  1. CASE STUDY OF A MULTYCYCLE DATAPATH

  2. 32 0 Mux 0 Mux 1 Instruction Reg ALU Out 32 0 1 Mux 32 32 1 ALU Control Mux 1 0 Extend 16 4 << 2 Alternative Multiple Cycle Datapath (In Textbook) • Minimizes Hardware: 1 memory, 1 ALU PCWr PCWrCond PCSrc Zero ALUSrcA IorD MemWr IRWr RegDst RegWr 1 Mux 32 PC 0 PC Zero 32 Rs Ra 32 Address 5 32 Rt 32 Rb busA A ALU Ideal Memory 32 Reg File 5 Rt 0 Rw 32 32 B 32 Rd 1 Mem Data Reg Din Dout busW busB 2 32 3 MemRd Imm 32 ALUOp MemtoReg ALUSrcB

  3. State Diagram: operations for Each Cycle Logic Immediate IR ¬ Mem[PC] State= 00000 A ¬ R[rs] B ¬ R[rt] PC ¬ PC + 4 State= 00010 ALUout ¬ A Op ZeroExt[imm16] State= 01010 R[rt] ¬ ALUout State= 01011 Go Next state= 00000 R-Type IR ¬ Mem[PC] State= 00000 A ¬ R[rs] B ¬ R[rt] PC ¬ PC + 4 State= 00001 ALUout ¬ A Op B State= 01000 R[rd] ¬ ALUout State= 01001 Go Next state= 00000 Store IR ¬ Mem[PC] State= 00000 A ¬ R[rs] B ¬ R[rt] PC ¬ PC + 4 State= 00100 ALUout ¬ A Op SignExt[imm16] State= 01111 Mem[R]¬ALUout State= 010000 Go Next state= 00000 Cond-Branch IR ¬ Mem[PC] State= 00000 A ¬ R[rs], B ¬ R[rt], Z[R[rs]-R[rt]] PC ¬ PC + 4 State= 00101 PC ¬ (PC + 4) + (Z=1) (SignExt(imm16) x4) State= 010001 Go Next state= 00000 Branch IR ¬ Mem[PC] State=00000 PC ¬ [PC + 4]28-31, (IMM-26)26] State= 00110 Go Next State 00000 Load IR ¬ Mem[PC] State= 00000 A ¬ R[rs] B ¬ R[rt] PC ¬ PC + 4 State= 00011 ALUout ¬ A Op SignExt[imm16] State= 01100 MDR ¬ ALUout State= 01101 R[rt] ¬ MDR State= 01110 Go Next state= 00000 IF ID EX/M WB

  4. IF Current Op field Z Next IR PC Ops Exec Mem Write-Back State A B Ex Sr ALU S R W M M-R Wr Dst ID BEQ R I LW SW

  5. IF Current Op field Z Next IR PC Ops Exec Mem Write-Back State A B Ex Sr ALU S R W M M-R WrDst 00000 XXXX ? 00001 1 00001 R-type x 01000 1 1 00010 I-type x 01010 1 1 00011 LW x 01100 1 1 00100 SW x 01111 1 1 00101 BEQ x 00111 1 1 00110 Jump x 00000 1 1 00111 xxxxxx x 00000 1 1 01000 xxxxxx x 01001 0 1 fun 1 01001 xxxxxx x 00000 1 0 0 1 1 01010 xxxxxx x 01011 0 0 or 1 01011 xxxxxx x 00000 1 0 0 1 0 01100 xxxxxx x 01101 1 0 add 1 01101 xxxxxx x 01110 1 0 1 01110 xxxxxx x 00000 1 0 1 1 0 01111 xxxxxx x 10000 1 0 add 1 10000 xxxxxx x 00000 1 0 0 1 ID BEQ R I LW SW
