Semantic representation of events in 3d animation

Semantic representation of eventsin 3D animation

Minhua Eunice Ma and Paul Mc Kevitt

School of Computing and Intelligent Systems

Faculty of Informatics

University of Ulster, Northern Ireland


Seanchaí:

an Intelligent MultiMedia storyteller

Seanchaí

multimodal presentation

CONFUCIUS

(story interpretation & presentation)

Homer

(story generation)

natural language stories

user input

user input

(text: stories, play/movie scripts)


CONFUCIUS:

story interpretation & presentation

Story in natural language

Storywriter /playwright

Speech (dialogue)

User

/story listener

Movie/drama script

CONFUCIUS

3D animation

non-speech audio

Tailored menu for script input


Architecture of confucius
Architecture of CONFUCIUS

Natural language stories

Script writer

Script parser

Prefabricated objects

(knowledge base)

lexicon

grammar

etc

Natural Language Processing

Text To Speech

Sound effects

Language knowledge

semantic representations

3D authoring tools

mapping

visual knowledge

Animation generation

visual knowledge

(3D graphic library)

Synchronizing & fusion

3D world with audio in VRML


Semantic representation languages
Semantic Representation Languages

Sentence level semantics

  • FOPC (First Order Predicate Calculus)

  • Semantic networks

  • Conceptual Dependency (CD) (Schank 1973)

    • Primitives and scripts

  • Frame-based representations (Minsky 1975)

    Verb Semantics

  • event-logic truth conditions (Siskind 1995)

  • x-schemas with f-structures (Bailey et al. 1997)


Multimodal semantic representation
MultiModal semantic representation

Multimodal semantics

High-level multimodal semantic representation:

XML-based/frame-based

Media-independent representation

Visual media-dependent representation

Intermediate level

Audio media-dependent representation

Non-speech audio modality

Visual modality

Language modality


Knowledge base of CONFUCIUS

knowledge base

Semantic knowledge - lexicons (eg. WordNet)

Syntactic knowledge - grammars

Statistical models of language

Associations between words

Language knowledge

Object model (nouns)

Functional information

Internal coordinate axes (for spatial reasoning)

Associations between objects

Event model (event verbs, describes the motion of objects)

Visual knowledge

World knowledge

Spatial & qualitative reasoning knowledge


Categories of events
Categories of events

  • Atomic entities

    • Change physical location such as position and orientation, e.g. “bounce”, “turn”

    • Change intrinsic attributes such as shape, size, color, and texture, e.g. “bend”, and even visibility, e.g. “disappear”, “fade” (in/out)

  • Non-atomic entities

    • Non-character events

      • Two or more individual objects fuse together, e.g. “melt” (in)

      • One object divides into two or more individual parts, e.g. “break” (into pieces)

      • Change sub-components (their position, size, color), e.g. “blossom”

      • Environment events (weather verbs), e.g. “snow”, “rain”

    • Character events

      • Action verbs

        • Intransitive verbs

        • Transitive verbs

      • Non-action verbs (stative, emotion, possession, mental activities, cognition & perception)

      • Idioms & metaphor verbs


Categories of action verbs

involve speech modality

Categories of action verbs

  • Intransitive verbs

    • Biped kinematics, e.g. “walk”, “swim”, & other motion models like “fly”

    • Face expressions, e.g. “laugh”, “anger”

    • Lip movement, e.g. “speak”, “say”

  • Transitive verbs

    • single object, e.g. “throw”, “push”, “kick”

    • multiple objects

      • direct and indirect objects, e.g. “give”, “pass”, “show”

      • indirect object & the tool used to perform the action, e.g. “cut”, “hammer”


Basic predicate arguments
Basic predicate-arguments

1)  move(obj, xInc, yInc, zInc)

2)moveTo(obj, loc)

3) moveToward(obj,loc,displacement)

4) rotate(obj,xAngle,yAngle,zAngle)

5)faceTo(obj1, obj2)

6)alignMiddle(obj1, obj2, axis)

7)alignMax(obj1, obj2, axis)

8)alignMin(obj1, obj2, axis)

9)alignTouch(obj1, obj2, axis)

10) touch(obj1, obj2, axis)

11) scale(obj, rate)

12) squash(obj, rate, axis)

13) group(x, [y|_], newObj)

14) ungroup(xyList, x, yList)


Hierarchical structure of predicates

3rd level

2nd level

Atomic level

touch()

moveToward(), alignMiddle(),alignTouch(), alignMax(), alignMin(), faceTo()

move(), moveTo(), rotate(), scale(), squash()


y

Front view

Top view

x

y

z

z

x

obj2

obj2

before

obj1

obj1

obj2

obj2

touch(obj1, obj2, x):-

alignMiddle(obj1,obj2,y),

alignMiddle(obj1,obj2,z),

alignTouch(obj1,obj2,x).

