实验十. A/D 转换实验. 实验要求. 1 、利用实验板上的 ADC0809 做 A/D 转换器，实验板上的电位器提供模拟量输入，编制程序，将模拟量转换成二进制数字量，用发光二极管显示。. 实验目的. 1. 掌握 A/D 转换与单片机的接口方法。 2. 了解 A/D 芯片 ADC0809 转换性能及编程。 3. 通过实验了解单片机如何进行数据采集。. 实验电路及连线. 开始. 初始化. 启动 A/D. 否. A/D 转换完. 数据输出. 清读数标志. 程序框图. 程序清单. CS0809 equ 08000h mov dptr, #CS0809
