  1. ENUMAustrian and VISIONng Demo ENUM Informational Update ICANN25. March 2003 Rudolf BRANDNER Siemens Tel: +49 172 273 9694 E-Mail: rudolf.brandner@siemens.com Richard STASTNY ÖFEG Tel: +43 664 420 4100E-Mail: richard.stastny@oefeg.at

  2. Overview • Demonstration of the Trials • ENUM Provisioning • ENUM Queries • ENUM Call Scenarios Richard Stastny

  3. ENUM Provisioning and Query • ENUM Webpage http://enum.nic.at • ENUM Query query via UK Siemens Roke Manor • Registration of an E.164 number by an ENUM subscriber via the web-interface • Query of ENUM entries via the web-interface by ENUM subscriber • Modification of ENUM entries via the web-interface by ENUM subscriber • DNS-query of ENUM entries by ENUM User with ENUM client SW and launch of applications • Query of WHOIS data related to an E.164 number Richard Stastny

  4. ENUM Call Scenarios • VoIP Call Scenarios without ENUM • VoIP Call Scenarios with ENUM • ENUM Query by User • ENUM Query by Server • Calls to the PSTN Richard Stastny

  5. ENUM * GK or SIP Server Internet GK GK GW GK GW "ENUM" VISIONng Backbone TDM VISIONng VISIONng TDM The VISIONng Scenario GK +87810xxx Richard Stastny

  6. pulver.com telekom.at nic.at iptel.org Internet VON Demo Scenario - SIP 19824 22123 16241 mah stastny test3 FWD - FWD: 16241 dials 19824 nic.at - FWD: stastny dials 19824@fwd.pulver.com Richard Stastny

  7. pulver.com telekom.at iptel.org nic.at Internet VON Demo Scenario – SIP +ENUM 19824 22123 ENUM 16241 mah stastny test3 test3 queries ENUM for +87810 87810 87810, gets 19824@fwd.pulver.com or mah dials +87810 87810 87810, nic.at queries ENUM, gets 19824@fwd.pulver.com Richard Stastny

  8. pulver.com telekom.gw telekom.at Internet iptel.org nic.at TDM VON Demo Scenario - PSTN 19824 22123 ENUM 16241 mah stastny test3 mah dials +87810 87810 87810, nic.at queries ENUM, gets +43 664 420 4100 +43 664 420 4100 Richard Stastny

  9. The END Thank you for your attention Any Questions? Richard Stastny

  10. Austrian ENUM Trial Demo Backup Slides Richard Stastny

  11. Content • ENUM Trial Welcome Page • ENUM Query via Siemens UK Roke Manor • Telecom Austria Welcome page • ENUM Subscriber Registration • Reassurance e-mail for registration • Validation using Phone Directory • Structured E-Mail to Tier 1 Registry • Confirmation e-mail to ENUM Subscriber • ENUM Subscriber Login • ENUM Subscriber edits NAPTR • ENUM Subscriber commits to ENUM • ENUM User queries with ENUM Client • ENUM User queries with (another) ENUM Client • Austrian ENUM Webpage • WHOIS query Richard Stastny

  12. ENUM Website Richard Stastny

  13. ENUM Website Richard Stastny

  14. Telekom Austria Welcome page Richard Stastny

  15. ENUM Subscriber Registration Richard Stastny

  16. Reassurance e-mail for registration • ----------------------------------------------------------------------------------------------------------- • Dear user, • you have been successfully registered to the enum trial system with the following data: • Max MustermannSeering 68141 UnterpremstättenAustria4331680031100 • email: max.mustermann@infonova.at • organisation: INFONOVA • E164 Numbers: • - 4331680031100 • Awaiting confirmation by the administrator. • -------------------------------------- • This Mail was generated automatically, • please do not reply. • ------------------------------------------------------------------------------------------------------------ Richard Stastny

  17. Validation using Phone Directory Richard Stastny

  18. Structured e-mail to Tier 1 Registry (nic.at) • -----Original Message----- From: ENUM System Notifier [mailto:enumtrial@infonova.com] Sent: Mon 25/11/2002 14:20 To: Administrator Cc: Subject: ENUM-ANTRAG 0.0.1.1.3.0.0.8.6.1.3.3.4.e164.arpa===========================Version: 164.0 (Bitte Versionsnummer NIEMALS loeschen)===========================DOMAIN OBJECTdomain:0.0.1.1.3.0.0.8.6.1.3.3.4.e164.arpadescr:[organisation]:INFONOVAdescr:[name]:Max Mustermanndescr:[street address]:Musterstrasse 4descr:[postal code]:8541descr:[city]:Grazdescr:[country]:Austriadescr:[phone]:031680031100descr:[e-mail]:max.mustermann@hotmail.atadmin-c:tech-c:zone-c:nserver:remarks:nserver:remarks:registrar-id:mnt-by: ENUM-TRIAL-AT-MNTsource: ENUM-TRIAL-AT Richard Stastny

  19. Confirmation Mail to ENUM Subscriber with Login Information • ------------------------------------------------------------------------------------------ • Dear Max Mustermann, • your request for registration was confirmed by the enum system. • Your userdata is: • ================= • User ID: 000784 • Password: lu788dca794 • -------------------------------------- • This Mail was generated automatically, • please do not reply. • ---------------------------------------------------------------------------------------------------------------------------------------------------------------- Richard Stastny

  20. ENUM Subscriber Login Richard Stastny

  21. ENUM Subscriber edits NAPTR Richard Stastny

  22. ENUM Subscriber commits to ENUM Richard Stastny

  23. ENUM User queries with ENUM Client Richard Stastny

  24. ENUM User queries with Enum Client Richard Stastny

  25. ENUM Website Richard Stastny

  26. ENUM User queries with Enum Client Richard Stastny
