A Secure Clustering Algorithm for Distributed Data Streams

1. A Secure Clustering Algorithm for Distributed Data Streams Geetha Jagannathan Rutgers University Joint work with Krishnan Pillaipakkamnatt and D. Umano

2. Outline • The problem • Prior results • Clustering data streams • Experimental results and comparison • A privacy-preserving protocol • Conclusion

3. The problem • Alice and Bob each have a data stream, defined on the same attributes. (horizontal partition) • The wish to compute a clustering on the combined data.

4. Bob Alice

5. Clustering on joint data Alice’s Data k = 4

6. Clustering on joint data Bob’s Data k = 4

7. Clustering on joint data Combined Data k = 4

8. Trusted third party k-clustering k-clustering Bob Alice

9. Privacy requirements • Parties are semi-honest • Same as trusted third party • Reveals nothing but the final output • In this case – the k cluster centers

10. Prior results • PPDM protocols convert distributed DM algorithms into private ones • The k-means algorithm is the basis for many clustering protocols [VC03, JKM05, JW05, BO07] • “Leak” intermediate information • [JPW05] presents a leak-free clustering protocol based on a new clustering algorithm.

11. Our Contributions • A leak free privacy-preserving protocol for distributed data streams. • A data stream clustering algorithm • Better than k-means (on average) • Comparable performance with BIRCH on many data sets, but with lower memory needs.

12. Data Stream Algorithms • Data arrives in “stream” fashion: d1, d2, …, dn, … (the “end” of the stream is not known ahead of time). • Data is too large to fit entirely in memory. • Data can be accessed only in the order that it arrives. • Each data item can only be “read” once.

13. The clustering algorithm • “Incrementally agglomerative”: It merges intermediate clusters without waiting for all the data to be available. • Runs in time linear in n.

14. Overview of clustering algorithm K = 5 Output expected after n = 25 data points Output Level 2 clustering Level 1 clustering Level 0 clustering

15. Clustering Algorithm Outline • The algorithm maintains a list of k-clusterings (each clustering is on some partial data). • In each iteration: • Input the next k data points as a level-0 clustering. • If two clusterings at level i are in the list, “merge” them into a level-(i + 1) k-clustering.

16. Clustering algorithm outline • If output is needed after some n points have been read, all k-clusterings are “merged” into a single k-clustering.

17. “Merging” clusterings • Have a set S clusters, which |S| > k. • Need a set S' of k clusters. • S' = S • Repeat • Compute merge error for every pair of clusters • Take the union of the pair with lowest error • Until |S'| = k

18. Error (C1 U C2) = C1.weight * C2.weight * (dist(C1, C2))2

19. Sample results (offset grid)

20. Sample results (vs k-means)

21. Sample result (vs. BIRCH)

22. Realistic Data (Network Intrusion)

23. The Secure Protocol • Input: Alice owns data stream D1 Bob owns data stream D2 • Output : k-clusters on D1m U D2n • Alice computes O(k log ( )) cluster centers and Bob computes O(k log ( )) cluster centers • Alice and Bob securely share their cluster centers • They securely merge clusters

24. Sample Run(Distributed non-private protocol)

25. Complexity • Communication complexity: O((k log(mn/k2)2) • Non-private setting (one party sends the intermediate clusters to the other) • Comm complexity: O(k log (m/k))
