Presentation Transcript
Adopting the experience api to work with the virtual patient standard how what and why

Adopting the Experience API to work with the Virtual Patient Standard - how, what and why?

Matt Cownie, Jonathan Wright

University of the West of England, Bristol


Abstract
Abstract Standard - how, what and

The eXperience Application Programming Interface (xAPI) is a new specification that allows learning content to link with learning systems to track and share all types of learning experiences. Learning activities can be tracked using combinations of a limited vocabulary of activities, verbs and subjects. While the specification provides a default profile of activities and verbs it allows for communities of practice to develop custom profiles of their own agreed activities and verbs. This presentation will have main 3 parts.


XAPI Standard - how, what and

Actor, Verb, Object

Leaner , Completed, Virtual Patient


Caveat emptor
Caveat Emptor Standard - how, what and

  • Tincan OR experienceAPI OR xAPI

  • Versions 0.90-0.95-1.0-1.01

  • Many examples are ‘slightly wrong’

  • Libraries for Java, JS and PHP

  • New .NET Library for the Tin Can API is Now Available!

  • Refer to the final spec 1.0.1

  • Assumes you are VP Standard aware


Part 1 how
Part 1 - How Standard - how, what and

Firstly it will demonstrate how to use the experience API to capture the stream of activities a learner generates while playing a Virtual Patient (VP). It will show technical examples that map VP concepts onto XAPI calls that can be used to populate a Learning Record System (LRS) with VP related learner data.


Simplest example c
Simplest example (C#) Standard - how, what and

Actor

Verb

Activity

Activity

Type

Statement

LRS

statement = actor + verb + activity


We made a statement
We made a statement Standard - how, what and

http://tincanapi.com/public-lrs/

Statement in the LRS


Json payload
JSON payload Standard - how, what and

URL


URI Standard - how, what and

URL


Simplest example javascript
Simplest example (JavaScript) Standard - how, what and


More detail
More detail? Standard - how, what and

COP Verb ?

“verb” : { “display” : {“en-US” :”visited”}, “id” : ”http://medbiq/exapi/verbs/visited },

COP Activity ?

“type” : http://medbiq/exapi/activites/virtualPatient/ } } }


Looks like but
Looks like, but Standard - how, what and


More detail with context simple
More detail with context (simple) Standard - how, what and

Tie everything together


sessionId Standard - how, what and


Xapi contextactivities
XAPI - ContextActivities Standard - how, what and

XAPI provides four possibilities - ‘parent’, ‘grouping’, ‘category’, and ‘other’

Parent - model the Virtual Patient as parent activity and set that as the context for all subsequent related activities. Further granularity would be a video and MCQ with a node as parent activity.

Grouping - might want to group an activity within the VP with related activities in same VP or other VPs

Category - “Category SHOULD be used to indicate a "profile" of xAPIbehaviors” - e.g. PhysicalExam, Medication?

Other - none of the above, perhaps supporting learning material or making a branching decision?


Some concerns
Some Concerns Standard - how, what and

  • Media Resources, Counters, CounterRules, DataItems,NodeRules, NodeAccessRules

  • Extensions

  • Exposing internal workings and Id’s

  • Name spacing

  • Versioning

  • Who’s the audience?


Part 2 what
Part 2 - what Standard - how, what and

Secondly it will review what this data looks like in an LRS and examples of querying it for meaning. It will outline what verbs and activities might be contained in a Virtual Patient specific profile and what use cases these could meet.


Simplest manual get c
Simplest – manual get (c#) Standard - how, what and

query

results


Dashboard
Dashboard Standard - how, what and


A report builder
A Report Builder Standard - how, what and


Statement forwarding
Statement Forwarding Standard - how, what and

Painting by Eugene Delacroix, available under a Creative Commons Public Domain license.


Verbs and activities and url s
Verbs and Activities and URL’s Standard - how, what and


Vp activities types
VP Activities + types Standard - how, what and

Page : page

Video : video

Html5 activity : interaction

Document : file

audio : audio

MCQ : question

YouTubeVid : media

Short answer : note

Flash activity : interaction

CounterRules : event

DataItems : file?

Image : media

NodeRules : event

Blood Test : media

Unity activity : interaction

DataItemRequest : interaction

CounterRules : event

Media Resources : media

NodeAccessRule : event


VP Verbs Standard - how, what and

Visited : was at

Commented : commented

Played : played

restarted : terminated?

Listened : listened

Watched : watched

Altered: updated?

Read : read

Triggered: ?????

Started : started

Answered :answered

Requested :requested

Completed : completed

Exited : exited


Extensions and profile
Extensions and Profile Standard - how, what and

counter : extension

feedback : extension


Part 3 why for vp s
Part 3 – why (for VP’s) Standard - how, what and

Lastly it will outline why the virtual patient community might want to adopt the experience API and ask whether a specific community profile is necessary. Influences for consideration include the “Internet of Things”, mobile learning, data-mining, combining virtual patients with other simulation activities, capturing the complete educational context of a learners VP experience and reporting into competency frameworks.


What were my use cases
What were my use cases? Standard - how, what and

  • Reporting

  • Big Data

  • Learning Management System(s)

  • LTI 1.1 &outcomes

  • Simulation


Other vp use cases
Other VP use cases? Standard - how, what and

  • 3D & Games

  • Multi-modal simulation

  • Team based

  • Platform transition (state API)

  • Learner Profiles


Wider reasons to adopt xapi
Wider reasons to adopt XAPI Standard - how, what and

  • Transversal

  • Transparency

  • System silos

  • Simulation (non-linear)

  • Mobile

  • Innovation

  • Future proof


Answer the question
Answer the Question… Standard - how, what and

Is a specific VP community profile necessary?


A friend in need
A friend in need Standard - how, what and

http://www.adlnet.gov/tla/experience-api

https://github.com/adlnet/xAPIWrapper

http://nodejs.org/

https://www.npmjs.org/package/adl-xapiwrapper

https://github.com/LearningLocker/learninglocker

http://thedesignspace.net/misc/xapi

https://github.com/RusticiSoftware/TinCan.NET

https://github.com/RusticiSoftware/TinCanJS

https://registry.tincanapi.com/

http://tincanapi.com/public-lrs/

http://scorm.com/scorm-solved/scorm-cloud-developers/
