    1. NPOESS Preparatory Project (NPP) Overview

    2. NPP Mission Overview

    3. Page-3 NPP Origins NPP is a joint partnership between NASA’s Science Mission Directorate and the NPOESS Integrated Program Office (IPO) initiated in 1998 Feasibility study began in November 1998 Formulation began in November 1999 NASA Confirmation Review completed in November 2003 The partnership provides both organizations with considerable cost savings while achieving their key program objectives: To provide NASA with continuation of a group of global change observations initiated by the Earth Observing System (EOS) TERRA, AQUA, and Aura missions To provide the NPOESS operational community with pre-operational risk reduction demonstration and validation for selected NPOESS instruments, and algorithms, as well as the ground system

    4. Page-4 NPP Roles / Responsibilities

    5. Page-5 Mission Segments and Responsibilities

    6. Page-6 NPP Developers

    7. Page-7 Mission Data Products NPP (and later the NPOESS Space Segment) will produce sensor data for processing by the NPOESS Interface Data Processing Segment (IDPS) The IDPS will produce Environmental Data Records (EDR’s) of geophysical products in an operational environment while minimizing data latency NASA, NOAA, and other agencies will leverage the operational EDR’s in performing climate research ADS will archive the IDPS xDRs (RDRs, SDRs, EDRs) SDS is intended to be a research tool in support of NASA’s efforts

    9. Page-9 Payload Complement Comparison

    10. Page-10

    12. NPP Space Segment Overview

    13. Page-13

    14. Page-14 Space Segment Elements Space Segment is comprised of seven elements Spacecraft VIIRS CrIS ATMS OMPS CERES Ground Support Equipment Need updated S/C Nadir Deck ViewNeed updated S/C Nadir Deck View

    15. Page-15 NPP Space Segment Key Requirements Orbit: 824 km, sun-synch (i=98.7 deg), 1:30 pm Ascending Node S-band Command and Telemetry Ground (Svalbard) Uplink: 2 & 128 kbps Downlink: 1, 4, 16, 32 kbps real-time TLM 512 kbps playback TLM TDRSS Uplink: 0.125 & 1 kbps Downlink: 1, 4, 16 kbps real-time TLM Uplink encryption Caribou X-band 300 Mbps Stored Mission Data (SMD) downlink SSR has SMD storage capacity for 3.5 orbits (343 Gbit) Simultaneous playback while recording SMD X-band 15 Mbps High Rate Data (HRD) direct broadcast of mission data Real-time downlink of mission data to users within HRD antenna FOV Continuous operation in normal science mode NPP Spacecraft High Rate Data RF ICD to the Direct-Broadcast Stations GSFC 429-03-02-24 NPP Mission Data Format Control Book GSFC 429-05-02-42

    16. Page-16 NPP Space Segment Key Requirements Support 5 instrument payload suite ATMS, CERES, & OMPS (1553 data interface) CrIS & VIIRS (1394 data interface) Support instrument power, mass and FOV requirements Provide required discrete command and telemetry interfaces (pulse commands, TOD pulse, thermistors, bilevel status) Controlled Reentry Enhanced propulsion module (320 kg propellant) 2 sets of 4 thrusters (pri/red sets) MELV launch vehicle compatible Boeing Delta-II (7920-10 configuration) 4-point launch vehicle interface (6915 PAF)

    17. Page-17 Visible/Infrared Imager/Radiometer Suite (VIIRS) Need updated marginsNeed updated margins

    18. Page-18 Cross-track Infrared Sounder (CrIS) Need updated margins Need updated margins

    19. Page-19 Advanced Technology Microwave Sounder (ATMS) Need updated margins Need updated margins

    20. Page-20 Ozone Mapping Profiler Suite (OMPS) Need updated margins Need updated margins

    21. Page-21 Clouds and the Earth’s Radiant Energy System (CERES) Need updated margins Need updated margins

    22. Page-22 NPP Satellite - Nadir Deck View Instruments lined up along cold facing panel

    23. NPP Prop. Module Integration

    24. Page-24 NPP Satellite - Zenith Deck View Majority of S/C components are mounted on zenith deck

    25. NPP Programmatics

    26. Page-26 Nature of Program Peer-to-Peer Partnership NASA / IPO / NOAA Shared Risk Agency-centric vulnerabilities Shared Control Joint Project Management Joint award fee representation Joint Oversight Tri-Agency (NOAA, NASA and DoD) Steering Committee Executive Committee (EXCOM) No Exchange of Funds Each partner will contribute mission components “in-kind”

    27. Page-27

    28. Page-28 Post Risk Reduction Phase Hardware Review (L-26m) CrIS FU1 Pre-Ship Review (PSR) 5/08 OMPS FU1 Pre-Ship Review (PSR) 8/08 Mission Operations Review (MOR) (L-18m) Mission Test Readiness Review (MTRR) (L-13m) VIIRS FU1 Pre-Ship Review (PSR) 3/10 Satellite Pre-Environmental Review (PER) (L-10m) Operational Readiness Review (ORR) (L-5m) Satellite Pre-ship Review (SPSR) (L-3m) Mission Readiness Review (MRR) (L-2m) Flight Readiness Review (FRR) (L-1/2w) Launch Readiness Review (LRR) (L-1/2d) Operations Hand-over Review (OHR) (L+3m) Mission Transfer Review (MTR) (L+6m)

    29. NPOESS Preparatory Project (NPP) Level 1 Joint Master Schedule
