + 6H2O(g) 824g ? moles Units match 824 g NH3 = moles NO 48.4

  25. Steps Involved in Solving Mass-Mass Stoichiometry Problems • Balance the chemical equation correctly • Using the molar mass of the given substance, convert the mass given to moles. • Determine the molar ratio. • Using the molar mass of the unknown substance, convert the moles just calculated to mass.

  26. Problem Type 4 grams ↔ grams When N2O5 is heated, it decomposes: How many grams of N2O5 are needed to produce 75.0 grams of O2? 2N2O5(g) 4NO2(g) + O2(g) 75.0 g ? grams 75.0 g O2 = grams N2O5 506

  27. Working a Stoichiometry Problem 6.50 grams of aluminum reacts with an excess of oxygen. How many grams of aluminum oxide are formed. 1. Identify reactants and products and write the balanced equation. Al + O2 Al2O3 a. What are the reactants? b. What are the products? c. What are the balanced coefficients?

  28. Working a Stoichiometry Problem 6.50 grams of aluminum reacts with an excess of oxygen. How many grams of aluminum oxide are formed? 4 Al + 3 O2 2Al2O3 = 6.50 g Al 1 mol Al 2 mol Al2O3 101.96 g Al2O3 ? g Al2O3 4 mol Al 1 mol Al2O3 26.98 g Al 6.50 x 2 x 101.96÷ 26.98 ÷ 4 = 12.3 g Al2O3

  29. Stoichiometry Review Problem Suppose you want to figure out how many grams of ammonia you can produce if you react 60.0 g of hydrogen gas with excess nitrogen. Remember the balanced chemical equation gives the mole relationship between reactants and products. N2 + 3 H2 2 NH3 1) Take the grams of hydrogen gas (recall that it is diatomic) and convert it to moles: 2) Convert the moles of hydrogen gas to moles of ammonia, using the coefficients in the balanced chemical equation: 3) Convert from moles of ammonia to grams of ammonia using the molecular mass and solve the equation:

  30. How many moles of ammonia are produced when 0.60 moles of nitrogen gas react with hydrogen gas.

  31. Given: amount of N2 = 0.6 moles Unknown: amount of NH3 in moles Amount of N2 in moles Amount of NH3in moles mol H2 x mol NH3 / mol H2 = mol NH3 0.6 mol N2x 2 mol NH3/ 1 mol H2= 1.2 mol NH3

  32. Acetylene gas (C2H2) is produced by adding water to calcium carbide: How many grams of acetylene are produced by adding water to 5.0 grams of CaC2? CaC2 + H2OC2H2 + Ca(OH)2 Balanced? 5.0 g ? grams 5.0 g CaC2 = grams C2H2 2.0

  33. How many moles of CaC2 are needed to react completely with 49.0 g H2O: • CaC2 +2H20 C2H2(g) + Ca(OH)2 How many moles of CaC2 are needed to react 49.0 g of H20? • CaC2+ 2H20 C2H2(g) + Ca(OH)2 49.0g ? moles Units match 49 g H2O = moles CaC2 1.36

  34. Calculating the Percent Yield • The predicted amount of product – which we have been doing with our • stoichiometry problems has been for 100% yield, or the • theoretical yield of a reaction. • The theoretical yield is the maximum amount of product that can be produces in a given reaction. • When chemical reactions take place, they are almost never 100% • complete. A reaction may not go to 100% due to not all the reactants • becoming involved, impurities in the reactants, competing side • reactions, loss of product due to filtering, or just not getting • it all out of the vessel. • The actual yield is how much product can be collected – and measured. • The percent yield is a ratio given by: • Percent Yield = Actual Yield x 100% • Theoretical Yield

  35. Calcium carbonate is decomposed by heating, as shown in the following equation: 1) What is the theoretical yield of this reaction if 24.8 g CaCO3 is heated to yield 13.1 g CaO? Handle like a typical stoichiometry problem: grams to grams Ignore the 13.1 g CaO to solve. This is the actual yield. 2) What is the percent yield?

  36. Standard Molar Volume Equal volumes of all gases at the same temperature and pressure contain the same number of molecules. - Amedeo Avogadro At STP (Standard Temperature and Pressure): 1 mole of a gas occupies 22.4 liters of volume

  37. Gas Stoichiometry #1 If reactants and products are at the same conditions of temperature and pressure, then mole ratios of gases are also volume ratios. 3 H2(g) + N2(g)  2NH3(g) 3 moles H2 + 1 mole N2  2 moles NH3 3 liters H2 + 1 liter N2  2 liters NH3

  38. Gas Stoichiometry #2 How many liters of ammonia can be produced when 12 liters of hydrogen react with an excess of nitrogen? 3 H2(g) + N2(g)  2NH3(g) 12 L H2 2 L NH3 = L NH3 8.0 3 L H2

  39. Gas Stoichiometry #3 How many liters of oxygen gas, at STP, can be collected from the complete decomposition of 50.0 grams of potassium chlorate? 2 KClO3(s)  2 KCl(s) + 3 O2(g) 50.0 g KClO3 1 mol KClO3 3 mol O2 22.4 L O2 122.55 g KClO3 2 mol KClO3 1 mol O2 = L O2 13.7