obj1

obj1

after

obj2

obj2

touch(obj1, obj2, y):-

alignMiddle(obj1,obj2,z),

alignMiddle(obj1,obj2,x),

alignTouch(obj1,obj2,y).

obj1

obj2 is on the top

obj1

obj2

obj2

obj1

touch(obj1, obj2, z):-

alignMiddle(obj1,obj2,x),

alignMiddle(obj1,obj2,y),

alignTouch(obj1,obj2,z).

obj1 is in the front

obj1


Decomposite predicate argument model an example call
Decomposite predicate-argument model-- an example: “call”

First Level

call(a):-

type(a, Person),

type(tel, Telephone),

pickup(a, tel.receiver,a.leftEar),

dial(a, tel.keypad),

speak(a, tel.receiver),

putdown(a, tel.receiver, tel.set).

Second Level

pickup(x,obj,dest):-

type(x, Person),

moveToward(x.leftHand,location(obj),location(obj)-location(x)-5),

touch(x.leftHand, obj, axis),

group(x.leftHand, obj, xHandObj),

moveToward(xHandObj, dest, _).

putdown(x, obj, dest):-

moveTo(x.leftHand, dest),

ungroup(x, obj, x1),

type(x1, Person).


Visual definition word sense

one

many

many

many

Visual definition & word sense

polysemy

verb

word sense

visual definition entry

mapping

synonymy

  • a normal door (rotation on y axis)

  • a sliding door (moving on x axis)

  • a rolling shutter door (a combination of rotation on x axis and moving on y axis)

Example: “close” (a door)

word sense -- minimal complete unit of meaning in the language modality

visual definition entry -- minimal complete unit of meaning in the visual modality


Troponyms verbs derived from adjectives nouns
Troponyms & verbs derived from adjectives/nouns

  • troponym

    • elaborates the manners of a base verb (Fellbaum 1998)

    • examples: “trot”-“walk” (fast), “gulp”-“eat” (quickly)

    • base verb + adverb

      present the base verb + modify the manner (speed, the agent’s state, duration of the activity, iteration, etc.)

  • Verbs derived from adjectives or nouns

    • change objects’ properties (size, color, shape) or the world state

    • verbs with affixes such as –en, -ify, or –ize, e.g. “lengthen”

    • using predicates scale(), squash() or changing the corresponding property fields of the object in VRML


Representing active passive voice
Representing active & passive voice

  • active and passive voice

  • converse verb pairs such as “give/take”, “buy/sell”, “lend/borrow”

  • same activity from different point of view

  • use of VRML Viewpoint node


Implementation semantics vrml
Implementation: semanticsVRML

DEF ball Transform {

translation 0 0 0

children [

DEF ball-TIMER TimeSensor {

loop TRUE

cycleInterval 0.5 },

DEF ball-POS-INTERP

PositionInterpolator {

key [0, 0.5, 1 ]

keyValue [0 0 0, 0 20 0, 0 0 0 ] },

Shape {

appearance Appearance {

material Material {}

}

geometry Sphere { radius 5 }

}]

ROUTE ball-TIMER.fraction_changed TO

ball-POS-INTERP.set_fraction

ROUTE ball-POS-INTERP.value_changed TO

ball.set_translation

}

(c) Output  VRML code of a bouncing ball

Example: “A ball is bouncing”

bounce(obj):-

move(obj, 0, 20, 0),

move(obj, 0, -20, 0).

(a) visual definition of “bounce”

DEF ball Transform {

translation 0 0 0

children [

Shape {

appearance Appearance{

material Material{}

}

geometry Sphere {

radius 5

}

}

]

}

(b) VRML code of a static ball


Relation to previous work

  • Semantic decomposition

  • previous decomposite methologies

    (e.g. Schank’s CD analysis)

  • basic predicates “move”, “go”, “change”

  • pros and cons

    • generative and interpretative facilities (Jackendoff, 1972)

    • inadequate to capture the creative aspect of meaning

  • comparison

    • aimed at presentation purposes for visual modalities

    • no emphasis on atomic predicates


high level

low level


Conclusion future work
Conclusion & future work

  • Conclusion

    • formalizes meaning of action verbs

    • implement in Java & VRML

    • reusable in other systems

  • Future work

    • inadequate

    • vagueness problem in language visualisation (underspecification)

    • temporal relations between sub-activities

    • representing non-action verbs & adjectives

    • using other modalities (e.g. speech/audio) to aid event representation
