Presentation Transcript


Designing state machines sqrt controller

Designing State MachinesSQRT controller

Lecture L9.2a

Section 9.2


Sqrt controller

SQRT Controller

  • Mealy and Moore Machines

  • SQRT Controller


A canonical sequential network

A canonical sequential network


A mealy state machine

A Mealy state machine


A moore state machine

A Moore state machine


Designing state machines sqrt controller

SQRTctl


Designing state machines sqrt controller

Lab 8


Designing state machines sqrt controller

MODULE SQRTctl

interface(Clk, Clear, lteflg, strt -> ald, sqld, dld, outld);

TITLE 'Control Unit for square root algorithm'

DECLARATIONS

" INPUT PINS "

Clk PIN; " clock

lteflg PIN;" <= flag

Clear PIN;" clear

start PIN;" GCD starts when start = 1

" OUTPUT PINS "

ald, sqld, dld, outld PIN;" reg load signals


A moore state machine1

A Moore state machine


Designing state machines sqrt controller

Q1..Q0 NODE ISTYPE 'reg buffer';

Q = [Q1..Q0]; " 2-bit state vector

" Definitions

QSTATE = [Q1, Q0];

start = [0, 0];

test = [0, 1];

update = [1, 0];

done = [1, 1];

state_diagram QSTATE

state start: if strt then test else start;

state test: if lteflg then update else done;

state update:goto test;

state done:goto done;


A moore state machine2

A Moore state machine


Designing state machines sqrt controller

EQUATIONS

WHEN QSTATE == start then" a <- SW

{ald = 1; sqld = 0; dld = 0; outld = 0;}

WHEN QSTATE == test then

{ald = 0; sqld = 0; dld = 0; outld = 0;}

WHEN QSTATE == update then" sq <- sq + del; del <- del + 2

{ald = 0; sqld = 1; dld = 1; outld = 0;}

WHEN QSTATE == done then " out <- (del - 1)/2

{ald = 0; sqld = 0; dld = 0; outld = 1;}

Q.C = Clk;

Q.AR = Clear;

END SQRTctl


Designing state machines sqrt controller

Lab 8
