  1. draft-khan-ip-serv-peer-arch-03.txtSPEERMINT Peering Architecture IETF-66, Montreal, Canada Sohel Khan, Ph.D. Technology Strategist

  2. Status • New authors • Reinaldo Penno, Juniper Network • Daryl Malas, Level 3 • Sohel Khan, Sprint • Adam Uzelac, Global Crossing • Mike Hammer, Cisco • Important Contributor • Otmar Lendl • Signification revision as per the input from • the IETF-65 meeting • the mailing list • Since, there are significant changes, we will go over the whole draft once again Sohel Khan, Ph.D., Sprint-Nextel

  3. Introduction • The Draft Defines • a reference SPEERMINT architecture • functional components • and peering interface functions Sohel Khan, Ph.D., Sprint-Nextel

  4. Peering Network Context Public Peering Function/Federation Entity Location Function Enterprise Provider A (L5) Enterprise Provider B (L5) Public (L3) Service Provider C (L5) Service Provider D (L5) L3 Peering Point (out of scope) Enterprise Provider E (L5) Enterprise Provider F (L5) Private (L3) Service Provider G (L5) Service Provider H (L5) Private Peering Function/Federation Entity Location Function Sohel Khan, Ph.D., Sprint-Nextel

  5. Federation • A providers' group • that has contractual agreements on various aspects of peering relationship • such as common: • administrative policy, • settlement, and • terminating calls. • The members of a federation may • jointly use a set of entities such as: • location function, • application servers, • subscriber databases, • SIP proxies , • and/or platforms that synthesize various SIP and non-SIP based applications. Sohel Khan, Ph.D., Sprint-Nextel

  6. Reference Peering Architecture LF LF LF OF OF SF SF SIP Service Provider Y SIP Service Provider X MF MF QF QF AF AF Security Security Ref. Purpose LF Enables discovery of the SF or OF Enables discovery of SF or exchanges policy/parameters to be used by SF OF Enables discovery of endpoints, assists in discovery and exchange of parameters to be used with the MF SF MF Enables media paths interconnection between endpoints QF Negotiates and reserves bandwidth resources, as well as polices/provides measurements for media paths Application Function: TBD or deleted AF Sohel Khan, Ph.D., Sprint-Nextel

  7. Location Function (LF) • Enables discovery of the next hop peering • signaling function (SF) • or operation function (OF) • Provides trusted registry database service • Can be Internal or external to a federation if a federation exists • Examples: • ENUM • DNS • Global Public Database (if hierarchical system exists ) • SIP Redirect Server • Out of scope • Number portability • Mobility Function Sohel Khan, Ph.D., Sprint-Nextel

  8. Location Function Examples ENUM: o Input: E.164 o Output: SIP AoR of a next hop Signaling Function (SF) or OF. DNS: o Input: Domain Name from the AoR of an end user o Output: SIP AoR of the next hop Signaling Function (SF) Global Public Database (if hierarchical system exists): o Input: • Local Signaling address (local context) • The domain name of an end user • the domain name of a destination service provider o Output: The next hop reachable address. SIP Redirect Server o Input: E.164 address or domain Name from the AoR of an end user o Output: SIP AoR of the next hop Signaling Function (SF) Sohel Khan, Ph.D., Sprint-Nextel

  9. Operation Function (OF) • Enables discovery of SF • Exchanges policy/parameters to be used by SF • Implementation is optional • Examples • Dynamic subscribe, notify, and exchange of policy information and parameters among providers • SLA Exchange • Accounting Data Exchange Sohel Khan, Ph.D., Sprint-Nextel

  10. Signaling Function (SF) • Performs L5 peering function • Enables discovery of endpoints, • Assists in discovery and exchange of parameters to be used with the MF • Examples of main components: • SIP Proxy, SIP B2BUA as per SIP RFCs • Other examples (optional) • Session Admission Control (SAC) • SIP DoS Protection • SIP Topology Hiding • SIP Security, Privacy, and Encryption Sohel Khan, Ph.D., Sprint-Nextel

  11. Media Function (MF) • Enables media paths interconnection between endpoints • Examples: • Transcoding of one voice coding to other • e.g., G.711 to EvRC • RTP Relay • Media security Sohel Khan, Ph.D., Sprint-Nextel

  12. QoS Function (QF) • Negotiates and reserves bandwidth resources, as well as polices/provides measurements for media paths • Ensures incoming and outgoing packets are marked correctly according to federation and peer policy • Implementation is Optional unless government regulation mandates • Various standard body should agree on a compatible set of SIP priority header mapping with particular attention to ETS/WPS Sohel Khan, Ph.D., Sprint-Nextel

  13. Application Function (AF) • Do we need it? • If we need it • Please write use cases in the discussion list Sohel Khan, Ph.D., Sprint-Nextel

  14. Deployment Option SF SIP SIP Service Provider X SF MF SIP Service Provider Y RTP MF • Composed or Decomposed: SF and MF • Centralized or Distributed: whether logical and physical functions are in one geographical point • or functions are distributed among multiple geographical locations • When one SF controls multiple MFs, which MF (IP address) the media should be • forwarded to? Sohel Khan, Ph.D., Sprint-Nextel

  15. Next Step • Continue to improve the draft • Accept the draft as a working group item Sohel Khan, Ph.D., Sprint-Nextel
