Kevin bacon game flood modeling edition

Kevin Bacon game: Flood modeling edition

David Ford Consulting Engineers, Inc.Sacramento, CA

California Water & Environmental Modeling ForumOct. 2006

Kevin bacon game

According to Wikipedia (so it must be right, huh?)The trivia game Six Degrees of Kevin Bacon is based on a variation of the concept of the small world phenomenon which states that any actor can be linked, through their film roles, to Kevin Bacon. The game requires a group of players to try to connect any film actor in history to Kevin Bacon as quickly as possible and in as few links as possible.

Kevin Bacon game

Kevin bacon game example

Kevin Bacon game example

Kevin bacon game example1

Kevin Bacon game example

  • Here is an example, using Elvis Presley:

    • Elvis Presley was in the movie Change of Habit (1969) with Edward Asner.

    • Edward Asner was in the movie JFK (1991) with Kevin Bacon.

Rules of the kevin bacon game flood modeling edition

Rules of the Kevin Bacon game: Flood modeling edition

  • Rule 1: I made up the game, so I get to make up the rules.

  • Rule 2: Forget the movies—no Hollywood here.

  • Rule 3: Link one flood model/study/modeler with another flood model/study/modeler with rational linkages.

Round 1 these 2 studies

Round 1: These 2 studies

Comp study hydrologic analyses

Comp. Study hydrologic analyses

  • Highly regulated stream, so fitting frequency model to gaged data not appropriate.

  • Common design storm approach (at right) wouldn’t work. [Where do you position the rainfall in a 26,000 sq mi watershed?]

  • Alternative approach, documented by Hickey et al. in ASCE journal, relies on gaged flows, historical patterns, composite floodplain concept. [See John Hickey for reprint.]

Comp study hydraulic analyses

Comp. Study hydraulic analyses

  • Hydraulic analyses use unsteady network model—the mother of all UNET models initially.

  • Geometric data collected using digital terrain models and bathymetric surveys (2-ft contour lines.)

  • Over 100 routing reaches and approximately 3,000 cross sections.

  • Extensive use of advanced modeling features, including hydraulic storage areas, lateral weirs, flow diversions, levees, and bridges.

We love the comp study h h mostly

We love the Comp Study H&H (mostly)

We love the Comp Study H&H (mostly)

Yuba feather basin

Yuba-Feather basin

Oroville Dam

New Bullards Bar Dam

Yuba feather operation challenges

Yuba-Feather operation challenges

  • Contributing watersheds large, with much unregulated flow.

  • Rainfall and snowmelt runoff.

  • Travel times long.

  • Dynamic natural + engineered system.

  • Operations managed by several agencies.

Benefit of forecast coordinated operation

Benefit of forecast-coordinated operation

  • Reservoirs interconnected, so decisions felt throughout system.

Benefit of forecast coordinated operation1

Benefit of forecast-coordinated operation

  • Reservoirs interconnected, so decisions felt throughout system.

  • Greatest benefit when operations coordinated. For example, best use of 300 kcfs capacity at confluence considers current and future states of both reservoirs.

Yuba feather f co

Yuba-Feather F-CO

Relationship of comp study and f co

Relationship of Comp Study and F-CO

  • Corps of Engineers did extensive study of hydrology and hydraulics in Central Valley for the Comprehensive (Comp) Study.

  • 2005 DWR study used design hydrographs from Comp Study to investigate flood operation options for Oroville and New Bullards Bar reservoirs.

  • Findings from study supported concept of F-CO project efforts; models formed foundation for work.

Round 2 these 2 storage facilities

Round 2: These 2 storage facilities

D05 watershed and channels

D05 watershed and channels

How should we determine the 100 yr wsel @ howe northrup

How should we determine the 100-yr WSEL @ Howe + Northrup?

 Use 100-yr design storm + 100-yr d/s boundary condition (BC)

 Use 100-yr design storm + ? d/s BC

 Use ? design storm + 100-yr d/s BC

 All of the above

Coincident frequency analysis

“Coincident frequency” analysis

  • If statistically independent, use total probability theorem

  • Pick a stage

  • Use eqn to get probability

  • Pick another stage

  • Repeat, repeat, repeat

  • Combine to get stage-probability

Interior area elevation frequency function at pond

Interior area elevation-frequency function (at pond)

Illustration of computation

Illustration of computation

sum = 0.04

Hydrology for map modernization for san joaquin basin

Hydrology for map modernization for San Joaquin basin?

  • Although study not yet completed, hydrology tools being developed.

  • Can’t use typical simple river approach in lower reaches due to impact of SJ river. So what do we do?

Round 2 d05 pond and new melones dam

Round 2: D05 pond and New Melones Dam

  • Stages in channel upstream of D05 pond affected by watershed runoff AND by pond elevation, which is affected by LAR stage.

  • Need “coincident frequency analysis” to account properly for both upstream and downstream conditions if independent.

  • Stages at some locations in channel downstream of New Melones affected by releases and San Joaquin River flow (stage), so need coincident frequency analysis here too.

Round 3 these 2 guys

Round 3: These 2 guys

Martis dam pmf study

Martis Dam PMF study

  • Joe DeVries managed PMF study (for Corps) of Martis Dam.

  • PMF=runoff from severe combo of meteorologic+ hydrologic conditions.

  • Caused by PMP.

  • PMP in this watershed has snowmelt.

Ferc snowmelt guidelines

FERC snowmelt guidelines

  • Compute using HEC-1 energy-budget model.

  • Requires

    • Shortwave radiation

    • Dewpoint temperature

    • Temperature sequence

    • Wind speed sequence

    • Rainfall sequence

    • Area covered by snow at start of storm

    • Snowpack water equivalent

    • Snowmelt temperature

    • Change in temperature with elevation

Where do we get data to calibrate verify snowmelt model

Where do we get data to calibrate/ verify snowmelt model?

Our hero

Round 3 joe devries and david parker

Round 3: Joe DeVries and David Parker

  • Joe DeVries managed PMF study of Martis Dam for Sacramento District of Corps.

  • Martis Dam PMF inflow includes snowmelt runoff, so snow data + snowmelt model needed.

  • Snow data stored by CDEC.

  • David Parker manages CDEC data dissemination system.

What s my point

What’s my point?

  • Kevin Bacon linkages are a fact in flood modeling. Flood studies often related by goals, methods, data, analysts, results.

  • We never really finish much. Flood studies may have a long legacy, so:

    • Do them good enough initially.

    • Take the time to document them.

  • Share your toys. Flood models, carefully assembled, can be re-usable and scalable.
